SCANTRONIC 9100 (3000)
SYSTEM SPECIFICATION
System capacity 16 zones plus Entry/Exit, PAB, 24 Hour,
Auxiliary zone
Keypads 2 remote keypads maximum
Programming 16 programmable zones
User Codes 1 access code
1 engineer code
Communications Plug on 9058 digital communicator
Plug on STU (Redcare)
Audible warning devices Onboard sounder as standard
External bell/strobe
Internal sounder
Other facilities Soak test
Double knock
Chime
Exterminator circuit
Part set
60 event alarm log
Written By Paul Wright
Written By Paul Wright
Press the number 4 (BELL TEST) square then ENTER, followed by the code number. The internal
sounders, followed by the external sounders and finally the strobe, if fitted, will be activated.
Each test lasts for 3 seconds. The panel will automatically return to the UNSET state.
USER OPERATING GUIDE
SETTING THE SYSTEM
Ensure the red DAY LED is on.
Enter the code number. The DAY LED will extinguish. The exit tone will start.
Leave the premises by the correct exit route closing the exit door after leaving
Ensure that the exit tone stops after the preset exit time expires. The system has now set
PART SETTING THE SYSTEM
Press the number 1 (Part Set) square, then ENTER, followed by the code number.
The DAY LED will extinguish, the PART SET LED will illuminate and the exit tone will start.
The system has part set correctly when the exit tone stops
UNSETTING THE SYSTEM
Enter the premises by the normal route. The entry tone will start. Proceed directly to the panel or
Keypad and enter the code number. The entry tone will stop and the DAY LED will illuminate.
The system is now unset
UNSETTING THE SYSTEM AFTER AN ALARM ACTIVATION
Enter the premises by the normal route. The entry tone will start. Proceed directly to the panel
or keypad and enter the user code. The entry tone will stop and the DAY LED will illuminate.
The system is now unset.
TESTING THE SOUNDERS
UNSET state.
WALK TEST
Press the number 5 (Walk Test) square then ENTER followed by the user code. The panel will
give a continuous tone. When a zone is violated the relevant zone number to return to the
will illuminate. All zones programmed to chime will do so when violated. When the chime option
is no longer required press the number 2 (CHIME) square then ENTER, followed by the user code
OMIT ZONES (MANUAL BYPASS)
CHANGING THE USER CODE
The user's code can only be changed by an engineer.
SELECTING ZONES TO CHIME
Press the number 2 (CHIME) square then ENTER, followed by the code number. The chime LED
Enter the user number and the DAT LED will extinguish. The exit tone will start. Within 5 seconds
press the omit square followed by the zone number to be omitted then press, 0 will appear in the
display. Repeat this if other zones are to be omitted. When all the required zones have been omitted
leave by the normal exit route. The system has set correctly when the exit tone stops
Enter the code number to silence the sounder. The CALL ENGINEER LED will be flashing. Enter
CUSTOMER EVENT LOG
Press the number 7 (SCROLL) square then ENTER> The alarm or the tamper LED'S will
illuminate and the display will show the last activation on the system.
TAMPER RESET
the code number. The tamper LED will illuminate and the display will show which zones has the
tamper fault. An engineer will need to visit the customer's premises
Written By Paul Wright
the activation. If a remote reset unit is fitted, quote the number in the display to the monitoring
Written By Paul Wright
illuminate.
RESETTING THE SMOKE DETECTOR AFTER AN ACTIVATION
Enter the code number the sounder will stop and the display will clear, the call engineer LED will
Following an alarm activation on the fire zone, ' A ' will appear in the display, the alarm LED will
illuminate and a two tone siren will sound. Enter the code number to silence the siren and reset
the system. Smoke detectors will require resetting. To reset the smoke detector press the small
reset button on the main control panel.
LINE FAULT
L ' Will appear in the display and the fault LED will illuminate. If the system is programmed for
audible line fault develops in day mode. When the system is programmed for silent line fault, the
L ' will appear in the display and the fault LED will illuminate but the sounder will not activate
engineer visiting the premises or by the use of a remote reset keypad if fitted. The monitoring
station or ARC should not perform a remote reset if the system requires any corrective
maintenance, if the police have been notified or if the customer does not know the exact cause of
centre. A restore code will then be given which should be entered in to the reset keypad.
RESETTING THE SYSTEM
Following am alarm activation the CALL ENGINEER LED and the alarm LED will be illuminated.
The activated zone will be flashing in the display. The system can be reset either by an
Zone No''
Zone No''
T
U
H
P
P
A
E
E
L
C
1
2
3
4AND THE FAULT LIGHT LIT TOTAL POWER FAIL MAINS AND BATT
Written By Paul Wright
ENGINEER REQD AUX FUSED
AND FAULT LIGHT LIT AUX POWER SUPPLY FAILURE
AND FAULT LIGHT LIT BATTERY FAULT
AND FAULT LIGHT LIT MAINS FAILURE
THE COMMUNICATOR WILL ATTEMPT
TO DIAL C/S 19 TIMES)
C/S TWICE OR MORE, (WE MAY
RECEIVE SIGNAL AFTER THIS AS
AND FAULT LIGHT LIT COMMUNICATOR FAILED TO CONTACT
AND FAULT LIGHT LIT PHONE LINE FAULT
AND TAMPER LIGHT LIT TAMPER CIRCUIT ON ENTRY/EXIT ZONE
ENGINEER REQD
AND ALARM LIGHT LIT ACTIVATION WAS ON ENTRY/EXIT ZONE
OLD SYSTEMS) CONTAINING SMOKE
DETECTOR
AND ALARM LIGHT LIT AUX ALARM OPERATED (NORMALLY
AND TAMPER LIGHT LIT PA CIRCUIT TAMPER ENGINEER REQD
CODE THREE TIMES
AND TAMPER LIGHT LIT 24HR LOOP TAMPER ENGINEER REQD
ZONE ENGINEER REQUIRED
AND TAMPER LIGHT LIT PANEL/BELL OR TAMPER LOOP
DISPLAYED CODES AND THEIR MEANINGS
AND ALARM LIGHT LIT ACTIVATION WAS ON THIS ZONE
AND TAMPER LIGHT LIT TAMPER WAS ACTIVATED ON THIS
ACTIVATED ENGINEER REQUIRED
AND TAMPER LIGHT LIT CUSTOMER HAS ENTERED INCORRECT
FAULT
AND ALARM LIGHT LIT PA BUTTON PRESSED OR PA CABLE
