Samson Expedition Express Bedienungsanleitung

Owner's Manual

v1.1

Samson Technologies Corp.

45 Gilpin Avenue

Hauppauge, New York 11788-8816

Phone: 1-800-3-SAMSON (1-800-372-6766)

Fax: 631-784-2201

www.samsontech.com

The Bluetooth® word mark and logos are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such marks by Samson Technologies is

under license. Other trademarks and trade names are those of their respective

owners.”

Important Safety Information

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK) AS THERE ARE NO

USER-SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

This lightning ﬂash with arrowhead symbol within an equilateral triangle

is intended to alert the user to the presence of non-insulated “danger-

ous voltage” within the product’s enclosure that may be of sufﬁcient

magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance in-

structions in the literature accompanying the appliance.

If you want to dispose this product, do not mix it with general household waste. There is a

separate collection system for used electronic products in accordance with legislation that

requires proper treatment, recovery and recycling.

Private household in the 25 member states of the EU, in Switzerland and Norway may return their used

electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar

new one).

For Countries not mentioned above, please contact your local authorities for a correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and

recycling and thus prevent potential negative effects on the environment and human health.

AVIS

RISQUE DE CHOC ÉLECTRONIQUE -

NE PAS OUVRIR

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation open-

ings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources

such as radiators, heat registers,

stoves, or other apparatus (including

ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of

the polarized or grounding type plug.

A polarized plug has two blades with

one wider than the other. A grounding

type plug has two blades and a third

grounding prong. The wide blade or

the third prong are provided for your

safety. If the provided plug does not

ﬁt into your outlet, consult an electri-

cian for replacement of the obsolete

outlet.

10. Protect the power cord from being

walked on or pinched particularly at

the plugs, convenience receptacles,

and at the point where they exit from

the apparatus.

11. Only use attachments/accessories

speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod,

bracket, or table speciﬁed by the

manufacturer, or sold with the ap-

paratus. When a cart is used, use

caution when moving the cart/appara-

tus combination to avoid injury from

tip-over.

13. Unplug the apparatus during lighten-

ing storms or when unused for long

periods of time.

14. Refer all servicing to qualiﬁed

personnel. Service is required when

the apparatus has been damaged in

any way, such as power supply cord

or plug is damaged, liquid has been

spilled or objects have fallen into the

apparatus has been exposed to rain or

moisture, does not operate normally,

or has been dropped.

15. This appliance shall not be exposed

to dripping or splashing water and

that no object ﬁlled with liquid such

as vases shall be placed on the ap-

paratus.

16. Caution-to prevent electrical shock,

match wide blade plug wide slot fully

insert.

17. Please keep a good ventilation envi-

ronment around the entire unit.

18. To prevent injury, this apparatus must

be securely attached to the stand

in accordance with the installation

instructions.

19. WARNING: The battery (battery or

batteries or battery pack) shall not

be exposed to excessive heat such as

sunshine, ﬁre or the like.

20. CAUTION: Danger of explosion if bat-

tery is incorrectly replaced. Replace

only with the same or equivalent type.

Important Safety Information

FCC Notice

1. This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference

that may cause undesired operation.

2. Changes or modiﬁcations not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

FCC Statement

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harm-

ful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be de-

termined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

RF Warning Statement

The device has been evaluated to meet general RF exposure requirement. The

device can be used in portable exposure condition without restriction.

This device complies with RSS-310 of Industry Canada. Operation is subject to

the condition that this device does not cause harmful interference.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . .7

Rear Panel Features . . . . . . . . . . . . . . . . . . . . 8

Quick Start . . . . . . . . . . . . . . . . . . . . . . . . 9

Pairing with a

Bluetooth

®device . . . . . . . . . . . . . 10

Charging the Battery . . . . . . . . . . . . . . . . . . . 11

Speaker Placement . . . . . . . . . . . . . . . . . . . 12

Avoiding Feedback. . . . . . . . . . . . . . . . . . . . 13

Making Connections . . . . . . . . . . . . . . . . . . . 14

Specifications . . . . . . . . . . . . . . . . . . . . . . 15

Introduction

Thank you for purchasing the Expedition Express battery-powered portable

sound system, featuring wireless Bluetooth®connectivity, to stream audio from

your smart phone, tablet, or computer. The Expedition Express is a complete

all-in-one solution providing the flexibility of a three-channel mixer (with inputs

for a microphone, instrument, and line level devices), a line output for linking

multiple speakers, and bass and treble tone controls.

Lightweight and compact, the Expedition Express weighs less than 10lbs mak-

ing it an excellent complement to any mobile speaker situation. The internal

battery provides eight hours of audio on a full charge. The Expedition Express

can also be powered by the included AC adaptor for continuous audio.

Whether you are looking for a sound system for use outdoors, in the classroom,

for karaoke, for presentations, or performing live music, the Expedition Express

provides high quality, portable audio in a small self-powered package.

We recommend you keep the following records for reference, as well as a copy

of your sales receipt.

Serial number: ____________________________________________

Date of purchase: __________________________________________

Dealer name: _____________________________________________

With proper care and maintenance, your Expedition Express will operate

trouble-free for many years. Should your speaker ever require servicing, a

Return Authorization (RA) number must be obtained before shipping your unit

to Samson. Without this number, the unit will not be accepted. Please call

Samson at 1-800-3SAMSON (1-800-372-6766) for an RA number prior to

shipping your unit. Please retain the original packing materials and, if possible,

return the unit in its original carton. If your Expedition Express was purchased

outside of the United States, contact your local distributor for warranty details

and service information.

