Product Manual for Gaming Headset
Model: RZ04-0347
.
FOR GAMERS. BY GAMERS.™
1
WHAT’S INSIDE / WHAT’S NEEDED
WHAT’S INSIDE
Gaming Headset (Model: RZ04-0347)
A. EQ / Xbox Pairing button
B. Game / Chat balance wheel
C. Bluetooth / Multi-function button
D. Adjustable padded headband
E. Breathable memory foam ear
cushions
F. Earcups powered by Razer
ChromaTM
G. Mic mute switch
H. Volume wheel
I. Status indicator
J. Power button
K. Charging port
L. Microphone jack
M. Mic diaphragm
Charging cable
Removable Razer™ HyperClear Supercardioid Mic
Important Product Information Guide
WHAT’S NEEDED
PRODUCT REQUIREMENTS
Xbox One TM / Xbox One TM S / Xbox One TM X / Xbox SeriesTM X
LEFT
RIGHT
FOR GAMERS. BY GAMERS.™2
OR
PC (Windows® 10 64-bit or higher) with a free USB port*
OR
Devices with Bluetooth 5.0 connectivity
RAZER HEADSET SETUP FOR XBOX APP REQUIREMENTS
PC or Xbox console
Internet connection for app installation
RAZER AUDIO COMPANION APP REQUIREMENTS
iOS or Android device with Bluetooth connectivity
Internet connection for app installation
*May require the Xbox Wireless Adapter for Windows 10 (not included).
SAFETY STATEMENT
IMPORTANT! Before using your Xbox console with this product, read its instruction manual for safety,
health, and other information regarding the use of your Xbox console.
LET’S GET YOU COVERED
You’ve got a great device in your hands, complete with a 2-year limited warranty coverage. Now
maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com
FOR GAMERS. BY GAMERS.™1
GETTING STARTED
CHARGING YOUR HEADSET
Connect your Gaming Headset (Model: RZ04-0347) to a powered USB port using the charging cable.
For best results, please fully charge your headset before using it for the first time. A depleted headset
will fully charge in about (x) hours.
Once fully charged, your Gaming Headset (Model: RZ04-0347) will briefly show its battery level on the
status indicator.
Indicator
Battery level
Charging
Fully charged
[IMAGE PLACEHOLDER]
[IMAGE
PLACEHOLDER]
Type C
FOR GAMERS. BY GAMERS.™3
PAIRING YOUR HEADSET
A. TO YOUR XBOX CONSOLE
1. Press the Connect button on your console.
2. Press and hold the power button until the status indicator is briefly lit or until you hear a tone
to power on the headset.
3. Press and hold the EQ / Xbox Pairing button until the status indicator is blinking green to
activate Xbox pairing mode. The status indicator will then turn static green to indicate that the
headset is now paired to the Xbox console.
[IMAGE
PLACEHOLDER]
Indicator
Status
Pairing
Connected
[IMAGE
PLACEHOLDER]
FOR GAMERS. BY GAMERS.™4
B. TO YOUR PC VIA XBOX WIRELESS ADAPTER FOR WINDOWS 10*
Make sure that your Xbox Wireless Adapter for Windows 10 is up-to-date. Some systems have Xbox
Wireless built in which allows you to pair your headset by using Add a device in Settings.
1. Plug in your Xbox Wireless Adapter for Windows 10* to your PC and then press its Connect
button.
2. While powered on, press and hold the EQ / Xbox Pairing button until the status indicator is
blinking green to activate Xbox pairing mode. The status indicator will then turn static green to
indicate that the headset is now paired to the wireless adapter.
Indicator
Status
Pairing
Connected
[IMAGE
PLACEHOLDER]
[IMAGE PLACEHOLDER]
FOR GAMERS. BY GAMERS.™5
C. TO YOUR MOBILE DEVICES VIA BLUETOOTH
While powered on, press the Bluetooth / Multi-function button until the status indicator is lit or until
you hear a tone to activate Bluetooth pairing mode. Follow your device’s instructions to pair it with
your headset. Once the headset is paired, the status indicator will briefly change to static blue.
[IMAGE
PLACEHOLDER]
FOR GAMERS. BY GAMERS.™6
USING YOUR GAMING HEADSET (MODEL: RZ04-0347)
POWER BUTTON
Power ON / OFF
Power on or off your headset by holding the power button until the status indicator is on; and holding
the button again to turn off. Two distinct tones will help notify you that the headset is powered on or
off.
Changing Earcup Lighting
When powered on, the power button can also be used to cycle between the lighting presets on the
headset. Simply press the power button to change the current lighting effect on the earcups.
[IMAGE
PLACEHOLDER]
The headset’s lighting effect can
also be configured from the
Razer Audio Companion app
(on iOS and Android) and the
Razer Headset Setup For Xbox
app (on PC and Xbox console).
[IMAGE
PLACEHOLDER]
FOR GAMERS. BY GAMERS.™7
