SAITEK P3000

WIRELESS PAD

USER MANUAL

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 1

1 2 Triggers

2 Shift Button

3 6 Fire Buttons

4 8-way D-Pad

5 Analog/Digital

Buttons

6 2 Analog Joysticks

7 Docking Station

8 2 Power Packs

Digital Mode Indicator

Analog Mode Indicator

Low Battery Warning

Battery Charge Level

12 Gâchettes 2 Triggers 2 Trigger 2 Gatillos

2Touche Shift Shift-Funktion Tasto-Shift Tecla de Mayús

36 Boutons de Tir 6 Tasten 6 Pulsanti 6 Botones

4Pavé Directionnel 8-Wege D-Pad Pulsantiera D-Pad Teclado en D 8 vias

62 Sticks Analogique 2 Analoge Joysticks 2 Joystick Analogici 2 Palancas de MandoAnalógicas

7Station D’accueil Docking-Ladestation Docking Station Estatción de atraque

82 Packs de Batteries 2 Power Pack 2 Pacchi Batterie 2 Unidades de Alimentación

AIndicateur de Mode Digital Digital ModusAnzeige Indicatore di modalità digitale Indicador de modo digital

BIndicateur de Mode Analogique Analog Modus Anzeige Indicatore di modalità analogica Indicador de modo analógico

CAttention Batterie faible Warnung niedriger Batterienstatus Avvertimento di batteria scarica Indicador de batería baja.

DNiveau de charge de la batterie BatterienstatusAnzeige Livello di carica della batteria Nivel de carga de la batería

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 2

GETTING STARTED

In order for this product to function correctly please install the drivers on the CD supplied

with this product.

The First Time You Use Your P3000 Wireless Pad

In order for the P3000 Pad to work you need to fully charge the batteries before you play. To obtain

a full charge, place one of the battery cells into the front of the docking station (after you have

completed the installation and with the USB cable connected and your PC switched on) and wait

for approximately one hour, or until the red Charge light switches off, indicating that the battery is

now fully charged. To recharge the battery after gameplay, simply repeat the procedure. The

battery will usually deliver a minimum of 8 hours gameplay after a full charge. The green Ready

light on the docking station indicates that the Docking Station is ready to communicate with the

pad.

Note: Remember you can play continuously without having to wait to recharge the batteries. Just

charge one of the battery cells in the docking station while you play with the other.

INSTALLATION FOR USERS OF WINDOWS® XP

A) Drivers Only For Typical Users

The software on the CD supplied with this product has been thoroughly tested and complies with

all Microsoft standards. However, we recommend that prior to installing any 3rd party software you

create a restore point to return to should you encounter any difficulties.

Windows®XP users can do this by clicking on Start followed by Programs, then Accessories,

System Tools and finally on System Restore. In the window that appears select Create a restore

point and then click on Next. You will be prompted to supply a name for this set-up.

Should you then encounter any difficulties during the installation process you can follow the same

path to restore your PC to its pre-installed state.

1 With your computer switched on, close down any programs that are currently running and

insert the Saitek Smart Technology CD into your CD-ROM drive.

2 When the Introduction Screen appears, click Install Software to continue.

3 When the Welcome screen appears, click Next to continue. (If the CD does not run

automatically, select Start from the Windows® Taskbar, then Run and type D:\Setup.exe and

click OK - where D:\ is letter of your CD-ROM drive).

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 3

4 After reading the Disclaimer, select the I accept the terms of the Disclaimer option and click

Next to continue.

5 At the Driver Setup screen, plug in your controller and click on Next.

6 At the Driver Setup screen, click Next to test your controller.

7 When the Saitek Controller screen appears, try out all your controller’s buttons and controls

to show that it is working properly. When you have finished, click OK.

8 At the Software Setup screen, select Do not install the SST Programming Software and

click Next. The Programming Software can be installed at a later date by following instruction

(B). below

9 At the Registration screen, select Check this box to register now and follow the on-screen

instructions, or you can choose to select this option later.

10 Click on Finish to complete the installation.

B) Drivers and Programming Software For Advanced Users

1 Follow points 1 – 7 of the install procedure in A), then at the Software Setup screen, select

Install the SST Programming Software and click Next.

2 In the following Software Setup screen, click Next and follow the on-screen instructions. At

this point you will be asked to install such features as the Saitek Magic Mouse,HID-

compliant mouse, Saitek Magic Keyboard and HID Keyboard Device (these are what XP

calls the various elements of your Saitek controller). Continue to click on Next and Finish to

accept the installation until the Registration screen appears.

3 At the Registration screen, select Check this box to register now and follow the on-screen

instructions, or do not select this option and register later.

4 Upon completion of the installation, you have the option to Run Profile Editor, which will give

you a view of the 3D programming environment. If you do not wish to see the Profile Editor at

this point, just uncheck the box and click on Finish to complete the installation.

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 4

INSTALLATION FOR USERS OF WINDOWS® 2000

A) Drivers Only For Typical Users

1 With your computer switched on, close down any programs that are currently running and

insert the Saitek Smart Technology CD into your CD-ROM drive.

2 When the Introduction Screen appears, click Install Software to continue.

3 When the Welcome screen appears, click Next to continue. (If the CD does not run

automatically, select Start from the Windows® Taskbar, then Run and type D:\Setup.exe and

click OK - where D:\ is letter of your CD-ROM drive).

4 After reading the Disclaimer, select the I accept the terms of the Disclaimer option and click

Next to continue.

