Pyle PPHP1249KT Bedienungsanleitung

www.PyleUSA.com

WARNING!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE THE COVER OF THIS UNIT.

THERE ARE NO USER - SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO A QUALIFIED TECHNICIAN.

The lighting ash with arrow head symbol within an equilateral triangle is intended

to alert the user to the presence of “dangerous”voltage within the product’s enclosure

that may be of sucient magnitude to constitute a risk of Electric shock to humans.

Users should exhibit extra safety when this symbol appears in this instruction manual

and follow all precautions as they are stated.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) in structions in

this manual.

SAFETY INSTRUCTION

1. Please read the user manual carefully before use and retain for future reference.

2. The power supply must match the demand of the device with reliable ground

wire.

3. All covering signal should be complied with the demand of device.

4. The device should be located far away from high temperature, moisture and

powerful electromagnetic eld.

5. Max operating temperature is 113°F.

6. No naked ame sources, such as lighted candles, shall be placed on the product.

7. Clean only with dry cloth – The appliance should be cleaned only as

recommended by the manufacturer.

8. When not in use, unplug the unit from the mains.

9. To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and

without distortion.

10. Only use suitable means of transportation if you want to move the speaker.

Note:

• Once the WIRELESS BT devices are paired, there is no need to pair them again.

• If the speaker is connected via BT device but does not play with sound, please

turn of nearby devices and only leave one device to re-connect with the speaker.

• When inserting the USB/SD Card , make sure the direction you selected is correct.

Never insert violently to avoid damaging the USB/SD Card or the unit. If it doesn't

work, please check if the direction is correct.

• Turn oﬀ and pull out the USB/SD before turning oﬀ the speaker.

www.PyleUSA.com

CONTROLS AND CONNECTIONS

1. SD card input

2. USB input

3. LCD screen

4. MP3 control

MODE: USB/SD/BT/FM convertor

: Play/Pause

: Repeat one/Repeat all/Random

FOL (FOLDER): Press and hold for 5 seconds to enter the folder option function

mode (press the previous/next songs button to choose the folder)

: Previous song, Press and hold for 2 second to decrease the volume, Press and

hold the volume goes down to zero

: Next song, Press and hold for 2 second to increase the volume, Press and

hold the volume goes up to 25

5. Volume control

6. Bass control for low frequencies

7. Treble control for high frequencies

8. Echo control

9. Mic input level control

10. 6.35 microphone 1 input

11. 6.35 microphone 2 input

12. Mic/Line switch

13. XLR line input

14. RCA Phone (R+L) line input

15. 6.35mm line output

16. Power LED indicator

17. Speaker out 8 ohm

18. MP3/Line switch

19. Fused IEC mains inlet

20. Main power switch

21. 110V/220V switch

www.PyleUSA.com

1. MODE: USB/SD/BT/FM CONVERTER

2. :when USB/SD: Previous Song,

Press and hold for fast rewind

when FM: Swich to backward

3. VOL+ : Increase volume

4. VOL- : Decresse volume

5. : when USB/SD: next Song,

Press and hold for fast forward

when FM: swich to next channel

6. : Stop. Switch the MP3 player oﬀ.

7. /SCAN: Play/Pause

When FM: Auto search

8. EQ: NORMAL, ROCK, POP, CLASS, JAZZ.

9. REP: Short press: Random/Single/Order

10. 0-9: Choosing music by numbers

11. MUTE: Mute the sound of the MP3 player

Wireless BT Connectivity:

• Instantly Stream Music from Your Wireless BT Devices

• Works with All Your Favorite Wireless BT Devices

(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)

• Wireless BT Version: 4.0

• Wireless Range: 100'+ Feet

• Wireless BT Network Name: 'Pyle'

Speaker Stands:

• Eﬀectively Elevates Speakers for Optimum Sound Performance

• Universal Speaker Compatibility (35mm Insert)

• Easy Setup and Quick Adjustment Control

• Reinforced Steel Support Construction

• Speaker Support Arm Extension

• Rugged and Reliable

• Safety Lock-in Pin

• Foldable for Quick Storage and Transport

• Rubber Capped Tripod Feet Base

• Perfect for On-Stage or Studio Use

• For Professional or Beginner Applications

• Speaker Height Adjustable: 59.1'' to 82.7'' -inches

• MAX. Load Capacity: 100 lbs. (50 kgs.) -Each

www.PyleUSA.com

Features:

• Dual 12-inch High-Powered Loudspeaker PA Systems

• Includes (1) Active Speaker, (1) Passive Speaker + (2) Stands

• Rugged, Durable & Reliable Sound

• Wireless BT Music Streaming Ability

• High-Frequency 1.0'' Tweeters

• Compression Driver with Titanium Diaphragm

• 2-Way Full Range Audio Projection

• Built-in Digital Audio Amplier

• XLR Microphone Input

• 1/4’’ SpeakOn (8 Ohm) Input

• 1/4’’ SpeakOn (8 Ohm) Speaker Output

• RCA (L/R) Audio Connector Jacks

• Connect & Stream Audio from External Devices

• USB Flash Drive & SD Memory Card Readers

• Digital LCD Display

• Rear Panel Rotary Dial & Button Control Center

• Master Volume, Mic Volume, Treble, Bass Adjustable

• Integrated Carry Handles

• 35mm Speaker Stand Mount Compatible

• Heavy Duty Engineered ABS Housing

Technical Specs:

• MAX Power Output: 1800 Watt

• Amplier: Class D

• Impedance: 8 Ohm

• T.H.D.: <1%

• Magnet: 40 oz.

• Sensitivity: 96dB (+/-2dB)

• Mic Input Level: <15mV

• Line Input/Output Level: >250mV

• Frequency Response: 50-18kHz

• Digital Audio File Compatibility: MP3, WMA

• Maximum SD/USB Flash Memory Support: 32GB

• Power: 120/240V

• Power Cable Length: 4.9 ft.

• Stand Adjustment Height: 24’’ x 47’’ -inches

• Speaker Dimension (L x W x H): 34'' x 31'' x 57.5'' -inches

What's in the Box:

• (1) 12'' Active PA Speaker

• (1) 12'' Passive PA Speaker

• (2) Speaker Stands

• Wired Microphone

• Remote Control

• Power Cable

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]om
