Qualcast QSPP51 Bedienungsanleitung

51cm 150cc Push

Petrol Rotary Lawn Mower 484346

Instruction Manual

IMPORTANT! Please read these instructions fully before starting assembly.

These instructions contain important information that will help you get the best

from your product, ensuring it is assembled correctly and safely. If you need help

or have damaged or missing parts, call the Customer Helpline on 01904 727 500.

October 2017

SPP51

Contents

General safety warnings 3

Intended use 8

Warning symbols 8

In the box 10

Assemble the lawn mower 11

Preparing to operate the lawn mower 14

Operation 16

Maintenance and storage 21

Troubleshooting 27

Technical data 28

Disposal 29

Getting help 29

Warranty 29

General Safety Warnings

Safety Warnings

WARNING! Read all safety warnings and

instructions.

Failure to follow the warnings and instructions may

result in electric shock, re and/or serious injury.

WARNING! Read all safety warnings and

instructions designated by the symbol.

Save all warnings and instructions for future

reference.

• Always ensure anyone intending to operate this

machine is fully conversant with the contents of this

instruction manual prior to assembling, maintaining or

operating the machine.

• Perform assembly operations as described in this

manual. Failure to observe this warning may lead to

serious injury, death, or damage to the machine.

• Always take care when removing the packaging, to

prevent damage to you or to the machine.

IMPORTANT! Before assembling the machine, check all

the parts indicated in the manual are in the box. Inspect

all the parts for signs of damage. Do not assemble the

machine if you observe any damaged components.

NOTE: This lawn mower complies with the Noise Emission

Directive 2000/14/EC.

General safety

• Keep this operating and maintenance manual in a safe

place for reference at a later date.

• Read the instructions carefully. Be familiar with the

controls and the proper use of the equipment.

• Never allow children or people unfamiliar with these

instructions to use the lawn mower. Local regulations

can restrict the age of the operator.

• Never mow while people, especially children or pets,

are nearby. Keep in mind that the operator or user is

responsible for accidents or hazards occurring to other

people or their property.

• This appliance is not intended for use by people

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning the use of the appliance by a

person responsible for their safety.

• Never touch a rotating blade.

Personal safety

• While mowing, always wear substantial footwear

and long trousers. Do not operate the equipment

when barefoot or wearing open-toed sandals.

• Thoroughly inspect the area where the equipment

is to be used and remove all objects which can be

thrown by the machine.

• Petrol is highly flammable; store fuel in containers

specifically designed for this purpose.

a) Refuel outdoors only and do not smoke while

refuelling.

b) Add fuel before starting the engine. Never remove

the cap of the fuel tank or add petrol while the engine is

running, or when the engine is hot.

c) If petrol is spilled, do not attempt to start the engine

but move the machine away from the area of spillage,

and avoid creating any source of ignition until petrol

vapours have dissipated.

d) Replace all fuel tank and container caps securely.

• Replace faulty silencers.

• Prior to use, visually inspect to see that the blade,

blade bolts and cutter assembly are not worn or

damaged. Replace worn or damaged blades and bolts

in sets, to preserve balance.

Operation safety

• Do not operate the engine in a confined space

where dangerous carbon monoxide fumes can

collect.

• Mow only in daylight or in good artificial light.

• Avoid operating the equipment on wet grass, where

feasible.

• Always be sure of your footing on slopes.

• Walk, never run.

• Mow across the face of a slope, never up and

down.

• Exercise extreme caution when changing direction

on slopes.

• Do not mow excessively steep slopes.

• Use extreme caution when reversing or pulling the

lawn mower towards you.

• Stop the blade if the lawn mower has to be tilted for

transportation when crossing surfaces other than

grass, and when transporting the lawn mower to

and from the area to be mowed.

• Never operate the lawn mower with defective

guards, or without safety devices, for example

deflectors and/or grass catchers, in place.

• Do not change the engine governor settings or over

speed the engine.

• Start the engine carefully according to the

instructions and with feet well away from the blade.

• Do not tilt the lawn mower when starting the

engine.

• Do not start the engine without the grass collector

in place.

• Do not put hands or feet near or under rotating

parts. Keep clear of the discharge opening at all times.

• Never pick up or carry a lawn mower while the

engine is running.

• Stop the engine and disconnect the spark plug

cable, making sure that all moving parts have come

to a complete stop:

a) Before clearing blockages or unclogging the chute.

b) Before checking, cleaning or working on the lawn

mower.

c) After striking a foreign object, inspect the lawn mower

for damage and make repairs before restarting and

operating the lawn mower.

d) If the lawn mower starts to vibrate abnormally, check

immediately.

• Stop the engine and disconnect the spark plug wire,

and make sure that all moving parts have come to a

complete stop before refuelling.

Maintenance and storage

• Keep all nuts, bolts and screws tight, to be sure the

equipment is in safe working condition.

• Never store the equipment with petrol in the tank inside

a building where fumes can reach an open ame or

spark.

• Allow the engine to cool before storing in any enclosure.

• To reduce the re hazard, keep the engine, silencer,

and petrol storage area free of grass, leaves, or

excessive grease.

• Check the grass collector frequently for wear or

deterioration.

• For safety, always replace worn or damaged parts.

• If the fuel tank has to be drained, this should be done

outdoors.

Intended Use

This mower is designed for domestic lawn mowing only. Use in any other way is considered

contrary to the intended use. Compliance with the operation, service and repair, as

specied in this handbook, also constitutes essential elements of the intended use.

Warning Symbols

Please read all of the safety and operating instructions carefully before using this

machine. Read the instruction manual before operating.

Keep bystanders away - especially children and pets.

Beware of sharp blades - remove the spark plug lead before maintenance.

No naked ames.

Appropriate ear, eye, and head protection (PPE) must be worn.

Add engine oil.

Only refuel with unleaded petrol.

Hot surfaces will burn the hands!

Warning! The lawn mower’s exhaust gas contains toxic substances. Do not run

the engine in closed or poorly-ventilated areas.

The blade continues to rotate for a period after the machine is switched off. Do

not touch the blade until all the machine components have stopped completely.

The product complies with the applicable European directives, and an evaluation

method of conformity for these directives was done.

Sound level data (98 dB), in accordance with Directive 2000/14/EC.

In The Box

Parts

A. Main mower deck (with handle attached)

B. Grass collection bag

C. Mulching plug

D. Side discharge chute

E. Cable clip

Tools

F. Spark plug wrench

A B C

DEF

You will also need:

- SAE 30 or 4-stroke oil - Unleaded fuel - Funnel

If there are any parts missing, please call the customer helpline on 01904 727 500.
