TapPlay™User Manual

TP-U400

Receiver: TP-U400

Transmitter: TP-DGH (HDMI dongle), TP-DGC (Type C dongle)

Document No. SD-MA-044

Document Version: 02




Contents
Overview ..........................................................................................................................................................1
Specification .....................................................................................................................................................4
Panel Layout.....................................................................................................................................................5
1 Hardware Interface ...........................................................................................................................5
1.1 TP-U400 Front Panel..........................................................................................................................5
1.2 TP-U400 back Panel...........................................................................................................................7
1.3 Factory Reset.....................................................................................................................................8
1.4 Dongle Front Panel............................................................................................................................9
2 Software Interface...........................................................................................................................11
2.1 Home Screen ...................................................................................................................................11
Installation......................................................................................................................................................13
1 Installation methods for the base unit............................................................................................13
2 Wiring Diagram................................................................................................................................14
3 Power Connection...........................................................................................................................14
4 Video Connection ............................................................................................................................15
5 Audio Connection............................................................................................................................15
6 LAN connection ...............................................................................................................................15
7 Use of USB devices ..........................................................................................................................16
Quick Start......................................................................................................................................................17
1 Mobile device: Wireless Connection...............................................................................................17
2 Pairing dongles with base unit ........................................................................................................17
3 Mirroring .........................................................................................................................................17
3.1 Windows PC/Mac with application .................................................................................................17
3.1.1 Options for Windows PC/Mac .................................................................................................19
3.1.2 Quad view mirroring................................................................................................................19
3.2 Mobiles Devices...............................................................................................................................20
3.3 Miracast on Android Devices and WIN10 PC ..................................................................................21
3.4 Chromecast on PC ...........................................................................................................................21
4 Preview Window .............................................................................................................................22




5 Whiteboard & Annotation...............................................................................................................22
5.1 Whiteboard .....................................................................................................................................22
5.2 Annotation.......................................................................................................................................25
Start video conferencing via USB-over-Wi-Fi technology ..............................................................................27
1 Start with application/dongles........................................................................................................27
WEBUI.............................................................................................................................................................28
1 Network settings .............................................................................................................................29
1.1 Wireless network.............................................................................................................................29
1.2 Ethernet...........................................................................................................................................32
1.3 Auto change password....................................................................................................................33
2 Display & Audio ...............................................................................................................................34
2.1 HDMI................................................................................................................................................34
2.2 Audio ...............................................................................................................................................36
2.3 Airplay screen quality......................................................................................................................37
2.4 Show the base device name and password when mirroring: .........................................................38
2.5 Home Screen background image.....................................................................................................39
3 Moderator control...........................................................................................................................40
4 System settings................................................................................................................................42
4.1 Buttons: ...........................................................................................................................................42
4.2 Date & Time.....................................................................................................................................43
4.3 Auto standby ...................................................................................................................................44
4.4 Language..........................................................................................................................................44
4.5 Reset................................................................................................................................................45
4.6 Configuration File ............................................................................................................................45
4.7 Series Port Setting ...........................................................................................................................46
4.8 Telnet switch ...................................................................................................................................46
4.9 Reboot .............................................................................................................................................47
5 Security Settings..............................................................................................................................48
5.1 Security level ...................................................................................................................................48
5.2 Login Password................................................................................................................................49
5.3 Connection password......................................................................................................................49


6 Firmware upgrade ...........................................................................................................................50
6.1 Firmware Update.............................................................................................................................50
6.2 Automatic Upgrading ......................................................................................................................50
7 Other settings..................................................................................................................................51
7.1 Auto create launcher.......................................................................................................................51
7.2 Clear history after meeting..............................................................................................................52
7.3 Developer tools ...............................................................................................................................52
8 UCC-Device manager.......................................................................................................................53
9 About device....................................................................................................................................54
Troubleshooting .............................................................................................................................................55

SD-MA-0441 V2.0

1. Overview

TP-U400 is a BYOM wireless presentation switcher designed for ease of use in conference room or

classroom applications with less cabling and cost. This product is compatible with most USB cameras

and conferencing audio solutions, such as speakerphones, AEC processors, video soundbars with

audio integration, etc.

TP-U400 features its own Wi-Fi access point and support popular mirroring technology such as Airplay

and Miracast from computers and phones. The product supports single view, 1x2 and 2x2 multiview

and can have up to 16 devices connected with preview. It can be incorporated with interactive display

or whiteboard to control source devices for manipulating or annotating. The use of TP-U400 can offer

a powerful presentation and collaboration environment for conference and meetings.

Key Features

TP-U400:

•Full wireless presentation and BYOM support

•Support wireless input up to 1080P@60Hz, and HDMI 2.0 output up to 4K@60Hz

•Support Windows/Android application and PnP HDMI/Type-C dongles for wireless connection

•Support wireless mirroring like Miracast

•Support USB peripherals like camera, mic, and speaker for wireless connection to PC/Mac

•Support mouse and keyboard control

•Support wireless touch back for PC/Android

•Fully compatible with VC platforms

•Support multiview up to 4 windows with preview

•Support PoE

•Support customisable home screen

•Built-in whiteboard and on-screen annotation

•Support WebUI for central management

•Low latency

•Best-in-class data security

•Support preview

SD-MA-0442 V2.0

TP-DGC/TP-DGH:

•Support wireless transmission from PC/Mac to base unit

•Support quick switch of the PC signal for less than 1s by tapping

•Dual color LED, indicating active source signal and power/link

•Support USB peripherals such as camera, mic, and speaker over Wi-Fi sharing

TP-U400 related devices and applications

A typical TP-U400 can work with two different types of dongles, ‘TapPlay’for Android/Windows/Mac

and Airplay for IOS. Depending on the application or size of the meeting room, users can purchase

more dongles, e.g., HDMI dongle/ Type C dongle if necessary.

