Rinnai INFINITY 32 Bedienungsanleitung

To Suit Water Heater Models -

INFINITY 32 REU-VR3237WG

INFINITY 26 REU-VR2626WG

INFINITY 26 Plus REU-VRM2630WD

INFINITY 26i REU-VR2632FFUG

INFINITY 20 REU-VR2024WG

INFINITY 16 REU-VR1620WG

INFINITY ENVIRO 32 REU-KM3237WD

INFINITY ENVIRO 26 REU-KM2635WD

B16 REU-VR1620WB

B20 REU-VR2024WB

B24 REU-VR2426WB

HD250e REU-VRM3237WC

HD200e REU-VRM2632WC

HD200i REU-VRM2632FFUC

Operation / Installation

Manual

Rinnai continuous flow water heaters

This appliance shall be installed in accordance with:

• Manufacturer’s Installation Instructions

• Current AS/NZS 3000, AS/NZS 3500 & AS/NZS 5601

• Local Regulations and Municipal Building Codes including local OH&S requirements

This appliance must be installed, maintained and removed by an Authorised Person.

For continued safety of this appliance it must be installed operated and maintained

in accordance with the manufacturers instructions.

Rinnai Australia i Operation Manual

TABLE OF CONTENTS

REGULATORY INFORMATION..................................................................................1

WARNING ABOUT HOT WATER ...............................................................................1

FEATURES AND BENEFITS ......................................................................................2

IMPORTANT INFORMATION .....................................................................................3

OPERATION WITHOUT CONTROLLERS..................................................................5

GENERAL WATER CONTROL INFORMATION ........................................................6

MAXIMUM DELIVERY TEMPERATURES...................................................................................................6

UNIVERSAL WATER CONTROLLERS......................................................................8

ABOUT THE UNIVERSAL WATER CONTROLLER (MC-91Q)................................................................... 8

TURNING ON THE CONTROLLER............................................................................................................. 8

ADJUSTING TEMPERATURE..................................................................................................................... 8

HOW TO USE TWO OR MORE UNIVERSAL WATER CONTROLLERS ................................................... 9

TRANSFERRING PRIORITY ....................................................................................................................... 9

ADJUSTING TEMPERATURE..................................................................................................................... 9

DELUXE BATHROOM WATER CONTROLLERS ....................................................10

ABOUT THE DELUXE BATHROOM WATER CONTROLLER (BC-100V) ................................................ 10

TURNING ON THE CONTROLLER........................................................................................................... 10

SETTING THE SOUND OPTIONS ............................................................................................................ 11

SETTING THE CLOCK .............................................................................................................................. 11

ADJUSTING TEMPERATURE................................................................................................................... 11

OPERATING THE SHOWER SAVER / BATH FILL FUNCTION ............................................................... 12

USING MULTIPLE WATER CONTROLLERS ........................................................................................... 13

COMBINING UNIVERSAL AND DELUXE WATER CONTROLLERS ....................................................... 13

DELUXE KITCHEN WATER CONTROLLERS .........................................................14

ABOUT THE DELUXE KITCHEN WATER CONTROLLER (MC-100V) .................................................... 14

TURNING ON THE CONTROLLER........................................................................................................... 14

SETTING THE SOUND OPTIONS ............................................................................................................ 14

SETTING THE CLOCK .............................................................................................................................. 15

ADJUSTING TEMPERATURE................................................................................................................... 15

SMARTSTART® PRE-HEAT OPERATION ..............................................................16

ABOUT THE SMARTSTART® PREHEAT SYSTEM ................................................................................. 16

TROUBLESHOOTING...............................................................................................17

INSTALLATION MANUAL ........................................................................................20

ACCESSORIES ........................................................................................................36

PRODUCT RECORDS .............................................................................................36

CONTACT INFORMATION ......................................................................................37

Rinnai Australia 1 Operation Manual

Your Rinnai Continuous Flow water heater has been certified by the Australian Gas Association.

