Qviart LUNIX3 4K Bedienungsanleitung
Open-source Linux operation system
Fully compatible with Enigma2
Broadcom 12K DMIPS 1.7GHz Dual-Core ARM processor (BCM 7252S)
Dual DVB-S2 Full-Band Capture Front End (2 x FBC Tuner)
1 x Plug & Play Detachable Tuner (Dual DVB-C or DVB-T2/C Hybrid)
4GB eMMC Flash / 2GB DDR4 RAM
Downloadable Plug-ins supported
H.264/MPEG-4 AVC & H.265/HEVC Video Compliant
1 x smartcard reader
10/100/1000 Mbps Gigabit Ethernet Interface
Internal SATA3 for 2.5" HDD
1 x USB3.0 & 1 x USB2.0 PVR Ready ports
1 x HDMI2.0 Interface
1 x Common Interface
1 x Optical (SPDIF) for digital audio
Composite Video (CVBS)
PIP: Picture in Picture
3D
Output Resolution: 4K2K UHD, 1080p, 1080i, 720p, 576p, 576i & 3D Ready
Media Player: avi, mkv, wmv, VP9 etc.
Hardware Transcoder
Less than 1 second channel change
Extended EPG and recording reservation on EPG
Multi language OSD, Supports DVB Teletext & Subtitle
Fully automatic, Manual Channel Search
Timer & multi-event recording
Teletext & Subtitle support by OSD and VBI
DiSEqC 1.0, 1,1 ,1.2 and 1.3(USALS) compatible
under 0.5 Watt Stand-by power consumption option
FEATURES
ACCESSORIES
Please check the following contents are enclosed:
User’s Guide 2 x AAA Batteries
Power Supply
Remote Control
SATA Cable HDMI 2.0 Cable
F1 F2
Front Panel
Live Status OSD Status
1. Power
Switch between operation and standby modes
2. Volume +/-
To change volume level
To change parameter value
3. Channel +/-
To change current channel
To move cursor up/down
4. Menu
To enter or exit the Main Menu
5. Exit
Close and return to the previous menu and screen
Shows current program's stream information
6. OK
To open channel list To Select/Confirm an item
7. Info
Shows current program's stream information.
7. Info
Display current menu information and channel name etc
8. Display
(VFD)
Shows current program's stream information.
7. Info
Insert smart card with the golden chip facing up
9.
Smartcard reader
Shows current program's stream information.
7. Info
PCMCIA Slot for a CA module
11. CI Slot
To connect USB 2.0 storage for PVR, media files and S/W update
10. USB
89
1110
Rear Panel
1RF IN/OUT (Optional)
Hybrid tuner input/loop-through for DVB Dual-C or DVB-T2/C.
2LNB1 IN
1st Satellite FBC tuner input from the LNB on a dish antenna.
3LNB2 IN
2nd satellite FBC tuner input from the LNB on a dish antenna.
4Audio / Video Output
To connect TV using RCA cable.
5S/PDIF
To connect an appropriate optical cable for your HiFi system.
6HDMI
To connect HDMI 2.0 cable for your UHD (or FHD) TV.
7 USB 3.0
To connect to the USB external HDD or USB stick for PVR,
media files and S/W update.
8 RS232
RS232C serial data port.
9 ETHERNET
Gigabit LAN port via HTTP, FTP, NFS, Telnet and Samba.
10 External Power Supply
To connect the power supply(12V/5A).
11 Power Switch
To turn AC Power On/Off.
13 4 5 6 7 8 9
10 11
INSTALLATION
Hi-Fi System
HDMI 2.0
External HDD or USB Stick
Network
DVB Dual-C or T2 Lite Composite AV
DVB-S2
1. Please refer to the Safety Guide before powering on the device.
2. Connect your LUNIX3 4K to your system as below (not all devices included):
3. Turn ON the LUNIX3 4K.
4. After booting up, please follow the initial setup menu according to your TV and satellite system.
REMOTE CONTROL
POWER ( ): Switches between operation & standby modes.
MUTE ( ): Turns Audio OFF/ON.
HELP: Displays an operation guide of the LUNIX3 4K.
HOME: Instantly moves to the top of the menu.
LAN: Opens the manu for LAN configuration.
ZOOM: To zoom the screen in/out.
END: Instantly moves to the bottom of the menu.
PLUGINS: To call plugins list.
NUMERIC KEY (0~9): Control the numerical operation & change the Channel/Service number directly.
PREV (<): Return to the previous channel/service or move to the end of the Service/Play List.
NEXT (>): Go to the next channel/service or move to the beginning of the Service/Play List.
VOL. +/-: Increase/Decrease the volume.
EPG: Displays the Electronic Program Guide (EPG) information if provided.
INFO ( ): Displays the Electronic Program Guide (EPG) information if provided and further information.
CH. +/-: Quick move in menus. In viewing mode, you can operate CH+/- by pressing UP/DOWN buttons.
AUDIO: Select an audio track & sound mode.
TELETEXT: Switch between teletext & TV mode.
SUBTITLE: Displays subtitle language list.
TIMER: Start timer function.
MENU: Opens the Main Menu & selects sub-menu by navigation buttons.
EXIT: Close & return to the previous menu or screen.
Navigation Buttons: Navigates up/down/left/right in the menus. Up/down keys are used to open the channel list.
OK: Select a menu or confirms the selected operation. Also displays the channel list while watching a program.
SAT: Opens the channel list according to a satellite.
PROV: Opens the channel list by provider.
COLOUR BUTTONS: Activates certain menu functions. Usage instructions are shown in each OSD menu.
LIST: Opens the Recorded file list menu.
MEDIA: Opens the Media file list.
F1: Preserved button for certain function if any.
F2: Start PIP function if the model supports it.
PVR FUNCTIONS(Buttons in box): Control the PVR functions in PVR Mode.
TV: Switch to TV mode.
RADIO: Switch to Radio mode.
F1 F2
Please read the following safety instructions carefully before using the LUNIX3 4K.
The manufacturer takes no responsibility for incorrect handling of the LUNIX3 4K.
* For sufficient ventilation, leave enough space.
* If unused for a prolonged amount of time, turn the power OFF.
* Do not cover the LUNIX3 4K ventilation openings with items such as newspapers, tablecloths, curtains, etc.
* Do not expose the LUNIX3 4K to liquid, moisture, direct sunlight, extreme weather.
* Do not place open flame sources, such as candles, near or on the LUNIX3 4K.
* Do not place any containers with liquid, such as vases, on the LUNIX3 4K.
* Do not connect or modify cables while the LUNIX3 4K is connected to power.
* Do not remove the cover. Risk of electric shock!
* Do not touch the LUNIX3 4K with wet hands. Risk of electric shock!
* Do not put any metal items into the slots or ventilation openings.
* Please disconnect your LUNIX3 4K from the main power during thunder or heavy storms.
* Disconnect the main power cable if the power cord is damaged.
* Cleaning: Disconnect the main power cord before cleaning the cover. Use a slightly damp cloth without cleaning agents.
* Connect the LUNIX3 4K only to suitable sockets. Do not allow overloads to occur.
WARNING!
* Modifications and changes to the LUNIX3 4K leads to loss of warranty.
* Incorrect software installation leads to loss of warranty.
* This instruction might be modified without prior notice.
1. This product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from
the municipal waste stream via designated collection facilities.
3. The correct disposal of your old appliance will help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal of your old appliance,
please contact your city office, waste disposal service or the shop where you purchased the product.
SAFETY INSTRUCTIONS
DISPOSAL INSTRUCTIONS
