Puretec Z18 Bedienungsanleitung

AS/NZS 3497

Licence No. WM 74726

Australian Certication

Services

User Guide

Quick Twist Undersink Water Filter System

Z12 / Z18

For correct operation & installation it is essential to observe these instructions.JUNE2019

Puretec Customer Service

Thank you for purchasing a Puretec Quick Twist Undersink Water Filter System. Your system is

a proven performer manufactured from only quality materials and components and will give

years of ‘spring fresh’ water free of impurities if maintained properly.

The Puretec Z12 & Z18 system cartridges need replacing regularly to maintain optimum

performance. This is a simple procedure when following instructions. For cartridge

replacements contact your nearest Puretec stockist.

Customer Service Helpline 1300 140 140 (Australia) 0800 130 140 (New Zealand).

Caution: Do not use with water that is microbiologically unsafe or with water of unknown



What's Inside

Operation ............................................................................................................................................... 3

Cartridge Replacement................................................................................................................... 3

Installation Requirements and Procedure ........................................................................... 3

Cartridge Changeout ....................................................................................................................... 4

Use Guidelines .................................................................................................................................... 5

Z12 / Z18 Assembly......................................................................................................................... 6

Z12 / Z18 Faucet Connections ................................................................................................... 7

Z12 / Z18 Battery Installation........................................................................................................7

Z12 / Z18 Performance Data...................................................................................................... 8

Warranty.......................................................................................................................................................9

What's Inside

This product contains a button battery. Accidental ingestion may

occur and can be fatal. Please keep out of reach from infants. If you

suspect an accidental ingestion please contact emergency services.

Quick Twist Undersink Water Filter System with LED Faucet

Operation

The Puretec Z12 & Z18 systems are designed to run economically for many years dependent

on the initial installation and periodical maintenance.





Cartridge Replacement



months (dependent on water quality and usage).



the battery from the rubber seat. Please refer to page 6 for a detailed diagram.

Order Z1-R for a replacement cartridge to suit your Z12 or Z18 system.

Installation

This system comes complete with an installation kit enabling it to be connected to 15

mm (½”) male thread. This product must be installed in accordance with local plumbing

regulations by a licensed plumber.

Installation requirements

 

 

 

4 Suitable location for faucet.

 

(½”) copper pipe. No electrical or drainage requirements needed.

Installation Procedure

 





2. Isolate water supply. Uninstall the connections on the cold water line and connect the

Smart Tee™. Reinstall the previous connection to the tee valve.

3. Connect the pressure limiting MultiValve to the Smart Tee™ with a length of White

Tubing.

 



as in the instructions for your model in step 5.

5. To install the faucet follow the instructions for your model below.

Z18 Faucet





supplied onto the base of the tap. Insert into the Counter Top or Sink and place the



the tap is in the correct position on the bench. Then place the Olive in the 1/4"



and attach to the tap thread.

Z12 Faucet







1/4" Tube and the Olive Insert into the end of the Tube and attach to the tap thread.

 

 







 

in the tubing.

9. Restore the water supply and check for leaks.

 



Installation

Quick Twist Undersink Water Filter System with LED Faucet

Installation Guide

Cartridge Installation/Changeout

 

 

applicable).

Replacement cartridge Z1-R

 

 

 

discontinue use and call your supporting dealer.

 

Use Guidelines

• Minimum operating pressure 200 kPa.

 

 

 

 

• This system must be installed according to local plumbing codes on the cold water line



• Replacement Cartridge: Z1-R

 



replacement frequency.

 





Caution: Do not use with water that is microbiologically unsafe or of unknown quality



Z12 / Z18 Assembly

1. Cut the tube square and push in to

the tube stop. For metal tube remove

burrs and chamfer tube end to prevent





 

 

tube is pushed in to tube stop.



3. Tube is secured in position.

Figure 2

Figure 1

No. 

1Smart Tee™



2 White Tubing

3 MultiValve

4 Filter Cartridge

5 Mounting Bracket

6

7 Tube Insert

8

Washer

9 Black Plastic Washer

10 Black Rubber Washer

11 

12 



Quick Twist Undersink Water Filter System with LED Faucet

Z12 / Z18 Faucet Connections

Figure 3

Faucet Display Battery Seat

Circuit Board

Battery

(CR2032)

Chrome Plated Metal Flange

ø12.5 Hole

Counter Top

Cone Washer/Olive



Plastic Washer





Gasket





BATTERY INSTALLATION - LED REMINDER LIGHT

1. Remove the black battery seat from the

faucet lever handle (see Figure 3).

 

positive side up.



twice and then followed

by the blue light.

3. Reinstall battery

seat assembly

into the faucet

lever.

Important note: Battery must be replaced when changing cartridges.

 

are due to be changed (usage has



Please change the battery when

changing the cartridges.

Positive

side up

Negative on

the PCB

 

Note: Filter faucet may vary

depending on system purchased.

Z12 / Z18 Performance Data

Performance Data

Substance Guidelines*

Average



Concentration



Concentration

Min Percent

Removal

Average



Concentration

Average

Percent

Removal

NSF Standard 42 Drinking Water Treatment Units

Chlorine





 2.1 0.3 50% 0.25 >94%

Standard 53 Cyst Live Cryptosporidium POU/POE

Cyst <1  ND (1) 99.98% + ND (1) 99.99%

Test Parameters

 120

 290

Temp deg C 21°C

Turbidity NTU 0.1

pH 7.57 

ND = Not Detected

This appliance meets the domestic water treatment appliance Standards AS/NZS3497 for the following

water treatment processes:

Class Treatment type Function Pass

IMicrobiological Status

Bacteriostatic 

remove them unless II(a) is passed

N/A

II Microbiological Treatment

II (a) Bacteria Removal Will remove or inactivate bacteria N/A

II (b) Virus Removal Will remove or inactivate virus N/A

II (c)  Will remove or inactivate Cryptosporidium



inactivate bacteria and virises unless II(a)

and II(b) is passed



III Turbidity & Particulate Reduction Reduces cloudiness 

IV Taste & Odour Reduction Reduces taste & odours 

V Chemical Treatment Decreases chlorine 

Notes



the name you can trust for viable and proven water solutions. The complete range of Puretec



worldwide market.







appliance it is essential to observe manufacturer’s instructions.

Warranty

Any claim under this warranty must be made within 10 years of the date of purchase of the

product. This product is warranted to be free of defect of material and workmanship for 10

years from date of purchase. 10 year warranty is 1 year parts and lanour plus 9 years parts











The warranty only applies if the product was used and/or installed in accordance with the



or implied warranties and manufacturer shall in no circumstance be held liable for damages



law.







Warranty

Warranty/Australia





This warranty is provided in addition to other rights and remedies you have under law: Our





reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or

replaced if the goods fail to be of acceptable quality and the failure does not amount to a



Warranty/New Zealand





This warranty is provided in addition to other rights and remedies you have under law: Our



reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or

replaced if the goods fail to be of acceptable quality and the failure does not amount to a



Warranty
