FURY

Residential Electric Water Heaters

Available in 30, 38.5 and 60 Imperial Gallon Electric Models



6 Year Limited Tank Warranty*



1 Year Limited Parts Warranty*

•R-Foam Insulation for greater heat

retention – cuts energy costs

•Proven Rheemglas™Lining resists

corrosive attacks of hot water chemicals

– ensures longer tank life

•Direct Immersion Elements efficiently

transmits heat directly to water and

creates more hot water at less cost

•Magnesium Anode Rod for greater

protection of inner tank – reduces

corrosion and extends water heater life

•Temperature and Pressure Relief

Valve included

•Factory Installed Plumbing Nipples

•Electrical Junction Box is located

ontop of water heater – reduces wiring

costs and more attractive appearance

•Automatic Temperature Control

Thermostats keeps water stored at a

desired temperature – convenient,

dependable hot water

•Certified to the CAN/CSA C191.1-M90

efficiency standard

*See Residential Warranty Information

Brochure for complete warranty information.

DESCRIPTION FEATURES ROUGHING IN DIMENSIONS

STORAGE HEATING ELEMENTS OUTSIDE HT. TO ESTIMATED

CAPACITY HEIGHT DIAMETER DRAIN SHIPPING WEIGHT

IMP. ELEM. 120 VOLT 208 VOLT 240 VOLT (IN.) (IN.) VALVE (IN.)

MODEL NUMBER GALS. LITERS QTY. WATTAGE AMPS WATTAGE AMPS WATTAGE AMPS A B C LBS. KG

RR317T 30 135 2 1500 12.5 2250 10.8 3000 12.5 46-1/2 19-3/4 3-1/2 105 48

RR415TM 37.5 170 2 1500 12.5 2250 10.8 3000 12.5 46 21-3/4 3-1/2 117 53

RR615TM 60 270 2 N/A N/A 3380 16.3 4500 18.8 59 23 3-1/2 177 80

RR415SI 38.5 175 2 N/A N/A 2250 10.8 3000 12.5 47 21 3-1/2 124 56

RR615SI 60 270 2 N/A N/A 3380 16.3 4500 18.8 58 23 3-1/2 174 79

RR620SI 60 270 2 N/A N/A 3380 16.3 4500 18.8 58 24-5/16 3-1/2 188 85

• 3⁄4" N.P.T. outlet, inlet, anode rod, T&P valve connections.

• 140°F thermostat setting.

• Not available with 3 phase wiring.

In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.

YEAR LIMITED

TANK WARRANTY

BECOMES

TOP INLET, TOP EXIT

SIDE INLET, TOP EXIT

Get

2 MORE YEARS

with ProtectionPlus™

Rheem Manufacturing Company • Water Heater Division

Rheem Canada Ltd./Ltée,128 Barton Street West, Hamilton, Ontario L8N 3P3

03/06 WP FORM NO. 101-5CAN Rev.6
