RAB Lightcloud Controller Mini Bedienungsanleitung

Welcome

LCCONTROL/MINI

Controller Mini

1 (844) LIGHTCLOUD

1 (844) 544-4825

[email protected]

WE’ RE HER E TO HELP:

1 (844) LIGHTCLOUD

170 Ludlow Avenue Northvale, NJ 07647

Custom manufactured in China

1 (844) 544-4825

[email protected]

Lightcloud is a commercial

wireless lighting control system.

It’s powerful and ﬂexible,

yet easy to use and install.

Learn more at lightcloud.com

FCC Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference

that may cause undesired operation.

Note: This device has been tested and found to comply with the limits for

Class A digital devices pursuant to Part 15A Subpart B, of the FCC rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential environment. This equipment generates, uses,

and can radiate radio frequency energy, and if not installed and used in

accordance with the instruction manual, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment oﬀ and on, the user is encouraged to

try and correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit diﬀerent from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

To comply with the FCC's RF exposure limits for general population /

uncontrolled exposure, this transmitter must be installed to provide a

separation distance of at least 20 cm from all persons and must not be

co-located or operating in conjunction with any other antenna or

transmitter.

CAUTION: Changes or modiﬁcations to this equipment not expressly

approved by RAB Lighting may void the user’s authority to operate

this equipment.

Hello

The Lightcloud Controller Mini

is a remotely controlled switch

and 0-10V dimming device.

Product Features

Wireless Control & Conﬁguration

Switching up to 4.2A

0-10V Dimming

Power Monitoring

Patent Pending

Contents

Lightcloud Controller

Instruction Manual

Wire Nuts

Lock Nut Gasket

x 3 x 3

POWER MEASUREMENT: The Lightcloud Controller is capable of

measuring the power usage of the attached circuit.

POWER LOS S DETECTI ON : If mains power to the Controller is lost,

the device will detect this and alert the Lightcloud application.

EMERGENCY DEFAULT: If communication is lost, the Controller may

optionally fall back to a speciﬁc state, such as turning the attached

circuit on.

Controller requires constant, unswitched power. Any wires not in use

must be capped o or otherwise insulated. This product should

only be installed by a qualied electrician and in compliance

with local and national electrical codes.

Speciﬁcations

PART NUMBER

LCCONTROL/MINI

INPUT

120V-277VAC, 60Hz

<0.8W (Standby and Active)

MAXIMUM SWITCHED LOAD RATINGS

For Control of Electronic Ballast (LED)

and Magnetic Ballast

Electronic/Tungsten: 4.2A @120VAC

Inductive/Resistive: 4.2A @120VAC, 1.8A @277VAC

OPERATING TEMPERATURE

-35ºC to +60ºC

OVERALL DIMENSIONS

1.6" diameter, 3.8" length

1/2" NPT Mount, Male

22AWG pigtails

18AWG pigtails

WIRELESS RANGE

Class 2

IP66 Rated

Indoor and Outdoor Rated

Wet and Damp Location

Plenum Rated

Line-of-Sight: 1000 feet

Obstructions: 100 feet

What You Need

Lightcloud Gateway

A Lightcloud installation requires at least

one Lightcloud Gateway to manage your devices.

1 (844) LIGHTCLOUD

or 1 (844) 544-4825

[email protected]

WE’RE HERE TO HELP:

1 (844) LIGHTCLOUD

or 1 (844) 544-4825

[email protected]

WE’RE HERE TO HELP:

Functionality

Conﬁguration

Operating Modes

To conﬁgure Lightcloud products, use the Web Application

(control.lightcloud.com) or call 1(844)LIGHTCLOUD.

CO NTROLLER: Provides switching and dimming for a single zone.

REPEATER: Extends the Lightcloud mesh network without controlling a load.

SENSOR (REQUIRES OPTIONAL SENSOR MODULE): Provides occupancy,

vacancy, and daylight harvesting.

Wiring

5Conﬁrm Device Connectivity

Conﬁrm Status Indicator is Solid Green (see details below)

Log on to www.lightcloud.com or call 1 (844) LIGHTCLOUD

6Commission your devices

To add new devices to your Lightcloud network, call RAB at

1 (844) LIGHTCLOUD, or email us at [email protected].

4Power up

GREYGREY

MODULARMODULAR

REDRED

PURPLEPURPLE

WHITEWHITE WHITEWHITE

BLACKBLACK BLACKBLACK

120-277 VAC

Load or

Fixture

Controller Mini

Lightcloud

Controller Mini

Lightcloud

Solid GREEN when connected to your

Lightcloud network. Blinking RED when not

connected. The device will automatically

continue trying to connect to a network

in Setup Mode.

