FITTING INSTRUCTIONS FOR FI0124BK FRAME INSERT

MV AGUSTA BRUTALE 1090 2013-LOWER LEFT CAST SECTION

THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.

DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.

Please note that the way the kit is packed does not necessarily represent the way of

mounting to the bike

THE PARTS SHOWN MAY BE REPRESENTATIVE ONLY (FOR CLARITY OF INSTRUCTIONS ONLY)

Please note that in cases where kits are packed with rubber washers holding the components onto the bolt –

the rubber washers should be thrown away!

TOOLS REQUIRED

3mm metric Allen key.

FITTING INSTRUCTIONS

Fit button head bolt through frame insert so head sits in counter-bore.

Place special nut on exposed end of bolt so it goes into the tapered slot.

Tighten bolt until the nut just contacts tapered face of plastic frame insert.

Place the assembly into frame recess in position shown above.

Tighten bolt so frame insert is held in position firmly (do not over tighten).

Push fit cap in centre as shown above.

Regularly check to ensure frame insert remains tight.

Issue 1 21/04/2016 (NSY)

CONSUMER NOTICE

The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design

changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order. The

Buyer acknowledges no representation or warranty (other than as to title) has been given or will apply to the Products other than those

in R&G’s order or confirmation and the Buyer confirms it has chosen the Products as being of merchantable quality and suitable for

its particular purposes. Where R&G fits the Products or undertakes other services it shall exercise reasonable skill and care and rectify

R&G Racing

Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire, GU34 3AQ

Tel: +44 (0) 1420 89007 | Fax : +44 (0) 1420 87301 | Email: info@rg-racing.com

any fault free of charge unless the workmanship has been disturbed. The Buyer is responsible for ensuring that the warranty on the

motorcycle is not affected by the fitting of the Products. On return of any defective Products R&G shall at its option either supply a

replacement or refund the purchase money but shall not be liable if the Products have been modified or used or maintained otherwise

than in accordance with R&G’s or manufacturer’s instructions and good engineering practice or if the defect arises from accident or

neglect. Other than identified above and subject to R&G not limiting its liability for causing death and personal injury, it shall not be

liable for indirect or consequential loss and otherwise its liability shall be limited to the amounts paid by the Buyer for the Products or

the fitting or service concerned. These terms do not affect the Buyer’s statutory rights.

R&G RACING RETURNS POLICY (NON-FAULTY GOODS)

Returns must be pre-authorised (if not pre-authorised the return will be rejected). Goods may only be returned direct to us if they were

purchased direct from us (customer must prove if necessary). Otherwise to be returned to original vendor. Goods must be in re-

sellable condition, in the opinion of R&G Racing. All returns are subject to a 25% restocking and handling fee (25% of the gross value

exc. P&P –at the prevailing price at time of purchase). The customer must pay any and all carriage charges. No returns of

discontinued products, unless within 14 days of purchase. This policy does not affect your statutory rights and does not refer to faulty

goods.

R&G Racing

Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire, GU34 3AQ

Tel: +44 (0) 1420 89007 | Fax : +44 (0) 1420 87301 | Email: info@rg-racing.com

NOTICE DE MONTAGE POUR FI0124BK INSERT DE CADRE

MV AGUSTA BRUTALE 1090 2013- SECTION INFERIEURE GAUCHE

Le kit contient les articles exposés ci-dessous, vérifier que toutes les pièces soient présentes

avant de procéder au montage.

La façon dont le kit est emballé ne correspond pas forcément à la façon de monter les pièces

sur la moto.

LES PARTIES PRESENTEES PEUVENT ETRE UNIQUEMENT REPRESENTATIVES

(POUR LA CLARTE DES INSTRUCTIONS UNIQUEMENT)

Notez que si les kits sont emballés avec des rondelles en caoutchouc servant à tenir les composants, ces

rondelles doivent être jetées!

OUTILS REQUIS

Clé Allen 3mm.

NOTICE DE MONTAGE

Passer le boulon dans l’insert de cadre de façon à ce que la tête se place dans l’alésage.

Placer l’écrou spécial sur l’extrémité du boulon pour qu’il se place dans la fente.

Serrer le boulon jusqu’à ce que l’écrou touche la face conique de l’insert de cadre.

Placer l’assemblage dans le creux de cadre dans la position ci-dessus.

Serrer le boulon de façon à ce que l’insert de cadre soit maintenu en position fermement (Ne pas

serrer complètement).

Pousser le capuchon au centre, comme ci dessus.

Vérifier le serrage de l’insert de cadre de façon régulière.

Issue 1 21/04/2016 (NSY)
