Rocket Fish RF-RBREC Bedienungsanleitung

Rocketboost™ Wireless Amplified

Audio Receiver

RF-RBREC

User Guide

RF-RBREC_10-1158_MAN_V4.fm Page 1 Friday, October 8, 2010 12:57 PM

RF-RBREC_10-1158_MAN_V4.fm Page 2 Friday, October 8, 2010 12:57 PM

RF-RBREC

Rocketfish RF-RBREC

Rocketboost™ Wireless

Amplified Audio Receiver

Contents

Introduction ...................................................................... 3

Important safety instructions ..................................... 4

Features .............................................................................. 8

Setting up your wireless receiver ............................13

Using your wireless receiver......................................17

Expanding your Rocketboost System....................21

Maintaining your system............................................23

Troubleshooting ............................................................23

Specifications..................................................................25

Legal notices ...................................................................25

One-year limited warranty.........................................29

Introduction

Congratulations on your purchase of the Rocketboost™ Wireless

Amplified Audio Receiver. This product represents the state of the art

in 2.4 GHz wireless audio design. When used with other Rocketboost

products you can enjoy your music throughout your house without

the limitations of cables.

The RF-RBREC is a Rocketboost receiver with a built in audio amplifier.

As an amplified receiver you connect it to your speakers and then

listen to the audio from any other Rocketboost sender. By using other

RF-RBREC_10-1158_MAN_V4.fm Page 3 Friday, October 8, 2010 12:57 PM

Rocketboost wireless audio products, you can also configure multiple

audio streams and listen to any of those audio streams at any

Rocketboost receiver device.

This Rocketboost product can receive signals from Rocketboost

senders that are up to 150 feet away. The audio signal is

uncompressed digital audio so your audio is the highest quality and

is free from interference.

This User Guide explains how to correctly install, operate, and get the

best performance from your Rocketboost Wireless Amplified Audio

Receiver. Read this guide carefully before installing your system, and

then keep it handy for quick reference.

Important safety instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning flash with arrowhead symbol,

within an equilateral triangle is intended to

alert the user to the presence of

uninsulated "dangerous voltage" within

the product's enclosure that may be of

sufficient magnitude to constitute a risk of

electric shock to persons.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK:

DO NOT REMOVE SCREWS, COVERS OR THE CABINET.

NO USER SERVICING PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RF-RBREC_10-1158_MAN_V4.fm Page 4 Friday, October 8, 2010 12:57 PM

RF-RBREC

4Follow all instructions.

5Do not use this apparatus near water.

6Clean only with a dry cloth.

7Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

8Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

9Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

11 Only use attachments/accessories specified by the manufacturer.

12 Unplug this apparatus during lightning storms or when unused for long

periods of time.

13 Refer all servicing to qualified service personnel. Servicing is required

when the apparatus has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

14 To reduce the risk of fire or electric shock, do not expose this device to

rain, moisture, dripping, or splashing, and no objects filled with liquids,

such as vases, shall be placed on it.

15 The wall plug is the disconnecting device. The plug must remain readily

operable.

16 Batteries should not be exposed to excessive heat such as sunshine, fire,

or the like.

Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

Warning: Read the Rating Label on the bottom of the unit for power input and other

safety information.

Caution - Proper Installation

Install the system in a place which is level, dry and neither too hot nor too cold. The

appropriate temperature is between 5° C and 35° C.

Install the system in a location with adequate ventilation to prevent internal heat

from building up inside the unit.

RF-RBREC_10-1158_MAN_V4.fm Page 5 Friday, October 8, 2010 12:57 PM

Proper ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate

the apparatus as follows:

Front: No obstructions and open spacing.

Sides/Top/Back: No obstructions should be placed in the areas shown

by the dimensions below.

Bottom: Place on the level surface. Maintain an adequate air path for

ventilation by placing on a stand with a height of 3-15/16" (10 cm) or

more.

What is Rocketboost™?

Rocketboost™ is expandable wireless digital audio.

• Products with Rocketboost™ technology let you easily expand your

listening experience throughout your home.

• Rocketboost™ does not interfere with other wireless products in your

home.

• Rocketboost™ is uncompressed digital audio compatible with all audio

formats such as Dolby® TrueHD, and DTS-HD Master Audio used with

Blu-ray.

(15 cm)

5-15/16"

(10 cm)

3-15 /16"

(15 cm)

5-15/16 "

(15 cm)

5-15/16 "

(15 cm)

5-15/16 "

Front view

Side view

RF-RBREC_10-1158_MAN_V4.fm Page 6 Friday, October 8, 2010 12:57 PM

RF-RBREC

When you see the Rocketboost™ logo on any product,

it has been designed to work with other

Rocketboost™ products, no matter who manufactures

them.

How does Rocketboost™ work?

Rocketboost technology can connect all audio devices throughout

your home to form a home audio network.

Rocketboost products include “Senders,” which send or transmit

audio streams, and “Receivers,” which receive the audio. This lets you

listen to music from your Sender in other rooms using your Receiver.

Rocketboost is expandable. Each Rocketboost Receiver can select the

audio from any Sender in your Rocketboost audio network. The

following shows an example Rocketboost network. You can set up

your network to meet your specific needs.

We hope you enjoy your new Rocketboost system. Remember that

it’s designed to grow with your home entertainment needs, and that

it’s easy to add a new device to the network as you expand your

system.

RF-RBREC

(receiver)

RF-RBWS02

(receiver)

RF-RBKIT

(sender)

RF-RBAUX

(sender/receiver)

RF-RBREC_10-1158_MAN_V4.fm Page 7 Friday, October 8, 2010 12:57 PM

Features

• High-Performance Audio - Uncompressed digital CD-quality sound,

adjustable volume control

• Strong Wireless Signal - 150 ft. wireless range (maximum, line of sight),

great sound, no static, won't interfere with your other wireless products

• Compatible with all Rocketboost products

• Easy to use - Easy to set up

• Two stereo channels with 42 W per channel, capable of driving any

non-powered speaker.

Package contents

The box should contain the following:

Wireless receiver

AC power cord

Speaker cable (2)

Remote control

User Guide Quick Setup Guide

Cable spool

RF-RBREC_10-1158_MAN_V4.fm Page 8 Friday, October 8, 2010 12:57 PM

RF-RBREC

Front panel

#Feature Description

1Standby indicator Turns red when receiver is in standby mode.

2Power/Join

button

Press to turn the receiver on. Press and hold to initiate joining. Press again to go to

standby mode.

Power/Join

indicator

The indicator will turn solid when it is joined in a network, if the device is not in a

network, the indicator blinks slowly. When the device is put in joining mode, the

indicator blinks rapidly.

4BASS button Toggles bass enhancement on or off.

5Bass indicator Lights when the bass enhancement is activated.

6SOURCE indicator Lights when the receiver is connected to an audio stream.

7SOURCE button Press to select different audio streams on your Rocketboost network. Each press moves

to the next source.

8HD indicator Lights when the receiver is receiving HD audio signals.

9IR sensor window Receives the signal from theremote control.

10 VOLUME knob Controls the volume level.

123

RF-RBREC_10-1158_MAN_V4.fm Page 9 Friday, October 8, 2010 12:57 PM

Back panel

#Feature Description

1 & 3 Slots for removable cable spool Use to mount the cable spool on the receiver.

2AC IN connector Plug the AC power cord into this connector.

4SPEAKER OUT jacks Connect your unamplified speakers to these jacks.

SPEAKER-OUT (4-8 Ohm)

120V~,60Hz

AC IN

RF-RBREC_10-1158_MAN_V4.fm Page 10 Friday, October 8, 2010 12:57 PM
