Ross RPPW2600 Bedienungsanleitung
Protect yourself and others by observing all safety information, warnings, and cautions.
Failure to comply with instructions could result in personal injury and/or damage to
product or property. Please retain instructions for future reference!
ROSSPOWER RPPW2600
X
RPPW2600
2600 psi (180 bar)
2000 psi (140 bar)
8 L/min
5.5hp
163cc
.
X
X
X
X
X
X
Assemble the hose support(A) to the right side
of the frame using 2 pan head bolts, 4 washers
and 2 nylon hex nuts.
10 | Page
Assemble the wand support(A) to the left side
of the frame using 2 pan head bolts, 4 washers
and 2 nylon hex nuts.
Attach quick-connect to pump inlet.
To do this, screw one side of the quick-connect
to the pump inlet. Next, screw the other side of
the quick-connect to the hose. See illustration
below.
metal gun(B). Pull back the rubber piece(C) to
expose the threaded fitting and screw the 2
pieces together, re-position the rubber piece.
. Next install the pressure hose to the wand
(A)and install the other end of the pressure hose
to the pump outlet(B) as shown below.
Assemble the stainless steel wand (A)and the
!"
!
"#
