PUTCO Molle Panels Handbuch

`DESCRIPTION QTY

Molle Front Plate 1

Molle Side Plates 2

Side Brackets 2

Front Brackets 3

M6 Torx-Head Bolts 10

8-32 Philip’s-Head Screws 3

5/16 Well Nuts 3

Congratulations on your purchase of a high quality PUTCO®product. Should

you need any application or technical assistance, feel free to call us at:

Monday-Friday 8:00am - 5:00pm (Central Standard Time)

Contact your PUTCO®dealer for other quality accessories.

1953XXI

1-800-247-3974

PLEASE READ ALL INSTRUCTIONS BEFORE INSTALLATION

AND CHECK TO SEE THAT ALL PARTS ARE INCLUDED

CONTENT LIST

T30 TORX DRIVERT40 TORX DRIVER

REQUIRED TOOLS

INSTRUCTION GUIDE

TOYOTA TACOMA

PHILLIPS SCREWDRIVER

MOLLE Panels Instruction Guide

1

2

Unscrew and remove both in-bed rails using a T30 Torx driver.

Using a T40 Torx driver, unscrew and remove the two tie-down hooks located towards the front

of the bed. Place the supplied side brackets behind the tie-down hooks, then fasten to the bed

re-using factory hardware.

Front bracket locations circled in red

INSTALLATION INSTRUCTIONS

1953XXI

3

4

Loosely assemble a well nut and Philip’s-head screw onto each of the three front brackets. Insert

the well nuts down into each of the three drain holes located towards the front of the bed ﬂoor,

then tighten the screw until the well nut is snug in the hole, but do not overtighten

Remove and set aside the two T30 Torx-head fasteners from the passenger-side bed cubby

shown below. The passenger-side molle plate will mount to this location re-using these fasteners.

MOLLE Panels Instruction Guide

7Fasten the molle plates to their brackets using the supplied M6 bolts and a T30 Torx driver.

8Once all the plates are installed in the vehicle, ensure all fasteners are tightened until snug, but

do not overtighten.

1953XXI

5

6

Place the side plates on the backside of the in-bed rails, then fasten to the bed re-using the

factory hardware.

Unscrew and remove the three required T30 Torx-head fasteners from the upper part of the bed

front, then set the front molle plate in place, and attach to the bed re-using these three fasteners.

Your new MOLLE Panels are now successfully

installed on your vehicle!
