Reebok Z7 Bedienungsanleitung

Z7 Treadmill

Assembly Guide

www.reebokﬁtness.info/productsupport

0201

reebokﬁtness.info

Assembly Guide

Z7 Treadmill

Assembly Guide

Z7 Treadmill

03 07

02 06

reebokﬁtness.info

05Assembly Guide

Z7 Treadmill

0908

11 15

10 14

reebokﬁtness.info

Assembly Guide

Z7 Treadmill

1716

18 22

reebokﬁtness.info

0807

09Exploded Diagram

Z7 Treadmill reebokﬁtness.info

Part Name QTY Part Name QTY

1 Base frame welding 1 49 Computer cover 1

2 Main frame welding 1 50 Place with the computer (big) 1

3 Upright post welding 1 51 Place with the computer (small) 1

4 Handle bar welding 1 52 Sundries frame (left) 1

5 Feet pad welding 1 53 Sundries frame (right) 1

6 Motor board welding 1 54 Handle bar cover (up) 1

7 Incline frame welding 1 55 Handle bar cover (down)） 1

8 Inner hex bolt M10*35*20 2 56 Ellipse round stuﬀ 2

9 Inner hex bolt M8*50*20 8 57 Protect wire ring 2

10 Inner hex bolt M8*45*20 2 58 Ellipse round stuﬀ 2

11 Inner hex bolt M8*40*20 1 59 Base frame cover (left) 1

12 Inner hex bolt M8*30*20 1 60 Base frame cover (right) 1

13 Inner hex bolt M8*20 2 61 Uncork stuﬀ 2

14 Hexagon knob 45*45*M8*20 2 62 Running board 1

15 Inner hex bolt M8*75 3 63 Front roller 1

16 Inner hex bolt M8*30 2 64 Rear roller 1

17 Inner hex bolt M8*15 4 65 Motor 1

18 Outside hex bolt M8*50 1 66 Cushion with seat 2

19 Outside hex bolt M8*40 1 67 Cylinder 1

20 Cross bolt M8*25 2 68 Taper feet pad 4

21 Cross bolt M6*25 4 69 Motor belt 1

22 Cross bolt M6*8 4 70 Running belt 1

23 Cross bolt M5*10 6 71 Rear cover feet pad 2

24 Cross bolt M4*10 8 72 Decorate piece 4

25 Cross bolt ST5*15 4 73 Wheel）62 2

26 Cross bolt ST4*30 4 74 Wheel）46 2

27 Cross bolt ST4*15 34 75 Foam 2

28 Cross bolt ST4*15 10 76 Controller 1

29 Cross bolt ST4*10 8 77 Transformer 1

30 Cross bolt ST5*15 2 78 Safety key 1

31 Cross bolt ST4*15 4 79 Switch 1

32 Cross bolt ST3*08 2 80 Fuse seat with wire 1

33 Hex nut M10 2 81 MP3 connect wire 1

34 Hex nut M8 6 82 Inductor 1

35 Flat washer ）10 2 83 Wire L1 1

36 Flat washer ）8 17 84 Wire L2 1

37 Washer ）5 1 85 Wire L3 1

38 Flat washer ）4 4 86 Power supply connect wire (red) 1

39 Washer ）8 2 87 Power supply connect wire (black) 1

40 Power metallurgy cover 17*）10*12 2 88 Speed wire and handle pulse wire set 1

41 Spring 1 89 Start and stop and handle pulse wire set 1

42 Motor cover(up) 1 90 Power supply wire 1

43 Side rail 2 91 Wire buckle 1

44 Decorate piece 2 92 Wire protect cover 1

45 Rear cover (left) 1 93 Square cushion 2

46 Rear cover (right) 1 94 Column cushion 2

47 Rear cover feet pad 2 95 Wire nip 1

48 Square stuﬀ 2 96 Cross screw ST4×20 4
