▪This item is consist with IEC42(0.75sq)Ⅹ2P wire 2000mm and
ciggy jack plug for vehicle.
▪Working light after connecting a ciggy jack plug to the ciggy
jack in your vehicle.
This item has a strong magnetic at the bottom to attach
anywhere which conduct magnetism. If you attach this on the
vehicle’s roof, it attached smoothly with a strong magnetic along
to vehicle’s body.
1) Warning!
Must turn off power supply and change bulb after 1 minute at
least.
▪Xenon lamp work with a high voltage, if you touch a
assembling board or lamp without power-off, you may receive
an electric shock.
2) Lens Removal
Remove lens by turning it counterclockwise. and make sure
related parts on the assembling board.
3) Change Lamp
▪Our company’s xenon lamp (1) is made as a connector type
lamp. If you pull out with a small strength, it can be separated
easily.
▪Please fit the lamp by checking a connector pin location (2) as
below picture.
S80SM Lamp removal Lamp fitting
S100SM ,S125SM Lamp removal Lamp fitting
4) Lens Assembling
Assemble the product in reverse order of separating.
▪If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem
on product operating. Make sure the using voltage does not
exceed +/-5% of the rated voltage.
▪If lens or body of the product is contaminated by chemicals such
as thinner, benzene, the product can be damaged, discolored
or deformed. Please be careful.
▪Do not give strong impact to the product. It can be a reason of
wire disconnection or short circuit.
▪Do not strongly pull the wire out from the product. It can cause a
disorder.
re-connecting Lamp
connector
Strobe working
irregularly.
Supplying Voltage
Lower than Rated
Voltage
Making Sure Using
Voltage
