Samsung SMX-K40BP Bedienungsanleitung

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please

www.samsung.com/register

SMX-K40BP/SMX-K40SP/SMX-K40LP

SMX-K44BP/SMX-K44SP/SMX-K44LP

SMX-K45BP/SMX-K45SP/SMX-K45LP

Memory Camcorder

user manual

key features of your memory camcorder

High-resolution colour widescreen LCD (2.7” WIDE TFT LCD)

Samsung memory camcorder utilizes a 2.7-inch 230k pixel Widescreen LCD which

allows bright and clear monitoring. In addition, the LCD Enhancer adjusts colour and

brightness to the screen lighting conditions for better monitoring under strong sunlight.

H.264/AVC (MPEG4 part 10/Advanced Video Coding) encoding

Latest video compression technology, H.264, uses a high compression rate to sharply

increase the recordable time with the same size storage.

Simple & easy user interface

Designed to provide optimized and easy use with an ergonomic design.

An improved Graphics User Interface offers a new and fresh look as well as an easy operation.

SSD (Solid State Drive) adopted as built-in memory (16GB (SMX-K44 only), 32GB (SMX-K45 only))

SSD based on ﬂash memory has been adopted as built-in memory for the camcorder. SSD helps the camcorder boot, read

data and operate the software much faster than normal HDD (Hard Disk Drives). Also, SSD is very stable, durable and makes

less noise while in operation. It is environment-friendly because low electric power is required.

User-friendly functions

User-friendly EASY Q optimises your memory camcorder to the recording conditions

automatically, providing beginners with the best performance.

Twice the memory options (16GB (SMX-K44 only), 32GB (SMX-K45 only))

The memory camcorder’s external memory slot accepts high capacity SDHC cards.

Play and transfer videos quickly and easily using the memory type of your choice.

In addition to this slot, the memory camcorder has built-in memory.

High-resolution image through Mobile DNIe

The Samsung memory camcorder has 3DNR (3-dimensional noise reduction), high-sensitivity colour expression

(intelligent colour expression), High performance Anti-Shake (OIS: Optical Image Stabiliser), and automatic face

detection features.

Capture visions farther than the eye can see : 52x Optical Power Zoom, 65x Intelli-Zoom, and 2200x Digital Zoom

Samsung's powerful optical zoom lenses bring the world closer without losing

image quality. In addition, Digital Zoom Interpolation enables clearer digital zooming,

with less distortion than previous types of digital zooms.

OFF

MODE

ii_English

Capturing photo image

This function captures a moving subject instantly and saves the scene as a photo image.

Time lapse recording catches the moment

You can record a long scene in short intervals. Record artistic, documentary videos

including the passage of clouds, blooming ﬂowers etc. Use this function to make

UCC (User Created Contents) videos, educational programmes or for other purposes.

Direct upload of your videos to the web!

The built-in editing Intelli-studio software installs directly from this camcorder to your

PC, enabling convenient connection only with a USB cable. Intelli-studio also allows

direct uploading of your contents to YouTube or Flickr. Sharing the contents with your friends is simpler than ever before.

Make a digest of your video with Storyboard printing!

This function captures 16 still images arbitrarily from the selected video and saves them into

the storage media. It presents a quick overview of your video, helping you to understand

the overall topic.

Make all your recordings with a simple VIEW button!

This function provides the preview of storyboard to be printed, which gives you digest of the

recorded video without viewing the whole sequence of it.

SD-quality images to HD-quality images, using up-scaling function!

You can enjoy high ﬁdelity viewing of your video recorded in SD quality if your TV

supports HD quality displaying by set the HD OUTPUT switch on the side of your

camcorder to “ON”. This function is used when up-converting recorded

SD-quality images to HD-quality images for playback on a HD TV.

OFF

MODE

{

vmm

tvkl

Off

Normal View

1/100:00:55

Normal View

0:00:550:00:55

Normal View

Photo Move Play

Date View

1/10

0:10:31

Date View

1/10

Photo Date Play

01/JAN/2009

iSCENE View

1/10

0:02:03

iSCENE View

1/10

Photo iSCENE Play

Auto

English_iii

Various methods for playback as you want with Multi View Option!

Multi View Option provides sorting thumbnails of recorded videos and photos by

order of recording, recorded date, and the iSCENE mode which can be used for

playback at your preferred order.

safety warnings

What the icons and signs in this user manual mean :

WARNING

Death or risk of serious personal injury.

