Roland SP-300 Bedienungsanleitung

SERVICE GUIDE BOOK

Model : SP

Model : SP-

-300

300

Revision 1.20_November 21st, 2003

Roland DG Corporation

Revision Record

Revision No. Date Description of changes

1.0 2003.10.30 First Edition

1.1 2003.11.13 1-4 Head Cleaning_ Ink consumption list has been revised.

1.2 2003.11.21 1-5 Handling_HEAD WASH

SP-300 requires 4 cleaning cartridges for Head Wash.

Chapter 1 : Technology

Contents . . .

1. Product Information

2. Printing Theory

3. Ink

4. Head Cleaning

5. Handling

6. Features

7. Cutting Function

8. Consumables

9. Periodical Maintenance

10. Sensors

• Appearance

SP-

-300

300

-1 : Product Information

1 : Product Information

Dimensions (With stand)

1720 [W] x 770 [D] x 1275 [H] mm

(67-3/4 [W] x 30-3/8 [D] x 50-1/4 [H] in.)

SOMETHING GOOD FOR THE EARTH

Using SP-300 means saving energy

SP-300 is high efficiency product that saves energy and money, and

care for the environment.

Product Information _ continue

• Energy-saving product

SP-300 is an ENERGY STAR certified product.

ENERGY STAR is a government-

backed program helping businesses and

individuals protect the environment

through superior energy efficiency.

• Head (Same Head as ProII series)

• Specification

1. Type : Piezo Inkjet Head

2. 2 Heads / 1 Machine

3. 2 Colors / 1 Head

4. Nozzles : 180 nozzles / 1 line

* Number of nozzles is 1.875 X

compared to FJ-PRO (96 nozzles)

5. Nozzle Pitch / 1 Color : 180dpi

6. Print Width : Approximately 1 inch

K C M Y

Chapter 1

Chapter 1-

-2 : Printing Theory

2 : Printing Theory

180dpi 360dpi

Printing Theory

• Printing Direction

1. Uni-direction

Head Carriage moves in one way to print.

Printing quality is higher because the first pass of dots have

enough time to dry up before the second pass of dots are fired,

which prevents dots to be mixed.

2. Bi-direction

Head Carriage moves in both ways to print.

Printing quality is not so good as uni-direction because the

color order will be reversed and dots could be mixed to each

other by printing the second pass before the first pass dries up.

• Piezo Driving Patterns

There are 5 different Piezo Driving Patterns to fire the dots

depending on . . . . . .

1. Size of a dot

2. Dot-Printing Method,

Fixed sized dot or Variable sized dot.

Piezo Driving Patterns

•FixedSizedDot

1. Small Dot

2. Middle Dot

3. Large Dot

• Variable Sized Dots

1. Variable Sized Dots 1

2. Variable Sized Dots 2

Printing Theory

• Printing Control

Choose best 2 or 3 modes for each media :

High Speed /Standard /High Quality

•You can control printing modes through Roland

COLORIP & Windows Driver.

Roland COLORIP : 3 modes

Windows Driver : 2 modes (High Speed / High Quality)

•Outputting with the best print quality suited for the

media and your purpose

• Resolution

Max. 1440 dpi

Printing Theory

Speed

priority

Speed

priority Quality

priority

Quality

priority

Print Speed :

- Test Conditions

Data : ISO N5A

Size : A2 (593mmx420mm)

Software : RCR & Windows Driver

Rotation : 90

Others : Carriage moves in full width

Printing Theory

Resolution Scan speed Direction Print Time

Bi 2'33"

Uni 5'02"

360x720 500mm/sec Bi 5'28"

720x720 500mm/sec Bi 8'34"

720x1440 500mm/sec Bi 17'07"

720x1440 250mm/sec Bi 39'46"

360x720 1000mm/sec
