Python 4106P Bedienungsanleitung
Vista, CA 92081
www.directed.com
Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
OWNER’S GUIDE MODEL
4106P
©2012 Directed. All rights reserved.
The company behind Python®Auto Security
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
accessories available. The recipient of nearly 100 pat-
ents and Innovations Awards in the field of advanced
electronic technology. Quality Directed products are
sold and serviced throughout North America and around
the world.
Call (800) 876-0800 for more information about our
products and services.
Vista, CA 92081
www.directed.com
SECURITY FOR THE BEST®
QRG4106P 2012-08
Congratulations
Congratulations on the purchase of your state-of-the-art remote start
and keyless entry system. Reading this Owner’s Guide prior to using
your system will help maximize the use of your system and its many
features. For more information please visit
www.pythoncarsecurity.com – for general and additional guide infor-
mation. For any additional questions please contact your authorized
Directed dealer or contact Directed at 1-800-753-0600. (U.S. only)
Additional Guide Information
Only basic commands, features and essential information are covered
in this compact guide. Your product has many advanced features
which are not discussed here, please consult the expanded online
version for information about these features at
www.pythoncarsecurity.com.
Most sections in this guide also contain additional information which
can be found in the expanded online version.
What you get
Welcome to the best generation of keyless entry with remote start.
Your system contains everything you need.
• Two 1-way SuperCode remote controls, (p/n 7154P)
• Owner’s guide
• Warranty registration card
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Your Warranty
Your system comes with a warranty. Make sure you receive the war-
ranty registration card and proof of purchase from your dealer indicat-
ing the product was installed by an authorized Directed dealer. Please
validate it online at www.prodregister.com/directed or complete and
return the warranty registration card.
Contents
Remote Control Information.................................................................................. 2
Control Center..................................................................................... 3
Using your System............................................................................................... 4
Commanding the system....................................................................... 4
Performing Commands ......................................................................... 4
Remote Control Command table ............................................................ 5
Basic Commands................................................................................................. 6
Lock ................................................................................................... 6
Unlock................................................................................................ 6
Remote Start........................................................................................ 6
AUX/Trunk.......................................................................................... 6
Battery Information.............................................................................................. 7
Battery Disposal .................................................................................. 7
Government Regulations ...................................................................................... 8
Warning! Safety First........................................................................................... 9
Installation .......................................................................................... 9
Remote Start Capable .......................................................................... 9
Manual Transmission Vehicles ............................................................... 9
Interference....................................................................................... 11
Upgrades ......................................................................................... 11
Water/Heat Resistance ...................................................................... 11
Limited lifetime consumer warranty ..................................................................... 12
2© 2012 Directed. All rights reserved.
Remote Control Information
Antenna
Transmit LED
Command Buttons
Function Button
Feature Description
Internal Antenna Used for transmitting information.
Transmit LED Active when transmitting information.
Command buttons (4) Used to perform locking, unlocking, auxiliary channel and
remote start commands
Function button Used to access function levels for commands, configuration
menus for programming and Car Selection.
3
© 2012 Directed. All rights reserved.
Control Center
Valet switch
LED
Control button
Status LED
Control Center
Control Center
Control Center Valet switch
LED
Control button
Status LED
Control Center
Antenna
Antenna
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override **operation.
* See Remote and System Operations in the online guide.
** See System Features in the online guide.
4© 2012 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used keyless entry and remote start
features while Advanced commands control more specialized fea-
tures.
Confirmations for Basic commands are indicated by horn honks* and
parking light flashes. A description of feature confirmation is found
in the following Basic command section. See the online guide for
Advanced Commands.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
A U
X
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Lock
1. Press the
A U
X
button once to access Function Level 1, The trans-
mit LED single flashes for 3 seconds.
2. Press the
AUX
AUX
button while the transmit LED is still flashing to
perform the Silent Lock command.
3. The system will lock the doors and flash the parking lights,
without horn honks.*
* The optional Horn Honk feature must be connected.
5
© 2012 Directed. All rights reserved.
Remote Control Command table
Button
Level Direct Access
A U X
x 1
Level 1
A U X
x 2
Level 2
A U X
x 3
Level 3
A U X
x 4
level 4
A U X
Lock Silent Lock
A U X
Unlock Silent Unlock Valet Mode Car Finder
A U X
Remote Start Reset Runtime Timer Mode Smart Start Rear
Defogger
AUX Trunk Release* AUX 1 AUX 2 AUX 3 AUX 4
A U X
Function Shift
*This is an optional feature. See your authorized Directed dealer
for details.
6© 2012 Directed. All rights reserved.
Basic Commands
Lock
Press and release
AUX
AUX
Doors lock (if connected).
To Lock and Panic
Press and hold
AUX
AUX
To lock the system, then activate Panic. For Panic to work,the
optional horn honk feature must be connected. Press the
AUX
AUX
or
AUX
AUX
button to stop Panic output.
Unlock
Press and release
AUX
AUX
The doors unlock (if connected).
Remote Start
Press and release
AUX
AUX
Activates (or if On, deactivates) the remote starter. The engine turns
On, or the engine turns Off accordingly. If a Remote start configura-
tion issue prevents the engine from starting, the parking lights flash a
Remote Start fault report to identify the fault.
AUX/Trunk*
Press and hold
AUX
The Trunk opens (if connected) when this button is pressed for 2 sec-
onds.
*This is an optional feature. See your authorized Directed dealer
for details.
7
© 2012 Directed. All rights reserved.
Battery Information
The remote controls are powered by 1 coin cell battery (CR-2032)
that can be purchased at most retailers. When the battery begins to
weaken, the operating range will be reduced.
Battery Disposal
Directed cares about the environment. If you need to dis-
pose of the battery, please do so in accordance with your
municipal requirements for battery disposal or return to
Directed.
Patent Information
This product is covered by one or more of the following United States
patents:
Vehicle Security Patents
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Remote Start
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Other patents pending
