Sargent 7800 Bedienungsanleitung

TEMPLATE LAYOUT

ON DOOR EDGE

A7623A

185P Occupancy Indicator s own

2-1/2"

CENTER INE

OF OCKBODY

CENTER INE OF

OCKBODY

2-1/2"1-3/8"

FOR META

DOORS: DRI

(2) PI OT HO ES

0.106 (#36 DRI )

AND TAP

(#6-32 UNC)

9/16"

2-3/4"

OW SIDE

OF DOOR

INSIDE RHRB

OUTSIDE H

NO BEVE

DOOR

HIGH SIDE

OF DOOR

INSIDE RH

OUTSIDE HRB

1/2" DIA. HO E

FOLD HERE ACCORDING TO DOOR HAND AND BEVEL

TOP

CY INDER

EVER OR

KNOB

ASSA ABLOY G oup company. All ights ese ved. Rep oduction

in whole o in pa t without the exp ess w itten pe mission of

Sa gent Manufactu ing Company is p ohibited.

INSTALLATION INSTRUCTIONS FOR

7800/8200 MORTISE LOCK

VISUAL(185C)/OCCUPANCY(185P) INDICATORS

For assistance contact SARGENT at 800-727-5477 or www.sargentlock.com

INSTALLATION INSTRUCTIONS FOR

7800/8200 MORTISE LOCK

VISUAL(185C)/OCCUPANCY(185P) INDICATORS

For assistance contact SARGENT at 800-727-5477 or www.sargentlock.com

A7623A

Item Description Qty. Part

Number

1Indicator Button 1 82-0592

Indicator Button–Emrgcy. Release 1 82-0591

2 Housing Plate 1 82-0589

3Red/White Slide 1 82-4050

VAC/OCC Slide 1 82-4051

4 Rotation Plate 1 82-0590

5 Snap Ring 1 01-4552

6 Spindle 1 77-1195

7 #6 x 5/8" Wood Screw (not shown) 2 01-2036

8 #6-32 x 1/2" MS (not shown) 2 01-1020

INSTRUCTIONS FOR CHANGING

INDICATOR SLIDES 1. SNAP RING

2. ROTATION P ATE

3. SPIND E

4. RED/WHITE S IDE

5. VAC/OCC S IDE

185C

185P

CENTER INE OF

OCKBODY

2-1/2" 1-3/8"

FOR META

DOORS: DRI

(2) PI OT HO ES

0.106 (#36 DRI )

AND TAP

(#6-32 UNC)

9/16"

2-3/4"

OW SIDE

OF DOOR

INSIDE HRB

OUTSIDE RH

NO BEVE

DOOR

HIGH SIDE

OF DOOR

INSIDE H

OUTSIDE RHRB

1/2" DIA. HO E

185C

185P

1. REMOVE SNAP RING.

2. REMOVE PARTS 2, 3, & 4 OR 5.

3. REP ACE WITH A TERNATE S IDE.

4. REASSEMB E PARTS 2 & 3.

NOTE: CHECK FOR PROPER ORIENTATION

OF VAC/OCC SLIDE TEXT.

5. REP ACE SNAP RING INTO GROOVE IN

BUTTON.

FOLD HERE ACCORDING TO DOOR HAND AND BEVEL

TOP

CY INDER

EVER OR KNOB

ASSA ABLOY G oup company. All ights ese ved. Rep oduction

in whole o in pa t without the exp ess w itten pe mission of

Sa gent Manufactu ing Company is p ohibited.
