PureLink CSW030 Bedienungsanleitung
WIRELESS HDMI EXTENDER SET
CSW030
Instruction Manual
-2-
TABLE OF CONTENT
CHAPTER PAGE
Introduction ................................................................................................. 3
Intended Use ................................................................................................ 3
Safety Instructions .................................................................................. 4-5
Delivery Content ..........................................................................................6
.......................................................................................... 6-9
Installation ................................................................................................ 10
Application ................................................................................................ 11
FAQ ....................................................................................................... 12-13
Maintenance ............................................................................................. 14
Cleaning ..................................................................................................... 14
Warranty and Liability ............................................................................ 15
CE Conformity ........................................................................................... 16
Disposal of the Device ............................................................................ 16
Disclaimer .................................................................................................. 17
-3- ENGLISH
1. INTRODUCTION
Congratulations on your purchase of the PureLink CSW030! Repla-
ce your HDMI cable wirelessly and locate your HDTV or projector
wherever you want in the same room. No need to worry about the
location of your HD equipment. Perfect if you would rather not see
cables running across the walls or if you do not want to (or cannot)
drill holes and lay cables.
Suitable for all HDMI equipment, such as Blu-ray® Player, HD set-
top box or Laptop.
PureLink products are manufactured with the utmost precision and
are top quality. Please read this manual carefully and follow the ins-
tructions in order to get the very best from this product.
2. INTENDED USE
This product is intended for indoor use only. Do not use it
outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes (CE), you must not rebuild and/
or modify this product. If you use the product for purposes other
than those described above, the product may be damaged. In addi-
electric shock etc.
Read the instructions carefully and keep them. Make this product
available to third parties only together with its operating instruc-
tions.
-4-
3. SAFETY INSTRUCTIONS
Read the operating instructions carefully and especially observe
the safety information. If you do not follow the safety instructions
and information on proper handling in this manual, we assume no li-
ability for any resulting personal injury or damage to property. Such
cases will invalidate the warranty/guarantee.
The device is not a toy. Keep it out of the reach of children and pets.
Do not leave packaging material lying around carelessly. These may
become dangerous playing material for children.
Protect the product from extreme temperatures, direct sunlight,
solvents.
Do not place the product under any mechanical stress.
If it is no longer possible to operate the product safely, take it out of
operation and protect it from any accidental use. Safe operation can
no longer be guaranteed if the product:
•is visibly damaged,
•is no longer working properly,
•has been stored for an extended period in poor ambient
conditions or
•has been subjected to any serious transport-related stresses
Please handle the product carefully. Jolts, impacts or a fall even
from a low height can damage the product.
Also observe the safety and operating instructions of any other
devices which are connected to the product.
-5-
Consult an expert when in doubt about the operation, safety or
connection of the device.
Make sure to observe the polarity and magnitude of the output
voltage. Incorrect polarity or excessive voltage input leads to the
destruction of the connected electrical appliance.
not cover the product. Never place the product on a table cloth or
The product should not be used immediately after it has been
brought from an area of cold temperature to an area of warm tem-
perature. Condensed water might destroy the product. Wait until
the product adapts to the new ambient temperature before use.
Make sure that the output of the power adapter is not short-circui-
ted.
-
tors, and other medical devices. Keep at least 6 inches (approxima-
and this product. If you suspect this product is interfering with your
pacemaker or any other medical device, stop using it and consult
ENGLISH
-6-
4. DELIVERY CONTENT
1x PureLink CSW030 Transmitter (TX)
1x PureLink CSW030 Receiver (RX)
1x DC 5V/2A power adapter for RX
2x USB-A to USB-C cable for RX & TX
1x User Manual
5. SPECIFICATIONS
Product Size in mm: TX: 72 x 52 x 14.2mm
RX: 124 x 70 x 18.8mm
Product Weight in g: %01-/+g05:XT
RX: 168 g +/- 10%
TX: Interface HDMI in
RX: Interface HDMI out / VGA out / Audio out
WiFi Standard IEEE 802.11 protocol (5GHz)
Frequency Range 5180MHz~5240MHz (Band 1)
RF Power 10 dBm max.
Distance 30 m line of sight (no walls) max.
HDMI Compliance HDMI 1.3
-7- ENGLISH
HDCP Compliance HDCP 1.3
Audio Output PCM 2CH
Resolution 1920 x 1080 @60Hz
Pixel Frequency Range 25MHz~165MHz
Power Supply AC in 110-240V / DC out 5V/2A
Operating Humidity 10 - 80%
Operating Temperature 0 - 45ºC
Storage Temperature -20 - 60ºC
-8-
RECEIVER
-9- ENGLISH
TRANSMITTER
-10-
6. INSTALLATION
THE PURELINK CSW030 TRANSMITTER (TX)
1. )TUOIMDH(ecivedDHruoyotrettimsnart030WSCruoytcennoC
or laptop (HDMI OUT).
2. Connect the power adapter to the USB port on the CSW030 trans-
mitter and to a socket. If your HD device or Laptop has a USB port
you can also use the USB cable to power the CSW030 transmitter.
THE PURELINK CSW030 RECEIVER (RX)
1. Connect your HDTV or HD Projector (HDMI IN) via an HDMI cable
to the CSW030 Receiver (HDMI OUT)
2. Connect the power adapter to the USB IN on the CSW030 Recei-
ver and to an electrical socket
Note: You cannot connect both receiver outputs at the same time.
You must connect either[HDMI OUT] or [VGA OUT + AUDIO OUT]