SD-MA-0443 V2.0

Name

Description

Base Unit

Base unit TP-U400

Dongles/Transmitters

For PC/Mac to share the desktop/extended

desktop.

‘TapPlay’app

For Android/Windows/Mac devices to share

the screen.

Airplay for IOS

For IOS devices to share the screen.

Accessories List

Name

Description

Antenna

3 pcs of antenna are included in the box. To

avoid damage, they are not pre-mounted.

The antenna can rotate for a better wireless

connection.

Power adapter

International plug inter-changeable power

adapter, of which the plugs include US,

Europe and UK standard.

Phoenix terminal

1 piece phoenix terminal for connecting the

RS232 port of the back panel.

Download Card

1 piece download card that user can find

related manuals on our website.

SD-MA-0444 V2.0

2. Specification

TP-U400 Specification

HDMI output

1x HDMI 19-pin female connector

Video Output Resolution

3840x2160@60Hz/30Hz, 1920x1080@60Hz, 1280x720@60Hz

Format Compliance

HDMI1.4/HDMI2.0

HDMI input / max. resolution

Maximum 1080P@60Hz via TP-DGH/DGC, app, and Airplay

HDCP

HDCP1.4/HDCP2.2

Compatible dongles

TP-DGH, TP-DGC

LAN port

2x RJ45: 1x 1000Mbps with POE, 1x 100Mbps

USB interface

3x USB3.0, 1x USB 2.0, 2x Type-C

Control

Keyboard, mouse, and interactive display touch back

Content Input

TP-DGH/TP-DGC, AirPlay, Miracast, Windows/Mac application

Audio Output (Analog)

1x 3.5mm audio female connectors

Control interface

WebUI, Telnet, 3.5mm Phoenix terminal/ RS232 interface

Multiview

Up to 4 simultaneously with adjustable layout

Number of simultaneous

connections

Minimum 16

Wireless transmission protocol

Wi-Fi IEEE 802.11 a/g/n/ac

Frequency band

2.4 GHz & 5 GHz

Data rate in wireless

Up to 1200Mbps

Latency

<100ms, min 20ms with low latency mouse cursor

Dimension (W x D x H)

220 x 120 x 34mm (incl. antennas 220 x 280 x 34mm)

Weight

0.74kg

Temperature

-4° ~ +140° F (-20° ~ +60° C)

Humidity (Storage / Operating)

20%-90%（non-condensing）

Power Supply

Power adaptor with exchangeable plugs (EU/UK/US) 12V/3A, POE

POE standard

POE plus - IEEE802.3af

Power Consumption

Maximum 36W

Security standard

WiFi: WPA PSK, WPA2 PSK - Video transmission encrypted with AES-256 bit +

RSA1024 bit

SD-MA-0445 V2.0

3. Panel Layout

About this chapter

The installation chapter gives an overview of the interface of TP-U400.

Overview

⚫Hardware Interface

◼TP-U400 Front Panel

◼TP-U400 Back Panel

◼TP-DGH/TP-DGC Front panel

⚫Software Interface

◼Home Screen

3.1 Hardware Interface

3.1.1 TP-U400 Front Panel

Note: Front USB port and type C port cannot be used at the same time, type C port is prior to USB

port.

SD-MA-0446 V2.0

Name

Description

Front USB connector

USB port, for dongle pairing, mouse control,

USB touch screen etc.

Front Type-C connector

Type-C port, for dongle pairing.

Power Button

Turn on or off the device.

Back-lit LED indicator

RED: Initialisation

Flashing GREEN: Power on

Static GREEN: Ready to share

Static Cyan, Sharing

USB port

⚫The USB port can be used to pair dongles with the base unit.

⚫The USB port can be used to create or upgrade TapPlay Windows/Mac/Android applications by

clicking Download button, when a USB stick is plugged in.

⚫The USB port can be used to connect a USB-based touch screen or mouse/keyboard for

controlling when a PC desktop is mirroring to the screen.

Type-C port

The Type-C port can be used for pairing TP-DGC with base unit.

Mounting

The mounting points for the unit are located at the bottom of the base unit.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Beliebte Empfänger Handbücher anderer Marken

Garmin

Garmin GA 23 Bedienungsanleitung

Aiphone

Aiphone PS-12F Bedienungsanleitung

IMES

IMES TCS-01CA-PMI Bedienungsanleitung

BWI Eagle

BWI Eagle AIR-EAGLE SR Handbuch

AMIMON

AMIMON AMN12310 WHDI Bedienungsanleitung

Dual

Dual DMCPA79BT Betriebsanleitung

Sound Associates

Sound Associates SA652P Bedienungsanleitung

Sherwood

Sherwood NewCastle R-772 Bedienungsanleitung

Audio

Audio A10-RX Series Bedienungsanleitung

AllSee

AllSee PushShare PSRV1.1 Bedienungsanleitung

DEMAG

DEMAG DRC-DR D2 Bedienungsanleitung

Teleco

Teleco TVRCL868A02 Bedienungsanleitung

Bosch

Bosch RF3222E Bedienungsanleitung

Kramer

Kramer 631R Bedienungsanleitung

Xpress

Xpress xmc10 Bedienungsanleitung

JVC

JVC KD-MR1BTS Bedienungsanleitung

Omega Engineering

Omega Engineering UWTC-REC3 Bedienungsanleitung

e-survey

e-survey E300 Pro Bedienungsanleitung
