Scotsman TouchFree MDT2C12 Bedienungsanleitung

MDT2C12

24 HOUR ICE PRODUCTION

Air-Cooled

ARI

700/500900/700

lbs./kg. lbs./kg.

MDT2C12 273/124 198/90

SCOTSMAN

Based on

Air/Water

Temperatures

•Sleek, high-tech styled design with durable plastic front and top panels.

•Extremely quiet operation, ideal for hospital floors, cafeterias and offices.

•Plastic chute easily removed for sterilization

•TouchFree actuation provides convenient one-hand operations and eliminates

the risk of cross contamination.

•Flexible utility location.

•Makes & dispenses cubelet ice, which is a harder, slow-melting ice form that

allows for more reliable and easier dispensing.

•Bigger sink allowing more clearance for larger containers.

WARRANTY See your dealer for complete warranty details.

•2years parts on all components.

•2years labor on all components.

•5years parts on compressor.

This product qualifies for the following listings:

YOU’LL VALUE OUR IMPROVED TOUCHFREE®

ICE MAKER / WATER DISPENSERS

TOUCHFREE®AIR COOLED CUBELET ICE MAKER / DISPENSER

19/32"

9/32"

5/8"

5/16"

Cubelet Ice

Lighted Key-Pad for

Dispensing Selection

Select either ice-only, ice and

water, water only, or dispensing

for pitchers with simple touch of

a button.

Hard, slow-melting ice that

allows for more reliable

dispensing.

Ice Maker/Dispenser Specifications

All models: Dimensions: W x D x H Unit: 15

˝ x 26

˝ x 34

˝ Shipping Carton: 18˝ x 28˝ x36˝

All units with stainless steel finish, and plastic front and top panels.

Refrigerant: R-134A.

1 lb. apx.= 32 fl.. oz.

*Based on 70° Air and 50° Water Temperatures.

IMPORTANT OPERATING REQUIREMENTS:

Minimum Maximum

Air Temperatures 500F (100C) 1000F (37.70C)

Water Temperatures 400F (4.40C) 1000F (37.70C)

Water Pressures 20 PSIG 80 PSIG

Electrical Voltage -5% +10%

INSTALLATION NOTE: Allow 6˝ minimum space at left side, top and back for ventilation and utility connections.

775 Corporate Woods Parkway • Vernon Hills, IL 60061 •1-800-SCOTSMAN • Fax: (847) 913-9844

Visit our website at: www.scotsman-ice.com • E-mail: customer.ser[email protected]

YOU’LL VALUE THE DIFFERENCE.

Consult Your Local SCOTSMAN Representative At:

Machine requires voltage indicated on rating name plate. Failures caused by improper voltage are not considered

factory defects. Extended periods of operation at temperatures exceeding limitations constitutes misuse under the

terms of Scotsman Manufacturer’s Limited Warranty, resulting in a loss of warranty coverage. Specifications and

design are subject to change without notice.

Scotsman’s ice machines are not designed for outdoor installations.

Power Water Usage

Bin Basic Max. Fuse Total Shipping Consumption Gallons/100 lbs.

Model Condenser Cap. Electrical Size or HACR Comp. Circuit Load Weight KWH/100 lbs. Potable Condenser

Number Unit lbs./kg. Volts/Hz/Phase Circuit Breaker HP Wires Amps lbs./kg. 90°F/70° F 90°F/70° F 90°F/70° F

MDT2C12A-1A Air 12/5 115/60/1 15 3/8 2 6.0 161/73 13.0 24 –

SD-2C12 3M 8-05

MDT2C12 12/5 11.4/5.1 192 + 182 = 374 96 + 91 = 187 64 + 61 = 125 48 + 46 = 94

Bin

Storage

lb./kg.

1 Hour

Recovery Cap.

lb./kg.

2 fl. oz.

Bin

Total

2 fl. oz.

Vends

Model

2 fl. oz.

Recovery

4 fl. oz.

Bin

Total

4 fl. oz.

Vends

4 fl. oz.

Recovery

6 fl. oz.

Bin

Total

6 fl. oz.

Vends

6 fl. oz.

Recovery

8 fl. oz.

Bin

Total

8 fl. oz.

Vends

8 fl. oz.

Recovery

Number of Vends Per Hour from Full Bin + Recovery = Total Vends

ICE VENDING CAPACITY

PEAK VENDS PER HOUR*

26 7/64"

(66.3 cm)

15 9/32"

(38.8 cm)

AIR EXHAUST

AIR

INTAKE 34.13/32"

(87.4 cm)

4 21/64"

(11.0 cm)

3/4" WATER

25/32"

(2.0 cm)

2 1/2"

(6.5 cm)

8 25/64"

(21.3 cm)

1 37/64"

(4.0 cm)

10 53/64"

(27.5 cm)
