Reolink Argus Eco Bedienungsanleitung

Argus Eco

Argus Eco works cable-free with a rechargeable battery and reliable Wi-Fi

connection. Flexible and weatherproof – you can put it anywhere with 5-minute

installation!

1. Specs

Status LED

Built-in Mic

4 IR LEDs

Lens

Daylight Sensor

Built-in PIR Motion Sensor

Status Light

Camera Status

Red light

Wi-Fi connection failed

Blue light

Wi-Fi connection succeeded

Blinking

Standby status

Working status

2. Setup and Install

Set up the Camera

What’s in the Box

Note: The package content may vary and update with different version and

On/Off Switch

Micro SD Card Slot

Speaker

Reset Hole

Antenna

Micro USB Port

Battery Status LED

platforms, please take the below information only for a reference. And the actual

package content are subject to the latest information on the product selling page.

Argus Eco

Set up the Camera on the App

Please follow the steps below to do initial setup for the battery-powered cameras

via Reolink App.

Step 1. Power on the camera. Remember to turn on the power switch on the

camera before initial setup except for Argus 2 and Argus Pro. After a startup sound,

you will hear a repeated Ding sound or a voice prompt.

Note: The voice prompt you will hear may be "Welcome to Reolink, please install

Reolink app and scan the QR code on the camera" in multilingual versions, or

"please run Reolink app, add the camera and set it up".

Step 2. Tap the icon in the top right corner to start the initial setup.

Surveillance Sticker*1

Pack of Screws*1

Reset Needle*1

Argus Eco*1

Mounting Template*1

Quick Start Guide*1

Outdoor Security

Mount*1

USB Cable*1

Step 3. Scan the QR code on the back of the camera. You may tap Light to enable

a flashlight when setting up the camera in a dark environment. If the phone

doesn't respond, please tap Input UID/IP and then manually type in the UID

(16-digit characters under the QR code of the camera). Then click Next.

Step 4. Select Wi-Fi Not Configured. If you hear a voice prompt played by the

camera, please tick correspondingly and then tap Next.

Step 5. Enter the WiFi password of the selected WiFi network (you may tap the

right eye icon to see and double-check the password) and tap Next.

Note: Argus Eco only supports the WiFi frequency of 2.4GHz.

Step 6. Tap Scan Now. Place the QR code on your phone in front of the camera’s

lens at a distance of about 30 cm (12 inches) and let the camera scan the QR code.

Tick correspondingly and tap Next.

Step 7. Wait around 60 seconds for the camera to connect to the router. After

hearing "connection to the router succeeded", tick correspondingly and tap Next.

Step 8. Create a login password and then name your camera.

Step 9. Read the note below and then tap Finish to complete the initialization of

your camera.

Once the initial setup is completed, you may choose a good position to mount your

camera.

Install the Camera

We offer you guides on different scenes in which the camera could be installed.

Check out them respectively.

Mount the Camera to the Wall

Step 1. Drill holes and screw the security mount into the wall.

Note: If you are mounting the camera on any hard surface, insert plastic anchors

into the holes first.

Step 2. Screw the antenna to the camera and install the camera to the mount.

Step 3. Loosen the adjusting knob and adjust the camera in the proper direction.

Step 4. Tighten the knob to fix the camera.

Attach the Camera to a Tree

Step 1. Thread the strap through the slots of the mounting plate.

Step 2. Fix the plate to the mount with screws.

Step 3. Fasten the strap onto the tree firmly.

Step 4. Attach the camera to the mount in the same way as in mounting it to the

wall.
