Seagull Models Swift 40 Bedienungsanleitung
Specifications:
Wingspan-------------------------------63in(160cm).
Wingarea------------------643.3sq.in(41.5sqdm).
Weight-------------------------5.5-6.2lbs(2.5-2.8kg).
Length--------------------------------45.8in(116.4cm).
Engine ------------------0.40-0.55cu.in----2stroke.
0.72-0.82cu.in--- 4 stroke.
Radio------------------------4channelswith4servos.
Eletricconversion:optional
ASSEMBLY MANUAL
MS:138
“Graphics and specifications may change without notice”.
2
SWIFT40. Instruction Manual.
INTRODUCTION.
Thankyouforchoosingthe SWIFT40 ARTFbySEAGULLMODELS.TheSWIFT 40 wasdesigned
with the sports trainer flyer in mind. It is a High-wing aeroplane which is easy to fly and quick to
assemble.Theairframeisconventionallybuilt using balsa, plywood andveneertomakeitstronger
thantheaverageARTF,yetthedesignallows the aeroplane to be kept light. You willfindthatmost
of the work has been done for you already. The pushrods are pre-made to the correct lengths, the
motor mount has been fitted and the hinges are pre-installed and pinned for security. Flying the
SWIFT40 is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manualthroughlybeforestarting assembly ofyourSWIFT40 .Usethe parts listingbelowtoidentify
all parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable
of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU ASSUME ALL
RISK & RESPONSIBILITY.
IfyouareinexperiencedwithbasicR/CflightwestronglyrecommendyoucontactyourR/Csupplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
proceduresdesignedtohelpthenewpilotonhiswaytosuccessfulR/Cflight.Theywillalsobeable
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
- 0.40-0.55 2 stroke .
- 0.72-0.82 4 stroke.
- 4 channel radio with four servos.
- Glow plug to suit engine.
- Propeller to suit engine.
- Protective foam rubber for radio
system.
- Silicone fuel line.
- Stick-on weights for balance
(If necessary).
TOOLS & SUPPLIES NEEDED.
- Thick cyanoacrylate glue.
- 30 minute epoxy.
- 5 minute epoxy.
- Hand or electric drill.
- Assorted drill bits.
-Modellingknife.
- Straight edge ruler.
- 2mm ball driver.
- Phillips head screwdriver.
- 220 grit sandpaper.
- 90° square or builder’s triangle.
- Wire cutters.
- Masking tape & T-pins.
- Thread-lock.
- Paper towels.
PARTS LISTING.
FUSELAGE ASSEMBLY
- (1) Fuselage.
- (1) Pre-installed throttle pushrod &
tube.
- (1) Pre-installed servo tray.
- (1) Pre-installed motor mount.
- (1) Pre-installed rudder pushrod.
- (1) Pre-installed elevator pushrod.
WING ASSEMBLY
- (1) Right wing half with pre-
installedaileron.
- (1) Left wing half with pre-installed
aileron.
- (1) Plywood wing dihedral brace.
- (1) Covering strip for centre
section joint.
TAIL SECTION ASSEMBLY
- (1) Vertical stabilizer with pre-
installedrudder.
- (1) Horizontal stabilizer with pre-
installedelevatorhalves.
3
Instruction Manual.
2)Removeeachhinge from thewingpanel
and aileron and place a T-pin in the center of
each hinge. Slide each hinge into the wing
panel until the T-pin is snug against the wing
panel. This will help ensure an equal amount
ofhingeis on eithersideofthe hinge linewhen
the aileron is mounted to the aileron.
The control surfaces, including the
ailerons, elevators, and rudder, are
prehinged with hinges installed, but the
hinges are not glued in place. It is
imperativethatyouproperlyadherethe
hingesinplaceperthestepsthatfollow
using a high-quality thin C/A glue.
Note:
HINGING THE AILERONS.
Hinge.
3) Slide the wing panel on the aileron until
there is only a slight gap. The hinge is now
centered on the wing panel and aileron.
