9405 DIGITAL

THERMOSTAT

Features and Benefits

Larger Back Lit Display

Makes viewing and setting the temperature

easy and accurate.

Automatic Compressor Short Cycle Protection

A system safeguard. Reduces wear and

tear of HVAC equipment.

Low Temperature Freeze Protection

Heat automatically turns on when temperature

goes below 40°F. Protects pipes from freezing.

Adjustable Temperature Differential

Maintains optimal customer comfort.

Quick Wire Terminal Block

Fast and easy installation. Uses sturdy wire clamps –

no wrap-around of screws.

Positive-Off Switch

Assured shutdown of HVAC system.

Toll-Free Assistance

Toll-Free Technical Service number printed right on

the thermostat provides immediate assistance.

1 Heat

Incredible Digital

When it comes to non-programmable temperature control, we

listened to the experts–YOU! Our new 9405 is the next evolution

in digital thermostats. The LCD display is clearly one of the

largest in the industry, up to 80% larger than competitive

models. Plus, the display is back lit, making it even easier to

read in a dark room.

This model is loaded with enhanced features. The 9405 comes

with a front load battery door, for no-hassle access to batteries,

and our fully adjustable differential provides increased comfort

control. This model is compatible with all standard 24 Volt AC

heating and millivolt systems.

When you select a Robertshaw thermostat, you’ve made the

choice of an industry partner that’s been making quality

products for 100 years. Come home to affordable comfort.

Come home to RobertshawSM.

Technical service available:

1-800-445-8299

M-F 7:30 a.m. - 5:30 p.m. CST

BATTERY

OPERATED

GAS

ELECTRIC

MILLIVOLT

new series!

Front Loading Battery Door

1 HeatTerminal Designations

THE ROBERTSHAW 9405 REPLACES:

Shipping Information

Indiv. Ctn. Dim.: 6.75" x 4.375" x 1.625"

Master Ctn. Qty.: 6

Master Ctn. Dim.: 9.25" x 5.625" x 7.625"

Master Ctn. Cu. Ft.: .23

Master Ctn. Wt.: 4.0 lbs.

Max. Pallet Qty.: 1170

Max. Pallet Dim.: 40" x 48" x 48"

Max. Pallet Cu. Ft.: 53.33

Max. Pallet Wt.: 835 lbs.

Other Single-Stage Heat

Thermostats

986-1: Mechanical

9204: Mercury-Free Deluxe Mechanical

24 VAC

Transformer

Fan

Relay

Heating

Relay

Specifications

Electrical rating: 24 Volt AC (18-30 VAC)

1 amp maximum load per terminal

3 amp total maximum load

(all terminals combined)

Temperature control range: 45˚- 90˚F (7˚- 32˚C)

Accuracy: +/-1˚F (+/-.5˚C)

DC power: 3.0 Volt

(2 “AA” alkaline batteries included)

System configurations: Single stage gas, oil,

electric or millivolt heating systems

Terminations: R, W, G

GAS ELECTRIC

Distributed by:

Uni-Line North America

515 South Promenade Avenue

Corona California 92879-1736 USA

Telephone +1 800 304 6563 Facsimile +1 800 426 0804

Outside the USA +1 909 734 2600

www.uni-line.com

9405 DIGITAL

THERMOSTAT

new series!

Robertshaw 9505

Honeywell, Inc.* T8400B

* Verify specific application requirements before substitution.

MILLIVOLT