Rear Panel Features

1. VOL (Ch1) - Used to control

the level of the Mic/Line

input.

2. MIC/LINE - Use this XLR/1⁄4"

input for microphone or a line

signal.

3. VOL (Ch2) - Used to control

the level of the line input.

4. INSTRUMENT Input - ¼" input

used to connect instrument or

line level signals.

5. VOL (Ch3) - Used to control

the level of the Bluetooth®

and MP3 inputs.

6. MP3 IN - Connect a line level

device using a 3.5mm audio

cable.

7. Pairing Button - Press this button to enable discoverable mode to pair with

a Bluetooth audio device.

8. Pairing Indicator - Displays the Bluetooth status of the Expedition Express

system.

9. TREBLE - Controls the high frequency tone of the entire system.

10. BASS - Controls the low frequency tone of the entire system.

11. Power - Switches on the main power.

12. LINE OUT - ¼" output connector to link multiple Expedition Express sys-

tems together.

13. POWER Indicator - Lights red when the audio power switch is turned on.

14. DC IN - Connect the supplied power adapter here.

15. Battery Indicator - Displays the status of the battery charge level.

Quick Start

Follow these steps below to quickly get started using your Expedition Express

portable sound system.

• Set the Expedition Express's power switch to the OFF position, and fully

turn all of the VOL controls counterclockwise to 0.

• If an outlet is available, connect the included power adaptor to the DC IN of

the speaker, and plug it into an AC socket.

• Connect a microphone using a standard XLR cable, instrument and line

level equipment using a 1⁄4" instrument cable, or portable audio device

using a 1⁄8" cable.

• Switch on the Expedition Express power.

• While speaking into the microphone, playing the instrument, or playing

music from a line level audio source, slowly raise the channel VOL until you

have reached the desired level.

NOTE: If not using the channel 1 input, turn the VOL control all the way down to

keep out any unwanted noise.

Using EQ

The Expedition Express feature a 2-band equalizer allowing you to adjust the

systems overall high and low frequencies. The system’s frequency response is

flat when the knobs are in the vertical or "12:00" position. Small movements of

the controls can make a big difference. Turning the controls all the way up can

cause distortion. Use your ears when adjusting the EQ to fit your application.

We have provided two example settings to help you get started fine tuning your

system.

Setting the EQ for Music

If you are using the Expedition Express for music

playback, turn up the BASS and TREBLE slightly

to produce a “hi-ﬁ” frequency response that ac-

centuates the low and high ranges.

Setting the EQ for Vocal

If you are using your Expedition Express with a

microphone for speech only, you can reduce the

BASS and raise the TREBLE slightly, which will

produce a frequency response that accentuates

the vocal range.

Pairing with a

Bluetooth

®device

Bluetooth®is a wireless communication technology that allows for connectivity

between a wide range of devices. The Expedition Express uses Bluetooth to

stream high quality audio from your Bluetooth enabled device without the need for

connecting any cables. In order for your device to work with the Expedition Express

it must first be paired.

1. Turn all three channel VOL controls all down counterclockwise to 0.

2. With the Expedition Express and your Bluetooth device powered on; press

the PAIR button on the rear panel of the Expedition Express speaker to

make the speaker discoverable. The Bluetooth indicator will slowly flash

blue.

3. In the settings of your Bluetooth device, set it to “discover” available

devices.

4. From the Bluetooth device list, select the "Samson Express" device.

5. If your device asks for a passkey, enter digits 0000 (four zeros) and press

OK. Some devices may also ask you to accept the connection.

6. As the Expedition Express is connecting

to your device, the Bluetooth indicator will

quickly flash blue.

7. The Expedition Express speaker indicates

that pairing is complete when the indica-

tor turns steady blue. You can now stream

audio from your device to the Expedition

Express speakers.

8. With the volume control on your Bluetooth

device turned up, play some music, and

slowly raise the Expedition Express channel

3 VOL control until you have reached the

desired level.

Andere Handbücher für Expedition Express

Inhaltsverzeichnis

Andere Samson Sprecher Handbücher

Samson

Samson StudioDock 3i Bedienungsanleitung

Samson

Samson RL112A Bedienungsanleitung

Samson

Samson Studio GT Bedienungsanleitung

Samson

Samson Expedition XP800 Bedienungsanleitung

Samson

Samson Expedition EX10 Bedienungsanleitung

Samson

Samson dB500 Bedienungsanleitung

Samson

Samson Expedition XP300 Bedienungsanleitung

Samson

Samson Resolv 50a Bedienungsanleitung

Samson

Samson EXPIDETION XP25I Bedienungsanleitung

Samson

Samson Resound RS12M Bedienungsanleitung

Samson

Samson Studio Reference Monitor System Resolv 40a Bedienungsanleitung

Samson

Samson DMS80 Bedienungsanleitung

Samson

Samson RESOLV5e Bedienungsanleitung

Samson

Samson Rubicon R8a Bedienungsanleitung

Samson

Samson MEDIAONE BT3 Bedienungsanleitung

Samson

Samson EXPEDITION XP150 Bedienungsanleitung

Samson

Samson RSX110 Bedienungsanleitung

Samson

Samson XP308i Bedienungsanleitung

Samson

Samson Resolv A5 Bedienungsanleitung

Samson

Samson dB300a Bedienungsanleitung

Samson

Samson dB300 Bedienungsanleitung

Samson

Samson EXPEDITION XP40i Bedienungsanleitung

Samson

Samson Expedition XP800 Bedienungsanleitung

Samson

Samson Expedition XP106 Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
