PURGE SOLUTIONS CYCLOPS Z Bedienungsanleitung

CYCLOPS

Z – Purge Indicator

IOM Manual

This page intentionally left blank

Information in this document is subject to change without notice. All terms mentioned in

this manual that are known to be trademarks have been appropriately capitalized. Purge

Solutions, Inc. acknowledges all trademark(s) and the rights of the trademark(s) owned by

the company referred to herein.

592 Avenue E 1/2, Alvin, Texas 77511 USA

Phone: 832-368-7166

Fax: 281-824-4418

E-mail: [email protected]

Web site: http://www.purgesolutions.com

Release Date: 12-August-2002

Document Number: DO-10011-X

Revision Record

Rev. Description Date

A Initial Release 12-Aug-02

B Web Site Changes 02-Jan-03

C Add 12 DC Powered Model 23-Mar-03

D Several Revisions 07-Dec-03

E Several Revisions 14-Mar-04

F Several Revisions 29-June-04

G Several Revisions 14-Dec-04

H Several Revisions 27-May-05

I Added Recommended UL Power Supply Requirements 06-Jan-06

J Revised Options and Illustrations 01-Mar-06

K Revised Initial and Maintenance Start Up Procedures 13-Jan-07

L Revised Illustrations 24-Jan-08

M Revisions Per Certification Updates and New Product Offerings 23-Aug-08

N Revisions Per New Purge Gas Inlet Kits Procedures 21-Aug-09

O Several Revisions 11-Nov-09

P Addition of Dust and Amended Installation Instructions 18-Nov-10

Q Removal of CYCLOPS Y – Purge Indicator from this manual 13-Jun-11

R Addition of Increase Safety Window Kits and UL Certification 17-Jun-13

S Address and Certification Changes 25-Nov-13

T Certification Required Revisions 18-Sep-14

U Added Storage Temperature Range 21-May-15

V Change of Address 27-May-16

W Several Revisions 23-Mar-18

X Several Updates 25-Nov-19

This document contains information proprietary to Purge Solutions, Inc. with all rights

reserved worldwide. Any reproduction or disclosure of this publication, or any part thereof,

to persons other than Purge Solutions, Inc. personnel or customers is strictly prohibited,

except by written permission of Purge Solutions, Inc. Unauthorized use, disclosure,

reproduction, or translation of this publication will result in Purge Solutions, Inc. exercising

maximum possible legal action against all persons and/or organizations involved.

Disclaimer:

Purge Solutions, Inc. makes every effort to ensure the accuracy and completeness of this

manual. However, we cannot be responsible for errors, omissions, or any loss of data as

the results of errors or omissions. We therefore make no representations or warranties

with respect to the contents hereof. Further, Purge Solutions, Inc. reserves the right to

revise this publication and to make changes in the content hereof, without obligation to

notify any person or organization of such revision or changes.

Shipment Arrival Procedures:

This shipment has been thoroughly inspected at the factory prior to its delivery to the

carrier. After the shipment is picked up by the carrier, it becomes their responsibility.

When the shipment arrives, make certain that it is undamaged and complete.

Patent Notice:

Manufactured under United States, Worldwide Patents, and Patents Pending.

Trademark Information:

Purge Solutions, Inc. and its logo(s) are trademark(s) of Purge Solutions, Inc.

Table of Contents

Legal Notices and Revision History Inside

front cover

Section 1

How To Use This Manual 1

Safety Considerations 1

Label Definition Table 2

Locating Information 2

General Safety 2

General Precautions 3

Electrical Power 4

System Location 4

Conditions of Safe Use 5

Section 2

Specifications 6

Features Table 6

Normal Operating

Conditions Table 6

Utility Requirements

Table 7

Environmental

Conditions Table 7

Model Number Matrix 8

Section 3

Introduction 9

Description 9

Warranty 12

Section 4

Installation 13

Indicator Installation

Procedure 13

Protective Gas Inlet Kit

Installation Procedure 24

Back-Up Exhaust Vent

Installation Procedure 29

Section 5

Start Up Procedures 36

Continuous Dilution

Explosive Gas

Applications 37

Continuous Dilution

Combustible Dust

Applications 40

Leakage Compensation

Explosive Gas

Applications 42

Section 6

Maintenance Procedures 46

Continuous Dilution

Explosive Gas

Applications 46

Continuous Dilution

Combustible Dust

Applications 48

Leakage Compensation

Explosive Gas

Applications 50

Section 7

Options 53

Section 8

Getting Help 55

Section 1

How to Use This IOM Manual

Safety Considerations:

This chapter includes important information that must be read and understood by all

persons installing, using, or maintaining this equipment. While this IOM Manual is

designed to aid personnel in the correct and safe installation, operation, and

maintenance of the systems described. Personnel must consider all actions and

procedures for potential hazards or conditions that may not have been anticipated in the

written procedures. If a procedure cannot be performed safely, it must not be

performed until appropriate actions can be taken to ensure the safety of personnel and

equipment. The procedures in this IOM Manual are not designed to replace or

supersede required or common sense safety practices. All safety warnings listed in any

documents applicable to equipment and parts used in or with the system described in

this IOM Manual must be read and heeded before commencing work on any part of the

system.

NOTE: Refer to all ATEX, CEC, IECEx, NEC and NFPA certificates for

any Special Conditions of Use. If the sign “X” is placed after the

certificate number, it indicates that the equipment or protective

system is subject to special conditions for safe use specified in the

schedule of the certificate.

NOTE: Review all material and safety information in this IOM Manual

and install in accordance with this document and all other applicable

ATEX, CEC, IECEx, NEC and NFPA standards.

