Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
Dear Customer!
Congratulations on the purchase of your Plug.n.DAQ Lite. This Product has been carefully designed and
engineered to provide you with a precise and reliable data acquisition instrument. Please read this
instruction manual before using the product, and keep it at hand for reference.
You’re ROGA-Instruments-Team
1. Introduction
1.1 System Requirements
PC with compatible OS and one available USB-connector (USB1.0, 1.1 or 2.0)
1.2 Included Parts
Following parts are included:
• 1 Plug.n.DAQ Lite 2 Channel or 1 Channel version IEPE DAQ
• 1 USB-cable
1.3 Safety Information– read before use!
Caution: The unit is only suitable for low voltage measurements. Under no circumstance should
voltages (AC or DC) above 40 Volt peak be connected to any input or output. Please enable the IEPE
supply only while an IEPE compatible sensor is connected to that input, as other devices may be destroyed
by the IEPE voltage of up to 28V.
The IEPE supply may also cause interference if there is no sensor connected.
2. Getting started
2.1 Connecting hardware
2.1.1 PC connection:
Use the supplied USB-cable to connect the Plug.n.DAQ Lite to an available USB port on your PC.
2.1.2 Analog Input
Connect your signal or sensor to the analog inputs (in 1 and in 2) using the optional BNC cable
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
2.2 Installation
Start your PC. Microsoft Windows ME, Windows 2000, Windows XP or above should be installed. These
operating systems do not require additional drivers. The Plug.n.DAQ Lite will be automatically detected and
installed as USB-Audio-Device.
You may now use your Plug.n.DAQ Lite with any software supporting Windows PC soundcards.
3. Making Measurements
3.1 Scaling
The maximum values represent the maximum input range (e.g. +32.767 = 5V;-32.768 = -5V). The input
range is defined as peak voltage, not rms.
Not all software applications detect the supported sampling rates properly. Please make sure to only
use the supported sampling rates as outlined in the specifications section.
3.3 Setup & Sensor supply
As first make sure that the Plug.n.DAQ Lite is enabled for two channel mode in the sound card properties:
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
4. Care and Maintenance
This equipment does not require scheduled or preventive maintenance. If you handle it with care, it will be
a reliable tool.
Should your Plug.n.DAQ Lite require cleaning, use a damp cloth or mild cleaning fluid. Take care not to get
any fluid in or around the connectors.
If your Plug.n.DAQ Lite requires manufacturer inspection and calibration, please contact your vendor.
5. Troubleshooting:
In case you experience problems with your Plug.n.DAQ Lite:
- Check that it is correctly recognized and installed by Windows. A USB- Audio device should be found
under Audio, Video and Game controller in the device manager.
Select Plug.n.DAQ Lite SC as default device under Properties of Sound and Audio devices
- Some application software requires manual selection of the recording and playback device. Please refer to
the manual or help function of your application software.
If you continue to experience problems, please contact your vendor.
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
6. Specifications (typical, fs=48kHz, f=1kHz,-3dBFS unless otherwise noted)
Analog Inputs
Impedance : 1 Mega ohm, single ended BNC
IEPE/ICP* sensor supply : 24V/4mA
Input ranges : +/- 5V (other ranges RFQ)
Mono Version : “left ch. = 5 V; right ch. = 500 mV”
Resolution : 16bit Sigma Delta ADC
Frequency Response : 3.5 Hz - 20 kHz +/-0.15dB
Sample rates : 48 kHz
Overall accuracy : better 1%
Gain error : less than 0.1%
THD : less than 0.01%
Dynamic range : 90 dB(A)
Channel separation : better 90dB
SFDR : -96 dB
Aliasing rejection : better 90dB (to 0.4x fs)
Miscellaneous
PC-interface : USB1.1 & 2.0 compatible
Power supply : USB powered: 5V, 180mA
Temperature range : +0°C to +50°C
Dimensions : 100mm*57mm*26mm
Weight : approx. 100g
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
Getting started with DEWESoft FFT Analyser
For Windows Vista users:
Before you setup the DEWESoft program under Windows vista, please make sure that the at the control
panel; user account the “User Account is turned off”.
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
At the CD ROM media you will find the DEWESoft6.xx_Fullinstaller.exe
Please double click to this file, and select “DEWESoft for Demo mode” than click next.
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
For Modal & FRF Analysis please check the DEWESoft FRF Option.
Please follow the installer until DEWESoft being installed.
After the setup you will find 2 icons on the Desktop; please click to DEWEsoft6x icon.
In the next step it is necessary to define the DAQ device in the analyser software by using “System” and
“Hardware Setup”
Uncheck all “Dewetron Modules” and select the Audio card at the Analog device pop up window.
In case of connected Plug.n.DAQ Lite at the PC, you can select the Plug.n.DAQ Lite.
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
The “Registration status DEMO” does not have any restrictions for further measurements and is timely
unlimited.
In the next step please click to the “Measure” icon; here you can set the sampling rate, and change the
engineering units > “SETUP Set ch.x”
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
Plug.n.DAQ Lite IEPE Sound Card Analyzer & Recorder
Plug.n.DAQ Lite Rev. 1.1 - 12.2011
1 & 2 channel IEPE sound card version