Remove the T-pins and snug the aileron
against the wing panel.Agap of 1/64” or less
shouldbemaintainedbetweenthewingpanel
andaileron.
1) Carefully remove the aileron from one
of the wing panels. Note the position of the
hinges.
C/Aglue.
4) Deflect the aileron and completely
saturate each hinge with thin C/A glue. The
aileronsfrontsurface should lightlycontactthe
wing during this procedure. Ideally, when the
hinges are glued in place, a 1/64” gap or less
will be maintained throughout the lengh of the
aileron to the wing panel hinge line.
Thehingeis constructedofa special
material that allows the C/A to wick
or penetrate and distribute
throughout the hinge, securely
bonding it to the wood structure of
the wing panel and aileron.
Note:
Epoxy.
C/Aglue.
4
SWIFT40. Instruction Manual.
Aluminumwing tube.
WING ASSEMBLY.
8)Afterboth ailerons are securelyhinged,
firmly grasp the wing panel and aileron to
make sure the hinges are securely glued and
cannot be pulled out. Do this by carefully
applying medium pressure, trying to separate
the aileron from the wing panel. Use caution
not to crush the wing structure.
7) Repeat this process with the other wing
panel, securely hinging the aileron in place.
6) Using C/A remover/debonder and a
papertowel,removeanyexcessC/A glue that
may have accumulated on the wing or in the
aileronhingearea.
5)Turn the wing paneloveranddeflectthe
aileron in the opposite direction from the
opposite side. Apply thin C/A glue to each
hinge,makingsurethatthe C/Apenetratesinto
both the aileron and wing panel.
Workthe aileronupand downseveral
times to “work in” the hinges and
check for proper movement.
Note:
HINGING THE ELEVATOR.
Glue the elevator hinges in place using the
same techniques used to hinge the ailerons.
HINGING THE RUDDER.
Glue the rudder hinges in place using the
same techniques used to hinge the ailerons.
5
Instruction Manual.
M2x12mm.
INSTALLING THEAILERON SERVO MOUNT.
M2x12mm.
M2x12mm.
6
SWIFT40. Instruction Manual.
INSTALLING THE MAIN GEAR WIRES.
Pushrod
wire.
1) The blind nuts for securing the landing
geararealreadymountedinsidethe fuselage.
2) Using the hardware provided, mount
the main landing gear to the fuselage.
3) Placethe fuselageinvertedonthework-
benchinasuitable stand. Set thelandinggear
in place and use a screwdrive to secure the
landing gear to the fuselage using bolts
M4x20mmandwashers.Make suretousethe
threadlock on the bolts so they don’t vibrate
loose.
8mm
Wirekeeper.
INSTALLINGTHEAILERON LINKAGE.
INSTALLING THE AILERON SERVO.
Install the aileron servo into the servo
mount, withtheoutputshafttowardsthelead-
ing edge of the wing, using the wood screws
provided with your radio system. Drill 1/16”
pilot holes through the mount before installing
the screws. This will prevent the wood from
splitting. Pen.
Wirekeeper.
7
Instruction Manual.
M4x20mm.
M4x20mm.
NOSE GEAR INSTALLATION.
1) Slide the fuel tank into the fuselage. Guide
the lines from the tank through the hole in the
firewall.
Steering arm.
Pushrod wire.
You should mark which tube is the vent
and which is the fuel pickup when you attach
fuel tubing to the tubes in the stopper. Once
thetankisinstalledinsidethefuselage,itmay
be difficult to determine which is which.
FUEL TANK INSTALLATION.
A
B
8
SWIFT40. Instruction Manual.
3) Connect the lines from the tank to the engine
and muffler. The vent line will connect to the
muffler and the line from the clunk to the
carburetor.
INSTALLINGTHEFUSELAGESERVOS.
1) Installtherubbergrommetsandbrass
collets onto the throttle servo. Test fit the
servo into the aileron servo mount.
2) Secure the servos with the screws
provided with your radio system.
Because the size of servos differ, you
mayneedto adjustthesizeof theprecutopen-
ing in the mount. The notch in the sides of the
mount allow the servo lead to pass through.