CAUTION

Potential risk of personal injury or material damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or personal injury when using your camcorder,

follow these basic safety precautions:

Hints or referential pages that may be helpful when operating the camcorder.

These warning signs are here to prevent injury to you and others.

Please follow them explicitly. After reading this section, keep it in a safe place for future reference.

precautions

Warning!

This camcorder should always be connected to an AC outlet with a protective grounding connection.

Batteries should not be exposed to excessive heat such as sunshine, ﬁre or similar.

•

Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket,

therefore the mains plug shall be readily operable.

iv_English

BEFORE USING THIS CAMCORDER

This camcorder is designed exclusively for use with the high-capacity built-in memory (16GB (SMX-K44

only), (32GB (SMX-K45 only)) and an external memory card.

This camcorder records video in H.264/AVC (MPEG4 part 10/Advanced Video Coding) format compliant

with the Standard resolution (SD-VIDEO) format.

Please note that this camcorder is not compatible with other digital video formats.

Before recording important video, make a trial recording.

- Play back your trial recording to make sure the video and audio have been recorded properly.

The recorded contents cannot be compensated for:

- Samsung cannot compensate for any damages caused when recording is not made normally or recorded

contents cannot be played back because of a defect in the camcorder or memory card.

Also, Samsung cannot be held responsible for your recorded video and audio.

Recorded contents may be lost due to an error when handling this camcorder or memory card, etc. Samsung

shall not be held responsible for the loss of recorded contents, and cannot compensate for any damages.

Make a backup of important recorded data.

- Protect your important recorded data by copying the ﬁles to a PC. We recommend copying the data to your

PC or other recording media for storage. Refer to the software installation and USB connection guide.

- Data recorded on a card in this camcorder from other digital/analogue media or devices is protected by the

Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly

recommended that you obtain permission beforehand.

•

IMPORTANT NOTE

Handle the liquid crystal display (LCD) with care:

- The LCD is a very delicate display device: Do not press its surface with excessive force, hit it or prick it with a

sharp object.

- If you push the LCD surface, display unevenness may occur. If unevenness does not disappear, turn the

camcorder off, wait for a few moments, and then turn it on again.

- Do not place the camcorder with the open LCD screen down.

- Close the LCD monitor when not using the camcorder.

•

important information on use

English_v

vi_English

Liquid crystal display:

- The LCD screen is a product of high precision technology. Out of the total pixels (approx. 230,000 pixels of an LCD

monitor ), 0.01% or less pixels may be out (black dots) or may remain lit as coloured dots (red, blue, and green).

This shows the limitations of the current technology, and does not indicate a fault that will interfere with recording.

- The LCD screen will be slightly dimmer than usual when the camcorder is at low temperature, as in cold areas, or

right after the power is turned on. Normal brightness will be restored when the temperature inside the camcorder

rises. Note that this will have no effect on the image in a storage media, so there is no cause for concern.

Hold the camcorder correctly:

- Do not hold the camcorder by the LCD monitor when lifting it: the LCD monitor could detach and the

camcorder may fall.

Do not subject the camcorder to impact:

- This camcorder is a precision machine. Take great care that you do not strike it against a hard object or let it fall.

- Do not use the camcorder on a tripod in a place where it is subject to severe vibrations or impact.

No sand or dust!

- Fine sand or dust entering the camcorder or AC power adaptor could cause malfunctions or defects.

No water or oil!

- Water or oil entering the camcorder or AC power adaptor could cause electric shock, malfunctions or defects.

Heat on surface of product:

- The surface of the camcorder will be slightly warm when used, but this does not indicate a fault.

Be careful of unusual ambient temperature:

- Using the camcorder in a place where the temperature is over 104°F (40°C) or lower than 32°F (0°C) may result

in abnormal recording/playback.

- Do not leave the camcorder on a beach or in a closed vehicle where the temperature is very high for a long

time: This could cause a malfunction.

Do not point directly at the sun:

- If direct sunlight strikes the lens, the camcorder could malfunction or a ﬁre could occur.

- Do not leave the camcorder with the LCD screen exposed to direct sunlight: This could cause a malfunction.

Do not use the camcorder near TV or radio:

- This could cause noise to appear on the TV screen or in radio broadcasts.

Do not use the camcorder near strong radio waves or magnetism:

- If the camcorder is used near strong radio waves or magnetism, such as near a radio transmitter tower or

electric appliances, it may cause distortion to the video and audio being recorded. During playback of normally

recorded video and audio, noise may also be present in picture and sound.