The A.G.A. Certification Number is shown on the data plate.

This Appliance must be installed correctly by an authorised person. The installation of gas, water, and

electricity must conform to local regulations.

The installation must also comply with the instructions supplied by Rinnai.

All dimensions referred to in these instructions are in millimetres, unless otherwise specified.

Please keep this instruction booklet in a safe place for future reference.

Notice to Victorian Consumers

This appliance must be installed by a person licensed with the Plumbing Industry Commission.

Only a licensed person will have insurance protecting their workmanship.

So make sure you use a licensed person to install this appliance and ask for your Compliance

Certificate. For Further information contact the Plumbing Industry Commission on 1800 015 129.

Heated water can be dangerous, especially for young

children and the infirm.

Water temperatures above 50°C can cause severe burns

instantly and may even result in death.

Those most at risk are children, disabled, elderly and the

infirm.

Hot water at 65°C (a very common hot water temperature in

Australia) can severely burn a child in less than half a second.

At 50°C it takes five minutes.

ALWAYS......

Test the temperature of the water with your elbow before placing your child in the bath, also

carefully feel water before bathing or showering yourself.

Supervise children whenever they are in the bathroom.

Make sure that the hot water tap is turned off tightly.

CONSIDER.....

Installing child proof tap covers or child resistant taps (both approaches will prevent a small

hand being able to turn on the tap).

Setting your appliance at a maximum temperature of 50°C (Contact Rinnai Australia).

NEVER…..

Leave a toddler in the care of another child. They may not understand the need to have the

water temperature set at a safe level.

REGULATORY INFORMATION

WARNING ABOUT HOT WATER

Rinnai Australia 2 Operation Manual

FEATURES AND BENEFITS

Congratulations on purchasing the latest technology temperature controlled Rinnai continuous flow

water heating system.

•The Rinnai Continuous Flow water heater products NEVER RUN OUT of hot water. Whilst

electricity, water and gas supplies are connected, hot water is available whenever hot water taps are

open.

•Built into the main micro-processor is the facility to LIMIT THE MAXIMUM TEMPERATURE of the

hot water supplied. The water temperature may be limited to various values. This is particularly

useful when the hot water unit is installed where young children or the infirm may be using the hot

water.

•The Rinnai Continuous Flow water heater products are power flued appliances. This makes them

COMPACT, saving both floor and wall space.

•The temperature of hot water is CONSTANTLY MONITORED by a BUILT-IN SENSOR. If the

temperature of the hot water rises to more than 3°C above the selected temperature the burner is

turned OFF and only turned ON again when the temperature falls below the selected temperature.

•The burner lights automatically when the hot water tap is opened, and goes out when the tap is

closed. IGNITION IS ELECTRONIC, so there is no pilot light. When the hot water tap is off, no gas is

used.

•The "Smartstart®" system when fitted can pre-heat the water in the pipe-work between the water

heater and the hot water outlets. This results in water savings and reduces waiting time for heated

water at the outlets.

•'Deluxe' or 'Universal' Water Controllers are available as an optional extra. Depending on the

models chosen, these offer the following features:

• Bath fill function (Deluxe Bathroom Control Only).

• Voice Prompting (Deluxe Control Only).

• Clock (Deluxe Control Only).

• Up to four water controllers can be fitted. See page 7 for details.

• Water controller cables are connected easily by the end user using a convenient quick connect

system.

•Operating NOISE LEVEL IS VERY LOW.

•ERROR MESSAGES ARE DISPLAYED on the Water Controllers and Status Monitor*, assisting with

service. *Status Monitor available on INFINITY 26 Plus (REU-VRM2630WD), HD250e (REU-

VRM3237WC), HD200e (REU-VRM2632WC) and HD200i (REU-VRM2632FFUC) models only.

Rinnai Australia 3 Operation Manual

IMPORTANT INFORMATION

The range of Rinnai continuous flow water heaters referred to in this manual are

incompatible with solar water heating systems. A dedicated range of solar

compatible continuous flow water heaters is available from Rinnai.

