Raycus RFL-A200D Bedienungsanleitung

Fiber Delivered Direct Diode

RFL-A200D

Laser User Guide

（compact module）

Wuhan Raycus Fiber Laser Technologies Co., Ltd

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

1. Safety Information

Thank you for choosing Raycus Fiber Delivered Direct Diode laser. This

User Guide provides important safety, operation, warranty and other

information. Please read it carefully before you use this product. In order

to ensure safe operation and optimal performance of the product, please

follow the warnings, cautions, operating procedures and other instructions

accordingly.

1.1 Symbols Used in this User Guide

WARNING: Describes a hazard that lead to a personal injury or death.

CAUTION: Describes a hazard that lead to a minor personal injury

or product damage.

1.2 Laser Classification

This series of lasers are classified as a high power Class 4 laser

instrument according to the European Community standards EN 60825-1, clause

9. This product emits invisible laser radiation at or around a wavelength

of 915 nm, and the total light power radiated from the optical output is

greater than 200W. Direct or indirect exposure of this level of light

intensity may cause damage to the eye or skin. Despite the radiation being

invisible, the beam may cause irreversible damage to the retina and/or cornea.

Appropriate and approved laser safety eyewear must be worn all the time while

the laser is operational.

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

WARNING: You must use appropriate laser safety eyewear when operating

this device. The laser safety eyewear is selected according to the

range of wavelengths emitted from this product. The end user must

ensure that the laser safety eyewear used protects against light

emitted by the device over its entire range of wavelengths. Please

check the safety labeling on the product and verify that the personal

protective equipment (e.g. enclosures, viewing windows or view ports,

eyewear, etc.) being utilized is adequate for the output power and

wavelength ranges listed on the product.

1.3 Safety Labels

These include warning labels, apertures through which laser radiation

is emitted and labels of certification and identification, etc.

Specifications of these labels are as follows:

1：

Laser Radiation Hazard

2: Aperture Label

3: Aperture Label(CN)

4: Class 4 Laser Product(EN)

5: Class 4 Laser Product(CN)

6:Class 2M Laser Product

Label for Guide Laser(EN)

7: Class 2M Laser Product

Label for Guide Laser(CN)

8: Electrical Hazard Label

9:Identification Plate

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

1.4 Optical Safety

Any dust on the end of the collimator assembly can burn the lens and

damage the laser.

CAUTION: If the output of the device is delivered through a lens with

an anti-reflection coating, make sure that the lens is of good quality

and clean.

CAUTION: DO NOT emit when the protective cap is not removed, or the

laser will be damaged.

1.5 Electrical Safety

a） Make sure your product is grounded through the PE line of the AC power

cord. The grounding must be firm and reliable.

WARNING: Any interruption from the protective earth will electrify

the enclosure, which may result in personal injury.

b） Make sure that the correct voltage of the DC power source is used.

CAUTION: Failure to connect the laser to the correct voltage could

damage the product.

c） There are no operator serviceable parts inside, so do not try to

remove covers, or electrical shock may be caused, and warranty will

be void.

1.6 Other Safety Rules

a） Never look into the laser output port when power is supplied to the

laser.

b） Avoid using the laser in a dim or darkened environment.

c） If this device is used in a manner not specified in this document,

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

the protection provided by the device may be impaired and the warranty

will be voided.

d） Do not remove the covers of the laser, or the warranty will be voided.

All maintenance must be performed in Raycus or by qualified Raycus

personnel.

2. Product Description

2.1 Features

Your Raycus Fiber Delivered Direct Diode laser is designed for

industrial and scientific research applications with high pump conversion

efficiency, low power consumption and excellent beam quality. It is compact

and ready to use. It can be used as a stand-alone unit or easily inserted

into user’s apparatus.

Main Features:

Fiber delivery

Reliable, long lifetime

Maintenance free operation

High wall-plug efficiency

Convenient control interface

Fast modulation

Applications:

Soldering Tin

Welding plastics

Scientific research

2.2 Package Contents

Please refer to the packing list accompanying the shipment to check

actual items included.

2.3 Unpacking and Inspection

Your Raycus fiber delivered direct diode laser is shipped in a package

designed to provide maximum protection. Upon delivery, please inspect all

packaging for evidence of mishandling or damage. If you find any evidence

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

of mishandling, please save the damaged material and contact the shipping

agent and Raycus immediately.

Remove all the contents from the packing case. Take extra care when

removing the unit from the packing case to ensure that the fiber optic cable

is not snagged and damaged. A comprehensive packing list is included with

the system documentation. Check all items against the list and contact Raycus

immediately if there is any missing item or evident damage to the unit.

DO NOT attempt to install or operate the laser, if there is any evident

or suspected damage to the unit.

It is recommended that you do not discard the packing materials, as they

will be necessary if you ever need to ship the unit back for service at a

later date.

CAUTION: The fiber optic cable and output head are precise optic

instrument, Any vibration or impact to the output head, and twist

or excessive bend to the cable will damage the instrument.

2.4 Operation Environment

Table 1 The Operation Conditions for the Laser

Installation Environment

Flat and no vibration

Ambient Temperature

0℃～30℃

Relative Humidity

＜70%

It is recommended to install the product in an environment with air

conditioning.

2.5 Precautions for Use

a） Make sure the instrument is properly grounded before you use it;

b） Make sure that the correct voltage of 48VDC power source is used.

Failure to connect power source correctly will damage the device;

c） There are no user serviceable parts, equipment or assemblies inside

the product. All service and maintenance shall be performed by

qualified Raycus personnel. In order to prevent electric shock,

please do not break the seal or uncover the shield. Failure to comply

with this instruction will void the warranty;

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

d） Please inspect the output head carefully for dust or other

contamination. Use appropriate lens paper to clean it if necessary.

