Raidon InTANK iR2023 Bedienungsanleitung

InTANK

iR2023

User Manual

» InTANK iR2023 User Manual ............................. 1

1. Package Contents and Product Views ..............................1

2. Operation Information........................................................2

3. Hardware Requirements and Precautions ........................3

4. Hardware Installation Procedure .......................................3

5. RAID Mode Setting............................................................4

6. Computer Setup ................................................................5

7. Hard Disk Status on LCD Screen......................................6

8. Data Rebuilding Operation ................................................7

9. GUI Monitoring Software and Firmware Update ...............8

10. Questions & Answers ......................................................10

» InTANK iR2023 產品使用說明 ........................... 12

1. 產品外觀及包裝內容 ..........................................................12

2. 環境需求 ............................................................................13

3. 硬體需求與注意事項 ..........................................................14

4. 硬體安裝 ............................................................................14

5. 設定 RAID 層級..................................................................15

6. 電腦設定 ............................................................................16

7. 訊息顯示 ............................................................................17

8. 資料重建功能說明..............................................................18

9. GUI 功能說明與韌體更新...................................................19

10. 常見問題 ..........................................................................21

iR2023 User Manual

V1.0

iR2023 User Manual

1. Package Contents and Product Views

Introduction

Thank you for purchasing RAIDON products. This User Manual will introduce you the InTANK iR2023

storage product. Before using your iR2023, please read it thoroughly. Although all information

contented in this User Manual had already been carefully veried before publishing, however, the

actual product and its specication will be based upon the time of delivery from RAIDON. Any update

to the product or its relevant information may be listed on www.raidon.com.tw . Product is subjected

to change without prior notications.

If you have any question regarding to the product you purchased, or you would like to know the

latest product information, User Manual’s update, please contact to your local supplier or visit to

www.raidon.com.tw for further information.

Open the package and you should nd the following parts:

iR2023

iR2023 x1 ( with removable drive tray enclosed x3)

SATA Cable x1

Screws & Keys

Quick Installation Guide x1

• Please check the product and accessories for any defect or missing parts. If you have any questions,

please contact your product supplier.

• Please visit the ofcial website (www.raidon.com.tw) to download drivers and other related resources.

iR2023 User Manual

Product View, Front and Back

LED Indicators：

1. LCD Display

2. UP/DOWN Buttons

3. ESC Button

4. Enter Button

5. Mute Button

6. Power Failure Indicator

1. Cooling Fan

2. 3-pin Fan Connector

3. RS232 Connector

4. 7-pin SATA Connector (Standalone HDD)

5. 15-pin Power Connector

6. 7-pin SATA Connector (RAID HDD)

Status Standalone HDD RAID HDD System Indication Buzzer

No HDD N/A Red light always on Purple light always on ON

HDD Idle Blue light always on Blue light always on Blue light always on N/A

Access Blue light ashing Purple light ashing Blue light always on N/A

Rebuilding-Source Blue light always on Blue light always on Blue light always on N/A

Rebuilding-Target Blue light always on Red light ashing Blue light always on N/A

Fan Failure Blue light always on Blue light always on Purple light always on ON

7. HDD Tray Handle

8. HDD Tray Ejection

9. HDD tray key lock

10. HDD Access Indicator

2. Operation Information

Operating Temperature : 0～40 ℃(32 ～104 ℉)

Storage Temperature : -10 ~ 70 oC (14 ~ 158 oF)

Line Voltage : 5V DC

Standalone HDD

Pri HDD

Sec HDD

iR2023 User Manual

After unlocking the HDD tray key lock with the key attached to the accessory, push the

HDD tray ejection to the right and the removable drive tray will pop open to remove the

removable tray.

Install the 2.5-inch hard disk and secure it with

the small screws included in the 4 parts package.

When the hard drive installation has been

completed, insert the hard drive tray into the

system horizontally and secure the latch into

place.

Install device into one of the CD-ROM bays

with screws from the accessory kit. Then

properly connect SATA cable and DC cable

from your system to the device.

3. Hardware Requirements and Precautions

1. Computers or servers must be with SATA I, SATA II, or SATA III interface.

2. Hard drive must be with SATA I, SATA II, or SATA III interface.

3. The independent drive at the top cannot be set into RAID mode with primary or secondary drive.

It is an independent drive.

4. You are strongly advised to set the storage mode before using your iR2023. (The default setting is

the RAID 1.)

5. Once the drive mode conguration has been completed, re-conguration using the same hard

drives to set the drive mode will result in complete data loss. If you must change the drive mode,

make sure to backup all data prior to the mode change.