Illuminates when the device receives a

message and blinks the signal strength.

3 Blinks - Best signal

2 Blinks - Acceptable signal

1 Blinks - Unacceptable signal

Consult the “Finding a Location” section

for more information

STATUS INDICATOR

SIGNAL INDICATOR

• Illuminated when device is powered

• Press once to highlight this device in the

Lightcloud Application

•

• Press twice and hold to set dim level

Press twice to toggle circuit on and oﬀ

• Press and hold for 10 seconds to remove

this device from a Lightcloud network

• Blinks when device is indicated from the

Lightcloud Application

DEVICE IDENTIFICATION BUTTON

Setup & Installation (cont’d) Setup & Installation

OFF

WARNING

OFF

Turn oﬀ power

Find a Suitable Location

Lightcloud Installer Application

3Labeling your device

Use these guidelines when installing devices:

• If there is a clear line of sight between two Lightcloud

devices, they can be placed up to 1000 feet apart.

• If the two devices are separated by ordinary drywall

construction, try to keep them within 100 ft. of each other.

• Brick, concrete and steel construction may require

additional Lightcloud devices to go around the obstruction.

LightcloudGateway

<= 100 ft.

Add an additional Lightcloud

Device to extend network range

around corners B R I C K ,

CONC R E T E O R

M E T A L WA L L

D R Y W A L L

O R S I MIL A R

When installing devices, it’s important to keep track of their Device IDs, installation

locations, panel/circuit #s, dimming function, and any additional notes. To organize this

information, use the Lightcloud Installer Application (A) or Device Table (B).

Install the LC Installer Application: LC Installer is available for iOS and Android.

Scan & Install Lightcloud Devices: Scan each device and assign to a room. It’s

recommended that each device is scanned just before or just after being wired so no

devices are missed. The more notes that are given, the easier it is to commission the system.

Send to RAB: Once all of the devices have been added and organized, submit the

information for commissioning.

Device Table

For setup and maintenance,

we provide two Lightcloud

Device Tables with the

Gateway: one that you can

attach to your panel and one

to hand oﬀ to a building

manager. Attach the Device

Identiﬁcation stickers included

witheach device to a row,

then write in additional

information, such as Zone

name, Panel/Circuit Number,

and whether or not a zone

uses dimming.

Device Scanner

Enter Manually

PLACE RECTANGLE TO FIT CODE ON LABEL

Scan Device Code

Device Info

SaveCancel

Device ID 0013A20040B62A4A

Location Oﬃce

Zone Name Oﬃce Lights

Dimmable

Power Monitoring

Enter Device Information Repeat for Additional Devices

Devices

Add DeviceSend to RAB

Office Light - ID 0013A20040B62A4A

Controller

Office Light - ID 0013A20040B62A4B

Sensor

Office Light - ID 0013A20040B62A4C

Dimmer

Office Light - ID 0013A20040B62A4D

Daylight

Office Light - ID 0013A20040B62A4E

Touch

Send to RAB

Device Scanner

Enter Manually

PLACE RECTANGLE TO FIT CODE ON LABEL

D E V IC E I Ds

DEVICE 1D ZONE NAME

PANEL/

CIRCUIT # DIMMING

Setup & Installation (cont’d)

2Install your Lightcloud Controller

0-10V DIMMING

NOTE: The National Electrical Code requires that low-voltage wiring used in

the same enclosure as high-voltage wiring have an equal or better insulation

rating. You may need to complete your low-voltage wiring in another

enclosure or use a partition.

0-10V is a common method of low-voltage control of dimmable

drivers and ballasts. Purple: 0-10V positive | Gray: 0-10V common

2a Install at a Junction Box (Indoor/Outdoor)

2b At Lighting Panel or Trough

Space and code allowing, you may install Lightcloud devices directly

in your breaker box or lighting panel. Alternatively, break out lighting

circuits and install Lightcloud devices in a separate trough.

Controller requires constant, unswitched power.

When power switch

is set to OFF

Controller is disconnected

from network

OFF

P O W E R L O A D

DON’T

Controller always has power and is

connected to the network

P O W E R L O A D

WHITE

BL ACK

Controller Mini

Lightcloud

RED

WHITE

BLACK

BL ACK

GRAY

PURPLE

To Load

To PanelTo Driver/Ballast

MODULAR CABLE