5 At the Device Driver Installation screen, click on Next and follow the on-screen instructions.

6 When prompted, plug your controller’s USB connector into your computer, then click on

Configure.

7 When the Controller Properties screen appears, click Next to view the Test screen.

8 Now try out all your controller’s buttons and controls to show that it is working properly. When

you have finished, click OK.

9 At the Programming Software screen, select Typical User and click Next.

10 At the Registration screen, select Register and follow the on-screen instructions or select

11 Click on Finish to complete the installation.

B) Drivers and Programming Software For Advanced Users

1 Follow points 1 – 7 of the install procedure in A), then at the Programming Software screen,

select Advanced User and click Next.

2 At the Programmable Controller Drivers screen, click Update and follow the on-screen

instructions.

3 Then at the Installation of programming software successful screen, click Next.

4 At the Registration screen, select Register and follow the on-screen instructions or select

5 Upon completion of the installation, you have the option to Run Profile Editor, which will give

you a view of the 3D programming environment. If you do not wish to see the Profile Editor at

this point, just uncheck the box and click on Finish to complete the installation.

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 5

INSTALLATION FOR USERS OF WINDOWS® 98 AND ME

A) Drivers Only For Typical Users

1 With your computer switched on, close down any programs that are currently running and

insert the Saitek Smart Technology CD into your CD-ROM drive.

2 When the Introduction Screen appears, click Install Software to continue.

3 When the Welcome screen appears, click Next to continue. (If the CD does not run

automatically, select Start from the Windows® Taskbar, then Run and type D:\Setup.exe and

click OK).

4 After reading and accepting the Disclaimer, click Next to continue.

Note: For your controller to work, you must have a minimum of Microsoft® DirectX® 8.1 installed

on your computer. The installer will automatically recognize if this software needs to be added, and

will allow you to install it directly from the Saitek Product Companion CD, if necessary.

If you are asked to install Microsoft® DirectX® 8.1, click Install and follow the on-screen

instructions, and then restart your computer when prompted. Make sure that you leave the Saitek

CD in the drive when restarting. After this software has been installed, you will automatically be

taken to the installation to continue with the next step.

5 Follow the on-screen instructions and select Yes, I want to restart my computer now when

prompted.

6 After the restart, at the Device Driver Installation screen, click on Next and follow the on-

screen instructions.

7 When prompted, plug your USB connector into your computer.

8 When the Controller Properties screen appears, click Next to view the Test Screen.

9 Now try out all your controller buttons and controls to show that it is working properly. When

you have finished, click OK.

10 At the Programming Software screen, select Typical User and click Next.

11 At the Registration screen, select Register my Saitek controller online, click Next and

follow the on-screen instructions or select Register Later and click Next.

12 Click on Finish to complete the installation.

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 6

B) Drivers and Programming Software For Advanced Users

1 Follow points 1 – 8 of the install procedure in A), then at the Programming Software screen,

select Advanced User and click Next.

2 At the Programmable Controller Drivers screen, click Update and follow the on-screen

instructions. At this point you will be asked to insert your Windows® CD, however, DO NOT do

this, just click on OK. At the next screen, type C:\windows\system into the prompt and click

OK and follow the on-screen instructions.

3 At the Installation of programming software successful screen, click Next.

4 At the Registration screen, select Register my Saitek controller online, click Next and

follow the on-screen instructions or select Register Later and click Next.

5 Upon completion of the installation, you have the option to Run Profile Editor, which will give

you a view of the 3D programming environment. If you do not wish to see the Profile Editor at

this point, just uncheck the box and click on Finish to complete the installation.

IMPORTANT INFORMATION

A Word on Driver Updates

From time to time there may be updates to the driver and programming software for this product.

You can check for the latest software updates by visiting the Saitek website and clicking on

Downloads. A drop down menu will appear. Select Drivers and Software.

For Windows® XP users; Dynamic updates:

You can check for Driver modifications using Windows update. Click on Start on the bottom left

hand corner of your monitor and then select Windows Update from the menu. Click on Driver

Updates then select from any of the update options that appear in the centre of the window. When

you have selected the relevant file to download go to the left hand side of the window and select

Review and Install Updates. Finally click on Install Now from the centre section.

P3000 Micro RoW Manual.qxd 30/01/2004 08:50 Page 7

How to Test your Controller

• You can do this at any time by Clicking on Start, then Settings and selecting Control Panel

in Windows (XP users may only need to click on Start and then Control Panel)

• Look for an icon called either Game Controllers or Gaming Options (XP users may have to

click Printers and Other Hardware first).

• Open the Game Controllers/Gaming Options window then the name your controller should

show up.

• Click on Properties and this will bring up the test screen.

• Moving your controller and pressing the buttons should result in a response in this screen; if

it's responding in there then you know that the controller is okay.

Enabling Your Controller in Game

Most games support game controllers, which you can enable by using a [control] options menu

within the Main Menu of the game itself.

If you are having trouble working out how to do this or if you're unsure whether the game being

used supports game controllers, please refer to the user manual for that game for more help.

NOTE: Even if the game you are using does not support game controllers, it is possible to make

the controller work in that game using the Saitek Smart Technology programming software (only

installed if you chose to be an Advanced User when installing). Using the programming software

allows you to program your controller with keyboard and mouse commands, enabling it to work in

those games that only have support for keyboards and mice. For help using this powerful pro-

gramming software, consult the Programming Your Saitek Controller with Saitek Smart Technology

Programming Software section in this manual.
