Pyle PPHP2836B Bedienungsanleitung

Dual8’’WirelessBTPortablePASpeaker

PPHP2836B

Portable PA& Karaoke PartyAudio Speaker

with Built-in Rechargeable Battery, Flashing Party Lights,

MP3/USB/FM Radio (600 Watt MAX)

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]

WARNING

Illegal operation may cause personal injury, which could be fatal and may cause

damage to property.

1. DO NOT place objects on top of the device, as objects may

scratch the device.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical eld.

5. DO NOT use the device in the rain

6. Please check with your Local Authority or retailer for proper

disposaI of electronic products.

7. DO NOT disassemble the device. Only a certied service

technician should perform repair.

8. The device has apertures to disperse heat. DO NOT block the

device ventilation, the device may become hot and malfunction

as a result.

FRONT PANEL FUNCTIONS

1. Master volume control

2. Charge LED indicator

3. DC 5V input jack

4. Short press to choose input signal, press and hold to turn ON/OFF light

5. Next/select saved radio station.

6. Play/Pause/TWS function/In FM mode, press and hold to search radio station

automatically and save.

7. Previous/select saved radio station

8. AUX input jack

9. USB input jack

10. Microphone input jack

11. Display screen

www.PyleUSA.com2www.PyleUSA.com 3

12345678910

www.PyleUSA.com4www.PyleUSA.com 5

REMOTE CONTROL FUNCTIONS

1. Power: Used to turn on and o

the MP3 player power

2. MODE: Used to switch the AUX/

USB/Wireless BT/Radio

3. Mute button

4. Play/Pause/Press and hold for TWS/

In FM mode, press and hold to search

radio station automatically and save

5. Next song/In FM mode, short press to

select saved radio station

6. Previous song /In FM mode, short press

to select saved radio station

TWS FUNCTION

For increase sound eect, our unit provides TWS function as follows:

Step-1: Turn ON BT mode on your device and connect the machine.

Step-2: Press and hold each control board“TWS” button more than 3's, and you will

see "ON" on display, unit will start to connect the other unit automatically,

now you can enjoy stereo sound, and adjusting one unit volume will aect

the other unit.

Remark:

1. After connection, press and hold again one of control board "TWS" button more

than 3's, you will see "OFF" on display, unit's TWS disconnection.

TROUBLESHOOTING

7. EQ solution

8. Increase volume

9. Choose song number directly/

In FM mode, choose FM Frequency

directly

10. Choose USB or SD signal directly

(Only suitable for models with USB

& SD both)

11. Decrease volume

12. Repeat song

1. The audio format in the U disc

is incorrect.

2. Improper operation has caused

a process disorder.

3. USB disc is disconnected.

1. Convert audio format into Mp3

format.

2. Reboot the machine.

3. Insert USB disc properly.

MP3

does not

play

Fault Possible Cause Solution

No sound

Distortion

of sound

Karaoke

does not

work

1. No input sound source.

2. Volume is too low.

1. Volume too high.

2. Speaker may be damaged

1. Microphone plug is not fully

inserted.

2. Microphone switch is not on.

3. Microphone volume knob is at

the lowest position.

1. Use a better music signal.

2. Adjust volume.

1. Turn down the volume.

2. If speaker is damaged, repair

or replace it.

1. Plug microphone properly into

the socket.

2. Turn on microphone switch.

3. Adjust microphone volume

properly.

www.PyleUSA.com6www.PyleUSA.com 7

Features:

• True Wireless Stereo System

• Portable Speaker System

• High-Powered PA Loudspeaker Style

• Wireless BT Music Streaming Ability

• Multi-Color Flashing LED Party Lights

• Built-in Rechargeable Battery

• FM Radio with Digital LED Display

• Connect & Stream Audio from External Devices

• Aux (3.5mm) Input Connector Jack

• USB Flash Memory Reader

• 6.5mm Microphone input

• Battery Level LED Indicator Lights

• Rugged & Durable Molded Cabinet Design

• Convenient Extendable Carry Handle

• For Indoor / Outdoor Use

Wireless BT Streaming:

• Built-in BT for Wireless Music Streaming

• Simple & Hassle-Free Pairing

• Works with All of Today’s Latest Devices

• Smartphones, Tablets, Laptops, Computers, etc.

• Wireless BT Version: 4.2

• Wireless BT Network Name: ‘PYLEUSA’

• Wireless Range: Up to 32’ ft.

What's in the Box:

• PA Speaker System

• Remote Control

• Power Adapter

Technical Specs:

• Material: Polypropylene (PP)

• Max Power Output: 600 Watt Max

• Sound System: 8’’ -inch Subwoofer x 2 + 1"Tweeter

• Impedance: 3.0 Ohm

• Frequency Response: 50Hz-12KHz

• USB Interface Type: 2.0

• Digital Audio File Support: MP3

• Maximum USB Flash Support: 32GB

• Remote Control Battery Operated, 1 Piece Button Cell Battery CR-2025

(Included)

• Battery Life: Up to 3 Hours (Charge Time: Approx. 4.5 Hours)

• Rechargeable Battery: Battery: 3.7V, 2400mAh – 8.88 Wh

• Power Supply: 120/240V, Switchable (5V/2A Power Adapter)

• Dimensions (L x W x H): 9.6’’ x 8.5’’ x 23.0’’ -inches

This product can expose you to a chemical or group of checmicals, which may include

“Lead and lead compounds” which is known in the state of California to cause cancer, birth

defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
