PureLink CSW110 Bedienungsanleitung

CSW110 User Manual | Benutzerhandbuch

-2-

SAFETY WARNINGS

• To prevent short circuits, this product should only be used inside and only in dry spaces. Do not

expose the components to rain or moisture. Do not use the product close to a bath, swimming

pool etc.

• Do not expose the components of your sytems to extremely high temperatures or bright light

sources.

• In case of improper usage or if you have altered and repaired the product yourself, all guarantees

expire. PureLink does not accept responsibility in the case of improper usage of the product or

when the product is used for purposes other than specied. PureLink does not accept responsibility

for additional damage other than covered by the legal product responsibility.

• This product is not a toy. Keep out of reach of children.

• Do not open the product: the device may contain live parts. The product should only be repaired or

serviced by a qualied expert.

• Only connect the adapter to the mains after checking whether the mains voltage is the same as the

values on the identication tags. Never connect an adapter or power cord when it is damaged. In

that case, contact your supplier.

1. INTRODUCTION

Congratulations on your purchase of the PureLink CSW110, which allows you to send a connected HD

signal wirelessly to your HDTV or HD projector.

Examples of HD devices: Blu-ray players, HD set-top boxes, PlayStation4, XboxOne, etc. The CSW110

supports FullHD resolutions up to 1080p and all 3D formats. The inbuilt loop-through function

(HDMI out) of the transmitter means that you can watch the same content on the 1st as on the 2nd

HDTV or the HD projector (via receiver). The inbuilt infrared extender function allows you to operate

HD equipment using your own remote control, even if it is kept in a closed cabinet!

PureLink products are manufactured with the utmost precision and of top quality. Please read this

manual carefully and follow the instructions in order to get the very results from this product.

2. PACKAGE CONTENT

1x PureLink CSW110 Transmitter (TX)

1x PureLink CSW110 Receiver (RX)

1x IR Receiver

1x IR Emitter

2x Power adapter 5V1A (Micro USB)

1x Manual

1x Screw Set

1x Wall Mount

-3- ENGLISH

3. CONNECTION

Step 1:

Use an HDMI cable to connect the HDMI IN of the CSW110 transmitter with a source device. You can

use another HDMI cable to connect the HDMI OUT to a display (Loop-Through).

Step 2:

Use an HDMI cable to connect the HDMI OUT of CSW110 receiver to a display device.

Step 3:

(Skip this step if you don‘t need IR Extension) Connect the IR emitter to the CSW110 transmitter. Then

place the emitter in front of the source device’s IR receiver. Connect the IR receiver to the CSW110

receiver. Then place the receiver probe in place, accessible for your remote control.

Step 4:

Connect a DC 5V1A power adapter to the power jack (MicroUSB) of the CSW110 transmitter.

Step 5:

Connect the other DC 5V1A power adapter to the power jack (MicroUSB) of the CSW110 receiver.

Step 6:

To pair receiver and transmitter, press the MODE key on the receiver‘s box and then press the MODE

key on the transmitter.

-4-

4. OPERATION

A. Installation

1. Make sure your input AC voltage is compliant with to the adapter specications.

2. Only use the power adapters provided with the CSW110. If you use your own adapter,

make sure the power output is 5V DC, 1A centre positive.

3. In a direct line-of-sight, the maximum range of A/V signal transmission can reach up to about

30 meters. This distance can be shortened by obstacles or walls placed between transmitter

and receiver. The optimum indoor range is under 30m.

4. To ensure a good infrared remote control operation, aim your remote control at the IR receiver

of the CSW110 and press the buttons rmly. For some remote controls it may be necessary

to press and hold each button for about a second. The working angle of the IR receiver is +/- 15°.

5. The remote controller has to be used within the distance of 0.3m - 5m at a working angle

of +/- 15°.

B. Transmitter & Receiver Pairing MODE

1. First press the “MODE” button on the receiver‘s box.

2. You will see a message “Connecting through Pairing ... ” on screen.

3. Then press the “MODE” button on the transmitter‘s box.

4. Wait for a few seconds for auto connection.

C. IR Extending Function

1. Make sure the IR emitter has been installed properly on the transmitter‘s box.

2. Make sure the IR receiver has been installed properly on the receiver‘s box.

3. Use the remote control of your source device to control the source form the receiver‘s box.

NOTE: Please do not cover CSW110 transmitter and receiver with any object! Those objects can

block the air circulation and cause serious defects and injuries. The warranty will also be void.