•

important information on use

English_vii

Do not expose the camcorder to soot or steam:

- Thick soot or steam could damage the camcorder case or cause a malfunction.

Do not use the camcorder near corrosive gas:

- If the camcorder is used in a place where there is dense exhaust gas generated by gasoline or diesel engines,

or corrosive gas such as hydrogen sulphide, the external or internal terminals could corrode, disabling normal

operation, or the battery connection terminals could corrode, so that power will not turn on.

Do not use the camcorder near an ultrasonic humidiﬁer:

- Calcium and other chemicals dissolved in water could scatter in the air, and white particles could adhere to the

optical head of the camcorder, which could cause it to operate abnormally.

Do not clean the camcorder body with benzene or thinner:

- The coating of exterior could peel off or the case surface could deteriorate.

- When using a chemical cleaning cloth, follow the instructions.

Keep a memory card out of reach of children to prevent swallowing.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket,

therefore the mains plug shall be readily operable.

•

ABOUT THIS USER MANUAL

Thank you for purchasing this Samsung Camcorder. Please read this user manual carefully before you use

the camcorder and keep it handy for future reference. Should your camcorder fail to operate correctly, refer to

Troubleshooting.

The 'SMX-K44'and 'SMX-K45' have a 16GB and 32GB built-in memory respectively but also use memory cards.

The 'SMX-K40' does not have built-in memory and uses memory cards exclusively.

Although some features of 'SMX-K40', 'SMX-K44' and 'SMX-K45' are different, they operate in the same way.

Illustrations of model SMX-K40 are used in this user manual.

The displays in this user manual may not be exactly the same as those you see on the LCD screen.

Designs and speciﬁcations of storage media and other accessories are subject to change without any notice.

In this user manual’s function descriptions, the icon on the on-screen display section means that it will appear on

the screen when you set the corresponding function.

Ex) Submenu item of “Video Resolution” ➥page 55

(If set, corresponding icon ( ) will appear on the screen.)

Descriptions of the “built-in memory” in this user manual apply only to the following models: SMX-K44(16GB),

SMX-K45(32GB)

•

item contents on-screen display

"TV Super Fine" Videos recorded in 720x576(50i) resolution at super-ﬁne image quality.

viii_English

NOTES REGARDING TRADEMARK

All the trade names and registered trademarks mentioned in this manual or other documentation provided with

your Samsung product are trademarks or registered trademarks of their respective holders.

Windows®is registered trademark or trademark of Microsoft Corporation, registered in the United States and other

countries.

Macintosh®is trademark of Apple Inc.

YouTube®is a trademark of Google Inc.

Flickr®is a trademark of Yahoo! Inc.

All the other product names mentioned herein may be the trademark or registered trademarks of their respective

companies.

Furthermore, “TM” and “®” are not mentioned in each case in this manual.

•

important information on use

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.

charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.

To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these

items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government ofﬁce,

for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed

of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb

indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.

If batteries are not properly disposed of, these substances can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste

and recycle them through your local, free battery return system.

English_ix

precautions during use

WARNING

Do not overload outlets or

extension cords as this may

result in abnormal heat or ﬁre.

Using the camcorder at

temperatures over 140°F (60°

C) may result in ﬁre. Keeping the

battery at a high temperature

may cause an explosion.

~GGGG{

{

Do not allow water or metal

and inﬂammable matter to

enter the camcorder or AC

power adaptor. Doing so may

pose a ﬁre hazard.

~GGGG{

{

No sand or dust! Fine sand or

dust entering the camcorder

or AC power adaptor could

cause malfunctions or defects.

SAND

~GGGG{

{

The safety precautions illustrated below are to prevent personal injury or material damage. Heed all instructions carefully.

Unplug from power supply.Do not touch product.Prohibited action.WARNING

Death or risk of serious

personal injury.

This precaution must be kept.Do not disassemble product.CAUTION

Means that there is a

potential risk of personal

injury or material damage.

Do not bend the power-cord or

damage the AC power adaptor

by pressing on it with a heavy

object. There may be a risk of

ﬁre or electric shock.

Do not disconnect the AC

adaptor by pulling on its

power-cord, as this could

damage the power-cord.

Do not aim the LCD screen

directly into the sun. Doing so

could cause eye injuries, as

well as lead to malfunctioning

of internal parts of the

product.

~GGGG{

{

No oil! Oil entering the

camcorder or AC power

adaptor could cause electric

shock, malfunctions or

defects.

