Saxby Lighting 75270 Handbuch

• Thissystemcontainsnon-replaceablepartsandcannotbeserviced.Ifdamageoccursthepartshould

bescrapped.

Instructionleaflet

Sentinel Battery PIR Wall Light

www.saxbylighting.com

Foryoursafety,alwaysswitchoffthesupplybeforecleaning.

Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilities

exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.

Recycling advice

Safety information

SaxbyLightingLtd.BH233PE

Werecommendcleaningwithasoftdrycloth.

Donotusesolventsorabrasivecleanersasthesecoulddamagethefinish.

Fitting/replacing bulbs

Iss.121062018

75270

PIR Adjustment

• Theunitmustbeinstalledinavertical position, and

fittedbetween1.8mand2.5mabovetheground.

• The PIR sensor can be adjusted, allowing the

detection distance to be altered to suit the location.

The detection angle is set at 180 degrees. The

durationthat thelamp stayson canbe alteredfrom

10±5 seconds to 60±10 seconds. The detection

distance "SENS" can be adjusted up to 10m Use a

small screwdriver to adjust the ‘TIME’ and ‘SENS’

screws. When adjusting the sensitivity (detection

distance)indaylightitwillbenecessarytocoverthe

sensortosimulatenighttime.

Detection range can be adjusted

by turning 'SENS' screw

Adjustable up to 10 metres

Duration the bulb stays on is

adjustable by turning 'TIME' screw

The sensor trigger point is adjust-

able by turning the ‘LUX’ screw.

Base of product

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand

satisfactoryoperationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.

Warning

Thisunitcannotbedimmed.

Thisproductcontainsnon-replaceablepartsand

cannotbeserviced.Ifdamageoccurstheproduct

shouldbescrapped.

Wasteelectricalproductsshouldnotbedisposedof

withhouseholdwaste.Pleaserecyclewherefacilities

exist.Checkwithyourlocalauthorityorretailerfor

recyclingadvice.

ThisproductisratedatIP44.

Thisproductisnotsuitableforlocationinorneara

marineenvironment.

Battery Care:-

- Donotrechargenon-rechargeablebatteries.

-Donotmixoldandnewbatteriesorbatteriesof

differenttypes/brands.

-Donotuserechargeablebatteries.Alwaysremove

exhaustedbatteriesfromtheproduct.

-Alwaysinsertbatterieswiththecorrectpolarity.

-Donotshortthesupplyterminals.

-Thisproductissuitableforusebyadultsonly.

Specification

Voltage: 6V

Lamp: 2x2WLEDModule

IPrating: 44

BatteryType: 4x1.5VAA(notsupplied).

Layout

• Avoidmountingonsurfacessubjecttovibration,as

thismayaffectthePIRsensor.

• Toavoiddamagetotheunit,donotaimthesensor

towardsthesunorareasofstrongelectro-magnetic

disturbances.

• Toavoidnuisancetriggering,thesensorshouldbe

aimedawayfromheatsources,suchasBBQ’s,

Air-Conditioners,otheroutsidelighting,movingcars

andflueventsorreflectivesurfacessuchassmooth

whitewallsorswimmingpools.

• Whenselectinglocation,itisadvisabletonotethat

movementacrossthesensorsfieldismoreeffective

thantowards/awayfromit..

• Decideontheoptimumlocationfortheproduct.Ensurethewalliscapableofholdingtheweightoftheproduct.

• Placetheproductinanuprightposition.

• Detachthewallbackbyremovingthescrewfromthebottomoftheproduct.Setscrewasideforrefittinglater

(Fig.1).

•.Pushbuttonontopofproductandremovewallback(Fig.1).

•.Usingthewallbackasatemplate,markanddrillthepositionofthefixingholes.

• Fixthewallbacktothewallusingthescrewsandwallplugs.Takecaretoavoiddamaginganyconcealed

wiringandpipes.Thecorrectfixingsshouldbeusedforbrickorcavitywalls.

• Removethebatterycasecoverandfitthebatteries.Ensurethe"BatteryCare"warningsonthepreviouspage

arefollowed(Fig.2).

• RefitthebatterycasecoverandthenRefitthescrewssetasideearliersecureinplace.

• SwitchontheproductusingthepushswitchonthefrontoftheproductandadjustthePIRsensorasdetailed

overleaf.Pleasenotethesensorrotatesforeasyaccesstothecontrols.Linethewhitedotsupatthefrontof

theproducttoensurethecorrectorientation.

• Gentlyrotatetheangleoftheshadesbyhandto     

yourpreferredposition.

• Yourlightisnowreadyforuse.

Installation

Fig. 1

Fig. 2

Push