-5- ENGLISH

5. FREQUENTLY ASKED QUESTIONS

1. When there is no picture presented:

Make sure the direct connection from the source device to the sink device works properly. Check

if all connectors are connected well; check if all cables can support the transmission speed. High

Speed HDMI cables from PureLink are recommended. Unplug the power cable to restart CSW110.

2. When there is no sound:

First, try to adjust the volume of the connected sink device (TV). Check cable connection to see

if it works properly. Check cable to see if it supports video transmission only (DVI) or not. The

HDCP encryption may not match very well at rst connection; please unplug the power cable to

restart CSW110.

3. Whenthereisno3Deect(Onlyfor3Dhardware):

Make sure the 3D function of the 3D sink device is activated (set to AUTO or 3D ON). Make sure

the 3D function of the 3D source device is activated (set to AUTO or 3D ON). Make sure that the

power of the shutter glasses (if active 3D) is on. Check the power of CSW110.

4. If the image is unstable or a snowing image shows on screen:

You might get interference form other wireless devices or heavy voltage sources inside the room

(ex. WiFi Router, Microwave, air conditioner). Please keep CSW110 away from those sources of

interference. The wireless transmission distance may be too far or blocked by a wall or another

object. Please place CSW110 in another location where you can get good signal and video

quality. Please change the direction of transmitter and receiver to get a better connection.

5. If the wireless connection fails:

Please make sure, the power of the connected source device is turned ON. Unplug the power

cable to restart CSW110.

6. IF the IR extending function is not work:

Check, if the IR emitter is connected to the CSW110 transmitter and place the emitter in front of

the source device’s IR receiver. The IR extending function of CSW110 works with all 30~60kHz IR

remote control systems. Some IR remote control systems use other frequencies or the IR signal

pulse is too short and will not work with the IR extending function.

-6-

6. TECHNICAL DATA

Resolutions

Supported HDTV resolution (HDMI) 1080p, 720p, 576p, 480p

Supported PC Resolution (max.) Max. 1920 x 1080 px

Supported 3D formats Frame Packing 1080p@24Hz,720p@50/60Hz

Supported audio formats (digital) Compressed formats, AC3, Dolby 5.1, DTS

Supported standards HDMI, HDCP 2.0, EDID 1.3

Wireless

Operating frequency 5 GHz

Operating range Up to 30m LOS

Latency Max. 0.5 seconds

RF Power Output: 10dBm max. / Receive Level -10dBm min.

Frequency Band 20MHz / 40MHz(5G)

Transmitter

HDMI input 1x

HDMI output 1x

IR extender LED Yes

Dimensions 84.9 x 83 x 13.5mm

Receiver

HDMI output 1x

Dimensions 84.9 x 83 x 13.5

Infrared

Supported IR frequency 36kHz – 56kHz (NEC, RC5, RC6)

Power supply

Switch mode power adapter 100-240V AC @ 50-60Hz, 5V1A DC

The manufacturer reserves the right to make changes in the hardware, packaging, manual and any

accompanying documentation without prior notice.

The terms HDMI, HDMI High-Denition Multimedia Interface and the HDMI Logo are trademarks

or registered trademarks of HDMI Licensing LLC in the United States and other countries. CSW110

incorporates HDMI® technology.

Enviromental Information for customers in the European Union

European Directive 2012/19/EU requires that the equipment bearing this symbol on the

product and/or its packaging must not be disposed of with unsorted municipal waste.

The symbol indicates that this product should be disposed o separately from regular

household waste streams. It is your responsibility to dispose of this and other electric and

electronic equipment via designated collection facilities appointed by the government

or local authorities. Correct disposal and recycling will help prevent potential negative

consequences to the enviroment and human health. For more detailed information about

the disposal of your old equipment, please contact your local authorities, waste disposal

service or the shop where you purchased the product.

-7- ENGLISH

7. REQUIREMENTS / CONFORMITY

This product is compliant with the following requirements:

CE-Conformity

RED | 2014/53/EU (Radio Emission Directive)

PureLink GmbH hereby declares that the CSW110 radio communication system complies

with Directive 2014/53/EU.

The full text of the EU Declaration of Conformity is available at the following internet address:

http://www.purelink.de/ce/4251364708026_CE.pdf

Dispose o all electronic products by taking it to your local collection point, recycling center for such

equipment or your specialized dealer. The product includes hazardous material that can cause harm

to health and environment when disposed o incorrectly.

Please help to protect the environment in which we all live.

The respective declarations are available on request from your dealer / reseller. For any questions

regarding regulatory compliance of our products, contact your dealer or reseller. Before putting the

product into operation please observe the respective country-specic regulations!