WARNING: Failure to follow appropriate safety procedures or

inappropriate use of the equipment described in this manual can lead

to injury of personnel or equipment damage.

WARNING – EXPLOSION HAZARD – Do not disconnect

equipment unless power has been removed or the area is known to be

non-hazardous.

The following symbols are used throughout this IOM Manual to alert users to potential

hazards or important information. Failure to heed the warnings and cautions listed

herein can lead to injury and equipment damage.

Document Label Definitions Used to

Indicate Potential Hazards

Symbol Label Description

WARNING:

Consists of conditions, practices or procedures

that must be observed to prevent personal injury

and / or equipment damage.

CAUTION:

Risk of electric shock or high temperature parts

may result in injury if proper precautions are not

taken.

NOTE: Emphasizes important or essential information.

Locating Information:

NOTE: In the interest of completeness, manuals and drawings included

with the system may provide information pertaining to options not

included with your equipment. Information in application notes

supersedes general information in these documents. Information can be

located in this manual using any of the following aids.

1. Table of Contents

2. Getting Help

General Safety and Operating Information:

This section contains general safety and operating information applicable to electrical

equipment installed within hazardous locations. This information must be understood by

all persons installing, using, or maintaining the electrical equipment. This information is

designed to aid personnel in safe installation, operation, and maintenance of the Type Z

– Purge System. It is not designed to replace or limit appropriate safety measures

applicable to work performed by personnel. Any additional safety and operating

measures that are required must be determined by and followed by personnel

performing work on the electrical equipment.

WARNING: Deviation from the specified instruction or procedure

steps can result in injury to personnel, equipment malfunction and /

or equipment damage.

WARNING: Return unit to factory for any repairs or replacement of

parts, customer not permitted. This will void all warranties and

hazardous area certification(s).

General Precautions:

Protective eyewear (glasses with side shields or goggles as appropriate)must be

worn when servicing any part of electrical equipment. Hot components should be

allowed to cool before servicing if possible. Other appropriate equipment or clothing

must be used as required by the type of work performed. All applicable regulations and

procedures must be followed for the work performed. Before beginning any work on

the equipment, carefully consider all the potential hazards and ensure that appropriate

measures are taken to prevent injury to personnel or equipment damage.

CAUTION: Applicable permits must be obtained and appropriate

precautions must be taken to prevent possible injury to personnel or

equipment dama

e when installin

or maintainin

this equipment.

Enclosure shall be marked by the end user identifying enclosure as pressurized. The

pressurized enclosure shall be marked the following or similar.

WARNING: PRESSURIZED ENCLOSURE.

To prevent the ignition of an explosive gas atmosphere or a combustible dust

atmosphere, which may be present when an enclosure is opened, doors and covers

shall be marked the following or similar.

WARNING: DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS

PRESENT.

Instructions shall be marked on the equipment by the end user to insure proper purging

the pressurized enclosure before energizing the electrical equipment. The instructions

shall include the following or similar.

WARNING: POWER SHALL NOT BE RESTORED AFTER

ENCLOSURE HAS BEEN OPENED UNTIL ENCLOSURE HAS BEEN

PURGED FOR ___ MINUTE

AT A MINIMUM FLOW RATE OF

For applications located in a Combustible Dust Atmosphere; a warning shall be marked

on the equipment stating that combustible dust shall be removed from the interior prior

to switching on the electrical supply. The marking shall include the following or similar:

WARNING: POWER SHALL NOT BE RESTORED AFTER THE

ENCLOSURE HAS BEEN OPENED UNTIL COMBUSTIBLE DUST

ACCUMULATIONS WITHIN THE ENCLOSURE HAVE BEEN REMOVED.

Electrical equipment mounted inside pressurized enclosure may have hot surfaces that

exceed the ignition temperature of the flammable or combustible substance located in

the hazardous location; even when power has been removed. Take appropriate

precautions to prevent injury from contact with hot items or damage to equipment and to

allow for adequate cooling; the equipment shall be marked with instructions that include

the following or similar.

WARNING: DO NOT OPEN ENCLOSURE DOOR OR COVER FOR

____ MINUTES AFTER REMOVING POWER.

Electrical Power:

The CYCLOPS Z – Purge Indicator uses AC power of 115 or 230 volts and DC power of

12 or 24. The AC power is converted to DC. Appropriate precautions must be taken to

prevent sparks that may ignite combustible materials that may be present in the Purge

Indicator’s environment. Precautions must also be taken to prevent electrical shock if

the electrical equipment’s enclosure being monitored by the CYCLOPS Z – Purge

Indicator is opened. The power to the CYCLOPS Z – Purge Indicator must be free from

noise, surges, sags, and spikes for proper operation of the purge indicator. AC power

circuit breakers and wiring must be sized properly for the required current. All wiring

installations must meet applicable electrical codes.

WARNING: Do not connect of disconnect CYCLOPS Z – Purge

Indicator when energized.

System Location:

The CYCLOPS Z – Purge Indicator must not be installed in an area classification for

which it is not rated and must be protected from temperature extremes and potentially

high vibration. The CYCLOPS Z – Purge Indicator must be attached securely and

appropriately to the wall of the electrical equipment’s enclosure being monitored per the

mounting instructions page 13 and mounted in a location to permit adequate viewing of

green indicator light and to permit proper purge exhaust venting.

Andere Handbücher für CYCLOPS Z

Inhaltsverzeichnis

Andere PURGE SOLUTIONS Messgerät Handbücher

PURGE SOLUTIONS

PURGE SOLUTIONS CYCLOPS Z Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
