Installing The New PSD
1. Disconnect the power
cable from the wall outlet.
This will turn off the IM | IS
280 iMeter™ postage
meter.
7. Remove the new PSD and prepaid shipping label
from the shipping package.
Place the old PSD into the same shipping package.
Seal the package with packing tape (not provided).
Apply the prepaid label to the package over the old
shipping label.
2. Disconnect the power
adapter from the IM | IS-
280 iMeter™ postage
meter. Put the power
adapter aside; it will be
connected to the new
base.
8. Install the new PSD by
sliding it in and then down.
Close the PSD cover. If the
PSD cover does not close
properly, the PSD is not
installed correctly.
3. Remove the scale from the
system. Set it on the side
in an upright position.
Ensure that no weight or
pressure is placed on the
scale platform.
9. Turn the IM | IS-280
iMeter™ postage meter
back to an upright position.
4. Remove the scale’s cable
from the scale compartment. 10. Tuck the scale’s cable into
the scale compartment.
5. Place the IM | IS-280
iMeter™ postage meter onto
its back to access the PSD
(meter) cover. Open the
PSD cover by pushing down
on the tab.
11. Place the scale onto the
system aligning the scale’s
feet with the indentations
on the base.
6. Remove the old PSD by
sliding it up and then out. 12. Connect the power adapter
to the back of the IM | IS-
280 iMeter™ postage
meter.
Swapping The PSD
1. Connect the power cable to
the wall outlet. This will
turn on the IM | IS 280
iMeter™ postage meter.
2. The screen will display
“Start in progress…”
