Reliance Foundry R-7535 Bedienungsanleitung
Decorave Bollard Installaon Adhesive Anchoring
1-877-789-3245 | info@reliance-foundry.com | www.reliance-foundry.com
To protect the nish, keep bollards in original
packaging unl exact moment of installaon.
Handle with care to avoid scratching or damaging
bollard surfaces as abrasions will lead to rust.
Once scratched, bollards cannot be repaired
to original form without re-nishing the enre
surface.
Parts List
Installaon Equipment
#PART QTY
1Bollard Base 1
2Bollard Cap 1
3Threaded Bar 1" 1
4Washer 1" 1
5Hex Nut 1" 1
6Hexagon Socket Set Screw 3
7Plasc Plug 3
1-1/8" Masonry Drill Bit Chalk
1-1/2" Wrench Caulking Gun
3/16" Hex Key Level
Hammer Drill or Rotary Hammer Measuring Tape
Adhesive Anchoring System* (included)
Before Installaon
STEP 1: Always check for hazards such as water pipes,
gas lines, and underground wiring before drilling.
STEP 2: Use a broom or pressure washer to clean the
concrete surface prior to bollard installaon.
STEP 3: Study the site plans to locate and mark the
precise center point of each bollard. For secure
installaon, ensure there is a minimum radius** of solid
concrete around each mark.
Drill the Hole
STEP 4: Tap a pilot divot hole in the center of each mark.
STEP 5: Set the depth control on the hammer drill (or
rotary hammer) to 4". If depth control is not available,
mark 4" on the masonry bit.
STEP 6: Drill a hole that has a 1-1/8" diameter and 4"
depth. Drill on high speed, using the hammer funcon
if available.
*Please refer to the adhesive manufacturer’s MSDS (included in
shipment) before using.
**Adhesive anchor manufacturers such as www.powers.com
recommend a minimum radius of 5".
R-7535
SECTION Y-Y
SCALE 0.42 : 1
PARTS LIST
DESCRIPTION
PART
NUMBER
QTY
ITEM
R7535 BaseR7535B
11
R7500
Threaded
Bar 1" x 42"
R7500B
AR 1"
1
4
Hex Nut 1" -
requires 1
1/2" wrench
Hex
Nut 1"
1
6
Hexagon
Socket Set
Screw 3/8" x
1/2" -
requires
3/16" hex key
Hexago
n
Socket
Set
Screw
3/8" x
1/2"
3
7
Polyethylene
Plug 3/8"
Polyethy
lene
Plug
3/8"
38
R7535 CapR7535C
1
2
Washer 1"
OD 2" Thick
1/8"
Washer
1" OD
2"
1
5
Y
Y
3
1
4
5
6
7
2
4"
1 1/8"
Decorave Bollard Installaon Adhesive Anchoring
1-877-789-3245 | info@reliance-foundry.com | www.reliance-foundry.com
4"
4"
PARTS LIST
DESCRIPTION
PART
NUMBER
QTY
ITEM
R7535 BaseR7535B
11
Drop-in
Concrete
Insert 3/4" -
requires 1" x
3 1/8" hole
(dia. x depth)
Drop-in
Concret
e Insert
3/4"
1
2
R7500
Threaded
Bar 3/4" x
30"
R7500B
AR 3/4"
1
4
R7535C
1
7
Hexagon
Socket Set
Screw 3/8" x
3/4" -
requires
3/16" hex key
Hexago
n
Socket
Set
Screw
3/8" x
3/4"
1
8
Polyethylene
Plug 3/8"
Polyethy
lene
Plug
3/8"
1
9
Install Plastic
Screw Cap
A
STEP 8
STEP 12 STEP 13
STEP 11
STEP 14
STEP 15
R-7535
Inspect the installaon. Abrasions should be
covered as soon as possible. For damage repair
or other servicing needs, please contact Reliance
Foundry’s sales department.
Secure the Bollard
STEP 7: Clear the hole of all debris and/or standing water
using the vacuum. Use a brush to remove any remaining
loose parcles.
STEP 8: Using the caulking gun, dispense the adhesive from
the boom up unl the hole is one-quarter full. Prevent air
pockets by withdrawing the mixing nozzle slowly.
STEP 9: Carefully place the bollard near the installaon
posion. When ready to install, remove its protecve
packaging.
STEP 10: Set the bollard base upright and maneuver it so
the center lines up with the drilled hole.
STEP 11: Lower the threaded rod through the top of the
bollard and into the drilled hole.
STEP 12: Insert the threaded rod the full 4" into the drilled
hole while turning for posive adhesion. The rod should
be centered in the bollard’s sha. Note: A minimum of 45
minutes at 68˚F is required for the anchoring system to set.
STEP 13: Place the washer over the threaded rod so it
rests on top of the bollard base. Apply the 1" nut to the
threaded rod and use a wrench to ghten unl the bollard
is secure.
STEP 14: Remove the bollard cap from packaging and place
on top of the sha of the bollard. Secure and align the
bollard cap to the bollard base with the three set screws.
Tighten in equal amounts to ensure the cap remains
centered.
STEP 15: Place the plasc plugs (A) over the heads of the
set screws.
