SEIDIO GPS READY MOUNT KIT

USER GUIDE

CONTENT

Features

Get to know your GPS ready mount

Power and charge your PDA

GPS ready connection

Speaker function

Additional Power output

FEATURES

 Model specific - You can simply slide your PDA into the cradle without having to take the time to plug in the

additional wires and cables.

 Securely hold and charge your PDA , while also improving the sound output making GPS voice commands and

other digital sounds to be heard clearly and loudly through the integral speaker.

 GPS ready - You can plug the GPS mouse (wired) receiver directly into the cradle for charging and connecting to

the PDA. No more messing around with tangled and expensive Y-cables. For blue tooth receiver users, It can

charge the blue tooth receiver with the optional charging cable.

 It can serve as a hands free speakerphone for cellular phone or PDA phone with optional hands free cable.

 With a 360-degree swivel adaptor, maximum driver/passenger readability and viewing is always assured.

 It can charge your blue tooth receiver, cellular phone, and additional PDA with optional charging cable.

 DC power can either be supplied either from the cigarette lighter socket or by hard-wiring the cradle directly into the

car’s electrical system (12-24 V)

 Mounting solutions - With pedestals included, PDA users can mount their PDA in a variety of ways based on

personal preference or vehicle interior.

GETTING TO KNOW YOUR GPS READY MOUNT

COMPONENTS

1. Protection Pad

2. PDA Holder

3. PDA Holder Connector

4. Power on LED indicator

5. GPS-Ready Port (GPS Ready connection for Mouse GPS)

6. DC OUT port (charge your blue tooth receiver, cellular phone, and additional PDA)

7. Mounting Bracket

8. 12V DC power input port

9. Audio In Jack

10. Volume Control

11. Amplified Speaker

POWER AND CHARGE YOUR PDA

Cigarette Lighter Adapter

Plug into the

DC input port

How to Power your cradle and charge your PDA?

This GPS Ready Mount comes with a cigarette lighter adapter. To power the cradle, simply plug the cigarette

lighter adaptor into 12V DC input port on the cradle.

The cradle can also be hard-wired directly into the car’s electrical system with optional hardwire cable

To charge your PDA, slide your PDA into the PDA holder. It will then be charged automatically. The charging light

on PDA should be on when PDA is being charged. If not, make sure PDA and PDA holder connector is properly

connected.

GPS READY MOUNT CONNECTION

GPS Ready Connection (For Wired GPS receiver users only)

Seidio GPS Ready Mount has a built-in RJ-11 connector on top of the cradle. You can plug your receiver directly

to the cradle for charging and connecting to your PDA for navigation. GPS receivers with connectors other than

RJ-11 need an additional GPS adaptor cable. The LED light on the receiver should be on when the receiver is

properly connected to the cradle

Supported Mouse GPS Receivers:

Seidio HaiCom Holux

TomTom iTrek Rikaline

Leadtek GlobalSat

The GPS adaptor for other models will be available soon. Please check with seidio site for update

GPS READY MOUNT SPEAKER FUNCTION

Speak Function (For GPS Ready Mount with speaker only)

The speaker function enables users to listen to GPS voice commands, digital books, and MP3 music over

the noise of the road through the built-in high performance speaker.

Step 1: Slide your PDA in the cradle.

Step 2:Plug the cigarette lighter connector from the cradle to the cigarette lighter

port in your car to get power from the car to operate the G2500 Mount.

Step 3: Connect the audio cable from the headphone jack on the PDA and to the

speaker jack on the cradle, which is located on the top right corner of the cradle.

Step 4: Play your music or any other voice program on your PDA. The sound

playing on your PDA will now play from the built in speaker on the cradle.

Step 5: Adjust the volume level by using the volume control on the left side of the

cradle to your desired volume level. Make sure the volume level will not disturb you when you are driving

Audio Cable

GPS READY MOUNT ADDITIONAL POWER OUTPUT

Charge an additional Device using add-on Charging Cable

This add-on charging cable must be purchased separately

With an Add-on Charging cable (optional), the GPS Ready Mount can charge an additional PDA, wireless

phone or some of the digital device such as FM transmitter.

To use this cable, plug the one end of the cable into the DC OUT port located on the left side of the cradle.

Plug the other end of the cable into the device charging port.

GPS READY MOUNT ADDITIONAL POWER OUTPUT

Charge the Bluetooth GPS receiver using the Bluetooth Receiver

Charging Cable

You must purchase this Bluetooth cable separately

With this "Bluetooth Receiver Charging Cable", you can power and charge your Bluetooth GPS receiver

through the DC OUT port on the cradle.

To use, attach one end of the cable to the DC OUT port located on the cradle and plug the other end of the

cable into the GPS Power inlet.

This cable is compatible with EMTAC/Socket Bluetooth GPS, Fortuna Bluetooth GPS, Belkin Bluetooth GPS

and TomTom Bluetooth GPS Receiver. The Charging Cables for other blue tooth receivers will be available

soon. Please check our web site, www.seidio.com, for updates.

SEIDIO GPS READY MOUNT

At SEIDIO we are dedicated to providing the best quality products

and service!

If you need any assistance with this product, please contact us by email:

For Europe customers:

[email protected]

For all other countries:

[email protected]

You may also find information and updated user documentation on the Seidio websites, www.seidio.com and

www.seidio-europe.com.

Our customer representatives will gladly assist you with any questions regarding the operation of this unit, available

accessories, or any other related matters.

Thank you for purchasing a SEIDIO GPS Ready Mount Kit!

Seidio Inc.

See the latest in products

by visiting us at:

www.seidio.com

Rev. 2.0
