COMBAT RUDDER PEDALS
USER GUIDE
CLOSER TO REALITY
WITH SAITEK’S PRO FLIGHT RANGE
YOUR COMPLETE COCKPIT SOLUTION //
FIP
DIGITAL LCD DISPLAY
COMBAT
RUDDER PEDALS
X65F
COMBAT CONTROL SYSTEM
PERFECT PARTNERS
ENGLISH
GEttING StartEd 4
INtroductIoN 6
INStaLLatIoN 6
ENabLING Your coNtroLLEr IN GamES 8
How to tESt aNd adjuSt Your coNtroLLEr 10
Smart tEcHNoLoGY ProGrammING SoftwarE 11
fraNÇaIS
démarraGE 15
INtroductIoN 17
INStaLLatIoN 17
actIvatIoN dE votrE coNtrôLEur daNS LES jEux 19
commENt tEStEr Et réGLEr votrE coNtrôLEur 22
Smart tEcHNoLoGY ProGrammING SoftwarE 23
dEutScH
ErStE ScHrIttE 27
EINfüHruNG 29
SoftwarEINStaLLatIoN 29
aktIvIErEN IHrES coNtroLLErS IN SPIELEN 32
tEStEN uNd EINStELLEN IHrES coNtroLLErS 34
Smart tEcHNoLoGY ProGrammING SoftwarE 35
ItaLIaNo
avvIo 39
INtroduzIoNE 41
INStaLLazIoNE 41
attIvazIoNE dEL coNtroLLEr NEI GIocHI 42
comE vErIfIcarE E rEGoLarE IL coNtroLLEr 45
Smart tEcHNoLoGY ProGrammING SoftwarE 46
ESPañoL
PrImEroS PaSoS 50
INtroduccIóN 52
INStaLacIóN 52
actIvar EL maNdo EN LoS juEGoS 54
cómo Probar Y ajuStar Su maNdo 56
Smart tEcHNoLoGY ProGrammING SoftwarE 57
GEttING StartEd
DURABLE METAL PEDALS
With independent toe brakes
Avec axes de freins de palonnier indépendants
Mit unabhängigen Zehenbremsen
Con freni indipendenti
Con frenos de dedos independientes
RUDDER AXIS
With self-centering mechanism
Avec mécanisme d’autocentrage
Mit selbstzentrierendem Mechanismus
Con meccanismo autocentrante
Con mecanismo autoajustable
ADJUSTABLE TENSION
Adjust the resistance to suit any plane
Ajustez la résistance pour s’adapter à tous les avions
Stellen Sie den Widerstand für Ihr jeweiliges Flugzeug ein
Per regolare la resistenza, in modo da adattarsi a qualsiasi aereo
Ajusta la resistencia para que se adapte a cualquier avión
4
How to adjuSt tHE PEdaL aNGLE
5
ENGLISH
INtroductIoN
The Saitek Pro Flight Combat Rudder Pedals are solid 3-axis rudder pedals designed
to maximize realism by enabling foot control of the rudder and brakes function in ight
simulation PC Games. The Pro Flight Combat Rudder Pedals work with any Saitek PC
product.
fEaturES:
• Independent left and right brake axes
• Rudder axis
• Self-centering with adjustable damping
• Silent, smooth action for optimum control and precision
• Adjustable pedal angle to suit all styles of ying
• High-quality, part metal construction for long life
• Smart Technology (ST) Programming Software allows gamers to congure their
controls to suit their preferred gaming style, and to save the congurations as
personal proles
drIvErS aNd SoftwarE INStaLLatIoN for uSErS of wINdowS® xP, 32- aNd 64-bIt
1. With your computer powered on, close down any programs that are currently running,
and then insert the Installation CD into your CD-ROM drive.
2. When the Introduction Screen appears, click Install Software to continue. If the CD
does not run automatically, select Start from the Windows Taskbar, then Run, then type
D:\Setup.exe into the Run window’s text entry eld, and then click OK (assuming D:\ is
the letter of your CD-ROM drive).
3. When the Welcome screen appears, click Next to continue.
4. After reading the Disclaimer, select the I accept the terms of the Disclaimer option
and click Next to continue.
5. At the Driver Setup screen, if you haven’t already done so, plug the USB cable into
one of your computer’s USB ports, and then click Next.
6
6. At the Driver Setup screen, click Next to test your controller.
7. When the Saitek Controller screen appears, try out all of your controller’s controls to
determine if it is working properly. When you have nished, click OK.
8. In the following Software Setup screen, click Next and follow the on-screen
instructions. At this point you will be asked to install such features as the
Programmable Support for Mouse, Programmable Support for Keyboard and
Programmable Hotkeys (these are important components of the programming
software and are required).