Always check water temperature carefully before

use. Refer to the WARNING ABOUT HOT WATER

on "page 1" of this manual for important safety

information.

At low water flows, the hot water unit may extinguish

without warning. Opening the tap further will restart

the appliance.

Do Not touch the unit cover or the flue outlet.

Do Not insert objects into the flue outlet.

On colder days steam may discharged from the flue

outlet. This condition is normal for high efficiency

appliances and does not indicate a fault.

Keep flammable materials, spray cans, fuel

containers, pool chemicals, trees, shrubs, etc. well

clear of the flue outlet.

Do Not spray water directly into the flue terminal.

If freezing conditions are expected, turn off water and

gas and drain all water from the appliance. If power

and the automatic frost protection are connected,

freezing will be prevented. (Anti-frost protection is

fitted as standard equipment on External units and is

available as an optional extra on Internal Units)

The delivered water temperature is controlled

automatically. The flow may vary depending on the

delivery temperature selected and the ambient water

temperature.

NOTE

OFF!

HOT!

Filter

Drain

Gas

Valve

GasColdHot

Turn Water Off

Turn Gas Off

Drain Water

43°C

55°C

Rinnai Australia 4 Operation Manual

IMPORTANT INFORMATION

To clean your water controller(s) use a soft

damp cloth with a mild detergent.

Do Not use solvents!

Whilst hot water outlets are open the set

temperature may be lowered. However they

cannot then be raised above 43°C. In addition

transfer of 'priority' between controllers is not

possible. These are safety features.

Depending on the weather conditions and the

length of the pipe between the hot water unit

and the outlet in use, there may be a variation

between the temperatures displayed at the

water controller(s) and the temperature of the

water at the outlet.

There is no need to turn the water controller(s)

off after use. However, if you prefer to turn the

water controller(s) off, selected temperatures

to a maximum of 50°C will be stored in the

system memory at all times whilst mains power

remains connected.

As a safety precaution, if a Kitchen Controller's

temperature is set above 50°C, transferring

and then returning 'priority' to the Kitchen

Controller will result in a default set

temperature of 50°C being selected. This is a

safety feature.

Do Not push the On/Off button on any

Controller when the ‘Red’ water heater ‘In Use’

indicator is illuminated as this will turn off the

water heater causing the water to go cold.

Someone maybe in the middle of having a

shower or filling a bath.

Max.

43°C

49°C

50°C

Kitchen Kitchen

Bathroom

Rinnai Australia 5 Operation Manual

OPERATION WITHOUT CONTROLLERS

Rinnai Continuous Flow water heater products do not use a pilot light.

When installed and operated without water controllers, the opening of any hot water tap will

automatically start the appliance.

Once water is flowing through the appliance the burner will be ignited by electronic ignition.

When the hot water tap is closed and water flowing through the appliance has stopped the burner

flame will extinguish.

Heated water can be dangerous, especially for young children and the infirm.

Water temperatures above 50°C can cause severe burns instantly and may even

result in death.

Those most at risk are children, disabled, elderly and the infirm.

Hot water at 65°C (a very common hot water temperature in Australia) can

severely burn a child in less than half a second. At 50°C it takes five minutes.

ALWAYS......

Test the temperature of the water with your elbow before placing your child in the

bath, also carefully feel water before bathing or showering yourself.

Supervise children whenever they are in the bathroom.

Make sure that the hot water tap is turned off tightly.

CONSIDER.....

Installing child proof tap covers or child resistant taps (both approaches will

prevent a small hand being able to turn on the tap).

Setting your appliance at a maximum temperature of 50°C (Contact Rinnai

Australia).

NEVER…..

Leave a toddler in the care of another child. They may not understand the need

to have the water temperature set at a safe level.

HOTHOT

COLDCOLD

ON!ON!

ON!ON! HOTHOT

COLDCOLD

OFF!OFF!