6. A reboot is required after adding or changing RAID mode to ensure that the update is completed

to the new RAID mode.

7. iR2023 product allows user to simultaneously use the two different hard drives from two different

manufactures. However, if the user expects a better efciency, we strongly recommend the user

to use the two hard drives from the same manufacturer.

8. Please make sure that the two hard drives are free from bad blocks or defects prior to installation

in order to avoid system crashes or data loss.

9. The actual storage capacity of iR2023 recognized by the system may differ from the total capacity

stated on the hard drives combined once the drives have been formatted.

10.It is highly recommended for user to back up important data contained within the iR2023 unit on

a regular basis or whenever the user feels necessary to a remote or a separate storage device.

RAIDON will not be responsible for any lost of data caused during the use of the unit or the

recovery of the data lost.

4. Hardware Installation Procedure

Please follow the instructions below to complete the hardware installation.

Step 1

Step 2

Step 3

Step 4

Lock Unlock

iR2023 User Manual

5. RAID Mode Setting

After placing your two hard disks, turn on power and press UP Button, you are with the RAID Setting

mode. (Since the default setting is RAID 1 mode by factory, you do not have to reset RAID if you

want to use your iR2023 with RAID 1 mode.)

1. RAID 1 mode

1). Place two new hard drives into iR2023.

We would strongly suggest you to use two identical hard drives to get the maximum memory

capacity. And if the capacities of your two hard drives are difference, iR2023 only recognizes

the memory capacity at the small capacity hard drive.

2). Under RAID 1 mode, two hard drives will have the identical information as one from its mirroring

feature, therefore, even though one and only one of the two hard drives failed, iR2023 will

still work ne and properly. Once you replace the failed hard disk with a new one, iR2023 will

automatically do rebuilding the data from the good one to the new hard disk.

RS232 Port and RS232 Cable: Provides hardware status monitoring to industrial control system or IPC via

RS232. If more information are required, please contact [email protected].

SATA

SATA Cable

SATA Power Cable

Internal host shell schematic

iR2023

Power on your system after hardware installation is completed, and your operating system

will automatically detect the hard drives from booting. Then follow the steps from your

operating system to partition and format the drives when necessary, device will be ready to

use once the format is completed.

Step 5

※ Note :

1. RS232 Port and RS232 Cable: Provides hardware status monitoring to industrial control system or IPC via RS232.

2. We do not recommend users to disassemble the device without proper instructions and authorization. The manufacture warranty

will not cover the damages caused by unauthorized disassembling.

3. To prevent the device from malfunction, please make sure the device is connected with a direct and dedicated power connection of

a stable power input.

4. RS232 Port: For industrial control system or IPC to monitor the hardware status. More information, please contact your sales

window or [email protected]

iR2023 User Manual

6. Computer Setup

When the hardware setup for iR2023 is complete, you are now ready to turn the machine on.

After the hardware installation is complete, the iR2023 will be treated as one single hard drive. When

the computer is turned on, the system will retrieve the following information.

1. Device Manager Utility of Window OS will automatically detect the hard drive(s).

2. You can choose to format the hard drive by using the Disk Management tool of the operating

system before using the iR2023.

At this point, the installation process is completely nished. The user can freely retrieve and save

data to iR2023 just like retrieving and saving data to a regular hard drive. If the user has any problem

during the operation, please refer to the Question & Answer (Q&A) section in Appendix.

2. RAID 0 mode

1). Place two new hard drives into iR2023.

We would strongly suggest you to use two identical hard drives to get the maximum memory

capacity. And if the capacities of your two hard drives are difference, iR2023 only recognizes

the memory capacity at the small capacity hard drive.

2). Under RAID 0 mode, the total memory capacity of iR2023 would be double from the small capacity

hard drive. And also, RAID 0 mode will perform an excellent efficiency from its high data

transfer rate for user to read & write data.

iR2023 User Manual

7. Hard Disk Status on LCD Screen

2. Over Heat (≥50°C)

Pri HDD : OK

Sec HDD : OK T

3. Fan Failure

Pri HDD : OK F

Sec HDD : OK

4. RAID 1 Degraded：Primary hard drive is failure, but secondary hard drive is normal.

RAID-1 degraded

Pri : M Sec : O

5. RAID 1 Failure：Primary and secondary hard drives are failure.

RAID-1 failure

Pri : M Sec : M

6. RAID 1 Failure：Double Source

RAID-1 failure

Double Source

7. RAID 0 Failure：Primary hard drive is missing, but secondary hard drive is normal.

RAID-0 failure

Pri : M Sec :O

8. Rebuilding

Rebuilding

Sec →Pri 32%

1. Booting and Normal status.

RAIDON RAIDbox2

RAID-1 vxxxxxx.x

Pri HDD : OK

Sec HDD : OK

iR2023 User Manual

The Hot Swappable hard drive and Auto Rebuilding features are available.