~GGGG{

{

x_English

Do not plug or unplug the power cord

with wet hands. There is a risk of electric

shock.

Do not attempt to disassemble, repair, or

reform the camcorder or the AC adaptor to

avoid a risk of ﬁre or electric shock.

Keep the power-cord unplugged when

not in use or during lightning storms to

prevent ﬁre hazard.

When cleaning the AC adaptor, unplug

the power-cord to avoid a risk of a

malfunction or electric shock.

If the camcorder makes an abnormal sound,

or smells or smokes, unplug the power-cord

immediately and request service from a Samsung

service centre. There is a risk of ﬁre or personal

injury.

Do not use the AC adaptor if it has

damaged, split or broken cords or wires.

Doing so may cause ﬁre or electric shock.

Do not connect the AC adaptor unless the

plug can be fully inserted with no part of

the blades exposed.

Keep the used lithium battery or memory

card out of the reach of children. If the

lithium battery or memory card is swallowed

by children, consult a physician immediately.

Keep the camcorder away from water

when used near the beach or pool or

when it rains. There is a risk of malfunction

or electric shock.

If the camcorder malfunctions, immediately

detach the AC adaptor or battery from the

camcorder immediately to avoid ﬁre or injury.

precautions during use

Do not dispose of battery pack in a ﬁre as

it may explode.

Never use cleaning ﬂuid or similar

chemicals. Do not spray cleaners directly

on the camcorder.

~GGGG{

{

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Camcorder Handbücher

Samsung

Samsung VP-D24 Betriebsanleitung

Samsung

Samsung SCD103/D105 Einrichtungshandbuch

Samsung

Samsung VM-C1400 Bedienungsanleitung

Samsung

Samsung HMX-M20BN Bedienungsanleitung

Samsung

Samsung SC-M102 Bedienungsanleitung

Samsung

Samsung SCD23 Betriebsanleitung

Samsung

Samsung SC-D963 Betriebsanleitung

Samsung

Samsung VP-D655I Betriebsanleitung

Samsung

Samsung VP-D461B Betriebsanleitung

Samsung

Samsung SC MX20 - Camcorder - 680 KP Bedienungsanleitung

Samsung

Samsung VP-DC171I Betriebsanleitung

Samsung

Samsung VP-W80U Einrichtungshandbuch

Samsung

Samsung VP-D30 Bedienungsanleitung

Samsung

Samsung SC MX10 - Camcorder - 680 KP Bedienungsanleitung

Samsung

Samsung VP-D301 Bedienungsanleitung

Samsung

Samsung SC-MX10AU Bedienungsanleitung

Samsung

Samsung HMX-H100N Bedienungsanleitung

Samsung

Samsung VP-D903D Betriebsanleitung

Samsung

Samsung SCW71 Betriebsanleitung

Samsung

Samsung VP-DC563 Betriebsanleitung

Samsung

Samsung VP-W61 Bedienungsanleitung

Samsung

Samsung SC-D107 Betriebsanleitung

Samsung

Samsung HMX-R10BN Bedienungsanleitung

Samsung

Samsung VP-X110L Betriebsanleitung

Beliebte Camcorder Handbücher anderer Marken

Toshiba

Toshiba CAMILEO Z100 Bedienungsanleitung

Panasonic

Panasonic NV-VS40B Bedienungsanleitung

Canon

Canon RC 260 Bedienungsanleitung

Sony

Sony Handycam DCR-DVD7E Bedienungsanleitung

Brinno

Brinno TimeLapse TLC200 Bedienungsanleitung

JVC

JVC GR-SXM68AC Kurzanleitung

Panasonic

Panasonic AG-HMC152EN Bedienungsanleitung

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Bedienungsanleitung

MYDLINK

MYDLINK DCS-6100LH Bedienungsanleitung

Sony

Sony video Hi8 Handycam CCD-TR555 Bedienungsanleitung

SECURECOM

SECURECOM V-5014B Bedienungsanleitung

Panasonic

Panasonic HDC-SD100 Bedienungsanleitung

Sharper Image

Sharper Image U-VIDEO Bedienungsanleitung

JVC

JVC AA-V15EG Bedienungsanleitung

Canon

Canon LEGRIA HV40 Bedienungsanleitung

Sony

Sony Handycam DCR-VX2000 Bedienungsanleitung

RCA

RCA CC616 Bedienungsanleitung

Panasonic

Panasonic NVM40 Bedienungsanleitung