CAUTION

Rinnai Australia 6 Operation Manual

GENERAL WATER CONTROL INFORMATION

MAXIMUM DELIVERY TEMPERATURES

Rinnai continuous flow water heaters are factory pre-set to various maximum delivery temperatures

depending on model and their intended application. For the majority of applications, the factory pre-

set temperature is appropriate. In the unlikely event this is not the case this setting can be increased

or decreased by an authorised person such as a licensed plumber.

Factory pre-set delivery temperatures for the various models are as follows:

This does not apply to “50 degree compliant” or “Solar” models. To meet the

regulatory requirements for these models, the maximum delivery temperature is

factory set and sealed.

MODEL NUMBER

Note: The model number is

written on the dataplate on

the left hand side of

appliance

MODEL NAME FACTORY “PRE-SET”

MAXIMUM

DELIVERY

TEMPERATURE (°C)

CAN FACTORY

“PRE-SET”

MAXIMUM

DELIVERY

TEMPERATURE BE

CHANGED BY AN

AUTHORISED

PERSON?

REU-VR1620WG INFINITY 16 60 Yes

REU-VR2024WG INFINITY 20 60 Yes

REU-VR2626WG INFINITY 26 60 Yes

REU-VR2632FFUG INFINITY 26 Internal 60 Yes

REU-VRM2630WD INFINITY 26 Plus 60 Yes

REU-VR3237WG INFINITY 32 60 Yes

REU-KM2635WD ENVIRO 26 60 Yes

REU-KM3237WD ENVIRO 32 60 Yes

REU-VR1620WG-50 INFINITY 16 - 50°C Compliant 50 No

REU-VR2024WG-50 INFINITY 20 - 50°C Compliant 50 No

REU-VR2626WG-50 INFINITY 26 - 50°C Compliant 50 No

REU-VR3237WG-50 INFINITY 32 - 50°C Compliant 50 No

REU-VR2632FFUG-50 INFINITY 26 Internal - 50°C

Compliant

50 No

REU-VR1620WB B16 60 Yes

REU-VR2024WB B20 60 Yes

REU-VR2426WB B24 60 Yes

REU-VR1620WB-50 B16 - 50°C Compliant 50 No

REU-VR2024WB-50 B20 - 50°C Compliant 50 No

REU-VR2426WB-50 B24 - 50°C Compliant 50 No

REU-VRM2632WC HD200e 75 Yes

REU-VRM2632FFUC HD200i 75 Yes

REU-VRM3237WC HD250e 75 Yes

REU-VRM2632WC-50 HD200e - 50°C Compliant 50 No

REU-VRM2632FFUC-50 HD200i - 50°C Compliant 50 No

REU-VRM3237WC-50 HD250e - 50°C Compliant 50 No

NOTE

Rinnai Australia 7 Operation Manual

Remote water controllers allow precise temperature control by the user. When used correctly, the hot

water unit will deliver the selected temperature, even when the water flow is varied, or more than one

tap is in use. Each water controller can be individually programmed, however the water heater can

only deliver one set temperature at any time. The available temperatures (°C) are as follows:

Kitchen Controller:

37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 48, 50, 55*, 60*, 65* and 75°C*

Bathroom Controller:

Hot Water Delivery: 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 48, 50°C

Bath fill Delivery: 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48°C

Whilst hot water outlets are open the set temperature may be lowered. However the set temperature

cannot then be raised above 43°C. In addition, transfer of 'priority' between water controllers is not

possible. These are safety features.

Suggested temperatures are:

Kitchen 50°C ~ 55°C* Shower 37°C ~ 43°C, Bath fill 39°C ~ 45°C

* Temperature may not be available refer to “Delivery Temperatures”.

These temperatures are suggestions only. You may find higher or lower temperatures more

comfortable. Maintaining lower temperatures helps save energy. To obtain water temperatures lower

than 37°C simply add cold water.