Off-line Back up：When the data is stored in iR2023, user can remove one of the hard drives as

back up drive for data such as system operation le, secured les, seldom modied les or image

and music les. The user can periodically insert the hard drive back into iR2023 to execute automatic

backup to protect the system from being hit by computer virus or to avoid the risk of having both hard

drives failing at the same time.

When one of the two hard drives fails in iR2023, it will issue an alert of a hard drive failure message

in both LCD display and the monitoring software. User can remove the failed hard drive from the

system while the system is still in operation without shutting down the machine. If the failed hard

drive is replaced shortly, the system will automatically execute the Auto Rebuilding function without

affecting the system operation and also any operation command from the user.

When the iR2023 detects one hard drive missing or failure, the Buzzer starts BEEPING and the LCD

displays the following messages：

After replacing a new hard disk with the failed one, LCD displays the following messages:

After few seconds from your inserting a new hard drive, LCD displays the data rebuilding progress：

When iR2023 completes its rebuilding, LCD again displays the following messages：

8. Data Rebuilding Operation

Pri HDD : OK

Sec HDD : OK

RAID-1 degraded

Pri : X Sec : O

Pri HDD : OK

Sec HDD : Insert

Rebuilding

Sec →Pri 32%

Pri HDD :Insert

Sec HDD : OK

Rebuilding

Pri →Sec 32%

iR2023 User Manual

Users can download the GUI software from the website to monitor the status of the product.

1. System Status:

This GUI automatically detects your iR2023 and reveals relative information accordingly.

2. Firmware Upfrade:

You may update the Firmware via this GUI, to just simply click on the “Load” button to locate the

rmware le to proceed. After completing the update, you may restart the power to work with the

new rmware.

※ Caution: Any random rmware update may cause the malfunction at your iR2023, We strongly recommend you not to change/upgrade

iR2023 rmware if still works properly.

9. GUI Monitoring Software and Firmware Update

Andere Handbücher für InTANK iR2023

Inhaltsverzeichnis

Andere Raidon Lagerung Handbücher

Raidon

Raidon SafeTANK GT2660-TB3 Bedienungsanleitung

Raidon

Raidon SafeTANK GR8680-TB3 Bedienungsanleitung

Raidon

Raidon SafeTANK GR3660-TB3 Bedienungsanleitung

Raidon

Raidon safetank GR4670-WSB3 Bedienungsanleitung

Raidon

Raidon iR2880-8S-U5 Bedienungsanleitung

Raidon

Raidon SafeTANK SL5640-LB2 Bedienungsanleitung

Raidon

Raidon iR2774-S3 Bedienungsanleitung

Raidon

Raidon iR2777-S3 Bedienungsanleitung

Raidon

Raidon SafeTANK GR5640-SB31+ Bedienungsanleitung

Raidon

Raidon SAFETANK GT4670-TB Bedienungsanleitung

Raidon

Raidon InTANK IR2025 Bedienungsanleitung

Raidon

Raidon InTANK iR2771-S3 Bedienungsanleitung

Raidon

Raidon InTANK iR2823 Original Betriebsanleitung

Raidon

Raidon iR8023 Bedienungsanleitung

Raidon

Raidon InTANK iR2024 Bedienungsanleitung

Raidon

Raidon InTANK iR2775-S3 Bedienungsanleitung

Raidon

Raidon SafeTANK GT4670-SB3 Bedienungsanleitung

Raidon

Raidon SafeTANK GR5630-SB3+ Bedienungsanleitung

Raidon

Raidon InTANK IR2025 Bedienungsanleitung

Raidon

Raidon SafeTANK GR5640-SB3 Bedienungsanleitung

Raidon

Raidon SR2611-2S-S2+ Bedienungsanleitung

Raidon

Raidon GT8670-TB3 Bedienungsanleitung

Raidon

Raidon safetank GT2670-WB3 Bedienungsanleitung

Raidon

Raidon InTANK iR2023 Bedienungsanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Western Digital

Western Digital Ultrastar Data60 Bedienungsanleitung