9. If you are asked if Windows can connect to Windows Update to search for software,
choose No, not at this time. Continue to click Next and Finish to accept the installation
until the Registration screen appears.
10. The next window will install the important components of the software. When asked
what to do, choose Install the software automatically (recommended). Do this for the
Keyboard, Mouse and Hotkeys.
11. At the Registration screen, select Check this box to register now and follow the
on-screen instructions, or do not select this option and register later.
12. Upon completion of the installation, you have the option to Run Prole Editor, which
will give you a view of the programming environment. If you do not wish to see the
Prole Editor at this point, uncheck the box and click Finish to complete the installation.
drIvErS aNd SoftwarE INStaLLatIoN for uSErS of wINdowS® vISta aNd 7, 32-
aNd 64-bIt
1. With your computer powered on, close down any programs that are currently running,
and then insert the Installation CD into your CD-ROM drive.
2. When the Introduction Screen appears, click Install Software to continue. If the CD
does not run automatically, select Start from the Windows Taskbar, then Run, then type
D:\Setup.exe into the Run window’s text entry eld, and then click OK (assuming D:\ is
the letter of your CD-ROM drive).
3. When the Welcome screen appears, click Next to continue.
4. After reading the Disclaimer, select the I accept the terms of the Disclaimer option
and click Next to continue.
7
ENGLISH
5. At the Driver Setup screen, if you haven’t already done so, plug the USB cable into
one of your computer’s USB ports and then click Next.
6. At the Driver Setup screen, click Next to test your controller.
7. When the Saitek Controller screen appears, try out all of your controller’s controls to
determine if it is working properly. When you have nished, click OK.
8. In the following Software Setup screen, click Next and a pop-up box will appear
asking if you “want to trust software from Saitek.” Click yes, and then click Next. The
installation will automatically continue until the Registration screen appears.
9. At the Registration screen, select Check this box to register now and follow the on-
screen instructions, or do not select this option and register later.
10. Upon completion of the installation, you have the option to Run Prole Editor,
which will give you a view of the programming environment. If you do not wish to see
the Prole Editor at this point, uncheck the box and click on Finish to complete the
installation.
ENabLING Your coNtroLLEr IN GamES
Most games support game controllers, which you can enable by using the [control]
options menu within the Main Menu of the game itself. If you are having trouble with
this, or are not sure if the game supports game controllers, please refer to the game’s
user manual for assistance.
SEtuP IN fLIGHt SIm x aNd fLIGHt SIm 2004
The Rudder Pedals have three axes, one for the rudder and two foot pedal axes that
are used for the toe brakes. There is also a rotary wheel in the center that allows for the
rudder movement’s tension to be increased and decreased. Due to the way in which
Flight Sim detects the pedals, they need to be correctly congured before you can start
getting the most out of them.
Start by opening FSX and going to Settings > Controls > Control Axes. Select the
Rudder Pedals in Controller Type. Double-click the Event Brake (left axis) and depress
8
the left brake when the Change Assignment window appears. Left toe will appear in the
window, and then click ok. Repeat the process for Brake (right axis) and the right pedal.
Ensure that there is a tick in the Reverse box for both brake axes. Finally, double-click
Rudder Axis and perform the rudder movement, so that the Change Assignment window
detects the rudder axis. These are the only three axes that should be set to the pedals;
if there are any more in the list, delete them using the Delete Joystick Assignment
command.
Now that the axes are set, go to the Calibration window. Select the Rudder Pedals and
then select Advanced Controls. Ensure that the sensitivities for both brake axes are set
to 75-80% and that the null zones are set to 0% for both. The rudder should be set to
50-75% sensitivity with a small null zone of about 5%. Before you load a ight, you will
need to disable Auto Rudder. To do this, go to Settings > Realism and ensure that the
Auto Rudder box does not have a tick inside it.
You should now be good to go. Load up a ight and when the plane is stationary
on the runway, depress the pedal, and then release it. You should see the brake
announcement in the corner of your screen. If all is well, the indicator will appear and
then disappear when the brake is released. If the brakes stay on, go back to Settings
> Controls > Control Axes, and remove the ticks from the reverse box for the brake
pedals.
9
ENGLISH
How to tESt aNd adjuSt Your coNtroLLEr
You can test your controller at any time by Clicking on Start, then Control Panel in
Windows. Look for an icon titled either Game Controllers or Gaming Options (Windows
7 users may have to click Printers and Other Hardware rst).
Open the Game Controllers/Gaming Options window and the Saitek Pro Flight Combat
Rudder pedals should appear. Click on Properties to bring up the test screen. Click on
the Test tab. Moving your rudder pedals should result in a response in this screen; if
there is a response you know that the rudder pedals are functioning correctly.