Water controllers are an optional extra. 'Universal' and 'Deluxe' water controllers can be fitted.

Universal water controllers allow temperature selection only. Deluxe water controllers allow

temperature selection, shower saver / bath fill and have a clock function.

Water controllers allow the water temperature to be set from the various locations where they are

installed. The temperature selected will be available to all outlets.

Universal (MC-91Q) and Deluxe (MC/BC-100V) Water Controllers - available configurations:

All

Models

A maximum of 4 water controllers can be fitted. Any combination of both deluxe and

universal controllers can be used with the following provisions:

Only ONE MC-100V water controller can be installed.

Up to TWO BC-100V water controllers can be installed.

The FOURTH water controllers in any installation MUST BE a MC-91Q.

GENERAL WATER CONTROL INFORMATION

Andere Handbücher für INFINITY 32

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Rinnai Boiler Handbücher

Rinnai

Rinnai INFINITYREU-V3232W Bedienungsanleitung

Rinnai

Rinnai EHP32-HPST265 Bedienungsanleitung

Rinnai

Rinnai V2532FFU Series Bedienungsanleitung

Rinnai

Rinnai ByPass Servo Programmierhandbuch

Rinnai

Rinnai Hotflo 25L Bedienungsanleitung

Rinnai

Rinnai RH180 Technisches Datenblatt

Rinnai

Rinnai REI-NP Series Bedienungsanleitung

Rinnai

Rinnai RIN80E24 Bedienungsanleitung

Rinnai

Rinnai Circ-Logic RU80i Bedienungsanleitung

Rinnai

Rinnai REU-VR3237WG Bedienungsanleitung

Rinnai

Rinnai GHF4135N Bedienungsanleitung

Rinnai

Rinnai Infinity N1600i Technisches Datenblatt

Rinnai

Rinnai REU- A1620WD-IND Technisches Datenblatt

Rinnai

Rinnai Infinity 20e Bedienungsanleitung

Rinnai

Rinnai V53De Bedienungsanleitung

Rinnai

Rinnai Continuous Flow Water Heaters Bedienungsanleitung

Rinnai

Rinnai Circ-Logic RU98i Bedienungsanleitung

Rinnai

Rinnai RUS-51FT Bedienungsanleitung

Rinnai

Rinnai HD56kWe external Bedienungsanleitung

Rinnai

Rinnai RUC80i, RUC98i RU80e, RU98e Bedienungsanleitung

Rinnai

Rinnai RUCS65i series Bedienungsanleitung

Rinnai

Rinnai RLX94i Bedienungsanleitung

Rinnai

Rinnai NIPPON 600MP Bedienungsanleitung

Rinnai

Rinnai REU-AM2626WDL Bedienungsanleitung

Beliebte Boiler Handbücher anderer Marken

Kenmore

Kenmore 153.582400 Bedienungsanleitung

Applimo

Applimo Edel AIR Bedienungsanleitung

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Bedienungsanleitung

clage

clage E-Mini Series Bedienungsanleitung

Toyotomi

Toyotomi Oil Miser OM-180 Bedienungsanleitung

Bradford White

Bradford White EF Series Bedienungsanleitung

Eccotemp

Eccotemp 40-H Bedienungsanleitung

Dimplex

Dimplex ECSd125-580 Leitfaden

Dux

Dux 32FCR6N Bedienungsanleitung

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Fehlerbehebungshandbuch

Noritz

Noritz N-132M Gebrauchsanweisung

TESY

TESY GCV7/4S 10047 Technisches Datenblatt

A.O. Smith

A.O. Smith Gphe 50 Bedienungsanleitung

Koryo

Koryo KWHZF15Y Bedienungsanleitung

Pentair

Pentair PSC-14-4-02 Bedienungsanleitung

GE 40M06AAG Montageanleitung

Thermor

Thermor AEROMAX SPLIT 2 Bedienungsanleitung

American Hometec

American Hometec AHQ-B03X Bedienungsanleitung
