QUANTUM SMART-1

6000-L/6000-XL

APPLIANCES

REPLACING SAN CARDS

Check Point Copyright Notice

licensing restricting their use, copying, distribution, and decompilation. No part of this product or related

documentation may be reproduced in any form or by any means without prior written authorization of Check

Point. While every precaution has been taken in the preparation of this book, Check Point assumes no

responsibility for errors or omissions. This publication and features described herein are subject to change

without notice.

RESTRICTED RIGHTS LEGEND:

Use, duplication, or disclosure by the government is subject to restrictions as set forth in subparagraph (c)

(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR

52.227-19.

TRADEMARKS:

Refer to the Copyright page for a list of our trademarks.

Refer to the Third Party copyright notices for a list of relevant copyrights and third-party licenses.

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |3

Important Information

Latest Software

We recommend that you install the most recent software release to stay up-to-date with the

latest functional improvements, stability fixes, security enhancements and protection against

new and evolving attacks.

Certifications

For third party independent certification of Check Point products, see the Check Point

Certifications page.

Check Point Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN

Cards

For more about this release, see the home page.

Latest Version of this Document in English

Download the latest version of this document in PDF format.

Feedback

Check Point is engaged in a continuous effort to improve its documentation.

Please help us by sending your comments.

Revision History

Date Description

17 February 2022 Rebranding - New Check Point logo

28 February 2021 First release of this document

Table of Contents

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |4

Table of Contents

Safety Instructions

Hardware Components

Procedure

Preparing the Appliance

Replacing the Bracket on a SAN Card

Removing the Riser

Installing an Expansion SAN Card into the Riser

Removing an Expansion SAN Card from the Riser

Installing the Riser

Reassembling the Appliance

Replacing a Transceiver

Attaching Cables

Viewing LEDs on the SAN Card

Safety Instructions

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |5

Safety Instructions

nLift the appliance with assistance. To avoid injury, do not attempt to lift the appliance by yourself.

nOpening or removing the appliance cover, while the appliance is powered on may expose you to a

risk of electric shock.

nDo not operate the appliance without the cover for more than five minutes. Operating the appliance

without the cover can result in component damage.

nMany repairs may only be done by a certified service technician. Only perform troubleshooting and

simple repairs as authorized in your product documentation, or as directed by the technical support.

nWe recommend that you always use an antistatic mat and antistatic strap on your wrist, while working

on components inside the appliance.

nTo ensure proper operation and cooling, all bays in the appliance and cooling fans must be always

populated with a component or a blank.

For more information, see the

Enterprise Products Safety, Environmental, and Regulatory Information

booklet supplied in the original appliance shipping carton.

Best Practice - We recommend that only experienced personnel install or remove

hardware components. Installing or removing components incorrectly can permanently

damage the Security Appliance.

Important - Make sure that you are electromagnetically grounded when working with

hardware components of the appliance. ESD (electrostatic discharge) can damage the

appliance.

Hardware Components

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |6

Hardware Components

Item Description

1 Front panel

2 Riser 1

3 Rear panel

Procedure

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |7

Procedure

Use the relevant install or replace workflow for your appliance. For each step in the workflow, follow the

instructions as described in the subsequent sections of this guide.

To install a new expansion SAN card:

1. Prepare the appliance with a shut down, halt and disconnection of power.

2. If necessary, replace the short bracket on the new SAN card with the supplied larger bracket.

3. Install a new expansion SAN card into the riser.

Best Practice - We recommend that you populate the bottom-most slot first.

4. Reassemble the appliance.

5. Install a transceiver.

To replace an existing expansion SAN card:

1. Prepare the appliance with a shut down, halt and disconnection of power.

2. Remove the existing expansion SAN card from the riser.

3. If necessary, replace the short bracket on the new SAN card with the supplied larger bracket.

4. Install a new expansion SAN card into the riser.

5. Reassemble the appliance.

6. Install a transceiver.

Preparing the Appliance

To prepare the appliance:

1. Make sure to follow the

Safety Instructions

2. Shut down the appliance:

nIn Gaia Portal:

Go to Maintenance >Shut Down, and click Halt.

nIn Gaia Clish:

Run: halt

3. Open the retention strap that secures the power cables to the PSUs.

4. If AC PSUs are installed in the appliance:

Disconnect the power cables from the AC PSUs.

5. If DC PSUs are installed in the appliance:

Procedure

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |8

Disconnect the safety ground wires from the DC PSUs.

Disconnect the DC power connectors from the DC PSUs.

6. Remove the hook-and-loop straps that hold and secure the system cables, if they interfere with the

PSU removal.

7. Remove any other attached cables, if necessary.

8. Remove the appliance from the rack. See the

Installing the Quantum Smart-1 6000-L/6000-XL

Telescopic Rails

booklet for illustrated installation procedures.

9. Put the Electrostatic Discharge (ESD) grounding strap on your wrist and attach the other end to a

grounding point.

10. Remove the appliance cover:

a. Use a flat or a Phillips head screwdriver to rotate the latch release lock counter-clockwise to the

unlocked position.

b. Lift the latch.

c. Slide the cover back.

The tabs on the cover should disengage from the guide slots on the appliance.

d. Hold the cover on both sides and lift the cover away from the appliance.

Replacing the Bracket on a SAN Card

The Emulex LPe31002 Dual, 16GFC Host Bus Adapter SFP+ is shipped with a short and long bracket.

nIf the long bracket is attached to the SAN card, no replacement is necessary and you can continue to

install the card in the riser.

nIf the short bracket is attached to the SAN card, follow the instructions below to replace it with the long

bracket supplied in the carton.

Note - The optical transceivers on the SAN card are delicate.

nRemove and install the transceivers carefully.

nUse ESD (Electrostatic Discharge) precautions such as an antistatic floor mat and an antistatic wrist

strap.

Procedure

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |9

To remove the transceivers:

1. Pull the bail (handle) out and down to release the latch for a typical optical transceiver.

2. Pull the transceiver gently (without force).

3. The transceiver slides out easily after the latch releases.

4. Remove the second optical transceiver.

5. Store the transceivers in a safe place using ESD (Electrostatic Discharge) precautions such as

antistatic bags.

To remove the bracket:

1. Remove the mounting bracket screws from the top of the adapter.

2. Remove the bracket.

Procedure

Quantum Smart-1 6000-L/6000-XL Appliances Replacing SAN Cards |10

3. Align the new longer bracket tabs with the holes in the adapter.

Notes:

nBe careful not to push the bracket past the EMI (Electromagnetic Interference) compression

tabs of the SFP+ (Small Form-Factor Pluggable) transceiver cages.

nMake sure that the LEDs for the SAN card ports align properly with the holes in the bracket.

4. Reinstall the screws to attach the new bracket to the SAN card.

To reinstall the transceivers:

1. Slide the transceiver into the housing.

2. Gently engage the latch until it clicks.

3. Push the bail (handle) back into place.

Removing the Riser

Press the release latches, and lift the riser from the riser connector on the system board.