Do not touch the output lens at any time;

e） Please cap the output head when it is not in use, and make sure the

cap is clean;

f） It is not allowed to install the output head when the laser is in

operation;

g） Do not look into the output head directly. Wear appropriate

protective eye glasses all the time when operating the laser;

h） Failure to follow the instructions may cause malfunction and damage

to the device, such damage is not covered by warranty.

2.6 Specifications

The specifications are listed in the following table.

Table 2 Product Specifications

Model

*RFL-A200D/B/5/B/T

Max Power Consumption (W)

1200

Power Supply

48VDC±10%

Nominal Output Power(W)

>200

Output Power Instability

≤2%

Emission Wavelength(nm)

915±10

Red Guide Laser

650±10nm，0.25～1mW

Core Fiber (μm)

200

Fiber NA

0.22

Connect model

SMA905

Connect Port

DB25、DB9

Operation Mode

EXT control/RS232

Modulation Frequency (Hz)

50Hz～10KHz

Cooling Method

wind

Operating Ambient Temperature(℃)

0～30℃

NOTE：

*RFL-A200D/B/5/B/T——code rule:

200——output laser power

B——wavelength 915nm

5——delivery cable length (m)

B——connect model SMA905

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

T——wind cooling

2.7 Dimensions and Installation

Figure1 and Figure2 show dimensions and Installation of the product.

Figure 1 dimensions (unit: mm)

Figure 2 Installation (unit: mm)

Please leave a space as table 3 between Raycus fiber on every side for

the necessary air circulating.

Table 3 gap wanted (unit: mm)

GAP

UPPER

200

FRONT SIDE

300

REAL SIDE

300

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

2.8 Installation Procedure

a） Check if the power supply has the correct voltage (48VDC±10%), and

the earth line is connected, make sure it is firm and reliable;

b） Place the product in an appropriate position, immobilize it if

necessary;

c） Connect the power cable and control cable to the product when power

supply is OFF;

d） Check the output head and clean it if necessary. This procedure must

be performed by Raycus personnel or person authorized by Raycus. Make

sure the environment is clean, or the output head may be contaminated.

It is prohibited to use fan during installation, which will cause

dust in the air;

e） Prevent the delivery cable from treading, pinching or excessive

bending during installation.

CAUTION: All the cables can only be connected when power supply is off.

Hot plug may damage the laser.

CAUTION: Ensure that there are no fiber bends with radius less than 20cm

when the product is installed. Avoid excessive twisting and tight bends

during the robotic arm movements. Tight bends will damage the laser

delivery system.

When the product is in storage, the bending radius of the delivery cable

should be more than 20cm.

CAUTION: Avoid vibration and impact to output head, or it may be damaged.

CAUTION: Make sure the aperture and the cavity of the processing head

is clean;

Keep the protective cap properly, prevent it from contamination; Or the

aperture will be contaminated when capped.

武汉锐科光纤激光技术股份有限公司

WUHAN RAYCUS FIBER LASER TECHNOLOGIES CO. LTD.

2.9 Precautions for Product

Fiber Delivered Direct Diode Lasers RFL-A200D adopts air cooled

miniaturization design, which requires high heat dissipation. Users in

different industries have different technology application plans when using

lasers. According to the heat dissipation capacity of this laser, the

recommended and restricted use conditions are given, as shown in Table 4

and Figure 3.

Table 4 Laser operating state at different ambient temperatures

The working

temperature ℃

Continuous use of

duty cycle %

Limit duty cycle

usage %

100

*95

**97

*80

**85

**30

>35

Note：

* Continuous use: working time ≤ 1 Hour.

** Restricted use: the laser working for a long time under this condition

may cause the radiator to overheat, the laser alarm, automatically shut

down the laser output; Turn off the power supply of the laser, wait for

the laser to cool down, and then re-energize it for normal use.

Dieses Handbuch passt für folgende Modelle

Andere Raycus Messgerät Handbücher

Raycus

Raycus RFL-C3300X Bedienungsanleitung

Raycus

Raycus RFL-A1000D Bedienungsanleitung

Raycus

Raycus RFL-A1500D Bedienungsanleitung

Raycus

Raycus RFL-C15000TZ Bedienungsanleitung

Raycus

Raycus RFL-P200 Bedienungsanleitung

Raycus

Raycus RFL-P200MX Montageanleitung

Raycus

Raycus RFL-C3000S Bedienungsanleitung

Raycus

Raycus RFL-QCW450/1500FS Bedienungsanleitung

Raycus

Raycus RFL-C2000S-HP Bedienungsanleitung

Raycus

Raycus RFL-P200S+ Montageanleitung

Raycus

Raycus RFL-FDDL100X Bedienungsanleitung

Raycus

Raycus RFL-C Series Bedienungsanleitung

Raycus

Raycus RFL-C4000XZ Bedienungsanleitung

Raycus

Raycus RFL-C Series Bedienungsanleitung

Raycus

Raycus RFL-A2000D Bedienungsanleitung

Raycus

Raycus RFL-C4000S Bedienungsanleitung

Raycus

Raycus RFL-C20000XZ Bedienungsanleitung

Raycus

Raycus RFL-C1500X Bedienungsanleitung

Raycus

Raycus RFL-P70Q Bedienungsanleitung

Raycus

Raycus RFL-P200 Bedienungsanleitung

Raycus

Raycus RFL-C1500 Bedienungsanleitung

Raycus

Raycus RFL-C1500H Bedienungsanleitung

Raycus

Raycus RFL-P100QA Montageanleitung

Raycus

Raycus RFL-C100 Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