Rudder servo.
Elevator servo.
Throttle servo.
Blow through one of the lines to en-
sure the fuel lines have not become kinked
inside the fuel tank compartment. Air
should flow through easily.
2) Use balsa plywood to help prevent
moveable from transferring to the fuel tank as
shown.
C/Aglue.
A
Venttube.
Fuel pick up tube.
Fuel fill tube.
Balsawood included.
C/Aglue.
Fuel tank.
B
9
Instruction Manual.
THROTTLE SERVO ARM INSTALLATION.
Install adjustable servo connector in the
servo arm as same as picture below:
Servo arm.
Loctile
secure.
Adjustableservo
connector.
Trimand cut.
Throttleservoarm.
Elevatorservo.
Rudderservo.
3/32” Hole.
INSTALLING THE SWITCH.
Installtheswitchintotheprecut hole in the
side, in the fuselage.
3) Use a drill to drill the four holes in the engine
mount rails.
Switch.
MOUNTING THE ENGINE.
110mm.
+ ENGENE .46- .55 : 2 STROKE.
1) Positionthe enginewiththedrivewasher
(110mm) forward of the firewall as shown.
2) Use a pin drill and 2mm drill bit to drill a
small indentation in the mount for the engine
mounting screw.
2mm.
10
SWIFT40. Instruction Manual.
Machinescrew M4x30mm.
8) Reinstall the servo horn by sliding the
connector over the pushrod wire. Center the
throttle stick and trim and install the servo horn
perpendicular to the servo center line.
9) Move the throttle stick to the closed position
and move the carburetor to closed. Use a 2.5mm
hex wrench to tighten the screw that secures
the throttle pushrod wire. Make sure to use
threadlock on the screw so it does not vibrate
loose.
4) On the fire wall has the location for the
throttle pusshrod tube (pre-drill).
7) Slide the throttle pushrod wire into the tube.
Position the engine between the mounts. Use
four M4x30mm machine screws to secure the
engine to the mount as shown.
5) Slide the pushrod tube in the firewall and
guide it through the fuel tank mount. Use
medium C/A to glue the tube to the firewall and
the fuel tank mount.
6) Connect the Z-bend in the 450mm throttle
pushrod to the outer hole of the carburetor arm.
Machinescrew M4x30mm.
2mm.
Pushrodwire.
2mm.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Seagull Models Spielzeug Handbücher
Seagull Models
Seagull Models A6M Zero Fighter 67 Bedienungsanleitung
Seagull Models
Seagull Models fair child PT19 Bedienungsanleitung
Seagull Models
Seagull Models Piper Cub Bedienungsanleitung
Seagull Models
Seagull Models CURTISS P-40N WARHAWK Bedienungsanleitung
Seagull Models
Seagull Models CHEROKEE Bedienungsanleitung
Seagull Models
Seagull Models EDGE 540 EP Bedienungsanleitung
Seagull Models
Seagull Models Ultimate Bedienungsanleitung
Seagull Models
Seagull Models De Havilland DH-60M Moth 72" wingspan... Bedienungsanleitung
Seagull Models
Seagull Models Fairchild PT-19 Bedienungsanleitung
Seagull Models
Seagull Models DEWOITINE D.520 Bedienungsanleitung
Seagull Models
Seagull Models GEEBEE ARTF Bedienungsanleitung
Seagull Models
Seagull Models EXTRA EA 300L Bedienungsanleitung
Seagull Models
Seagull Models Magic Bird EF1 RACER 40E PNP, 46" Bedienungsanleitung
Seagull Models
Seagull Models SEA FURY Bedienungsanleitung
Seagull Models
Seagull Models DUAL ACE Bedienungsanleitung
Seagull Models
Seagull Models SEA 94 Pilatus PC-9 Bedienungsanleitung
Seagull Models
Seagull Models ZERO MS:123 Bedienungsanleitung
Seagull Models
Seagull Models PERCIVAL MEW GULL Bedienungsanleitung
Seagull Models
Seagull Models GLASAIR SPORTSMAN 2-2 Bedienungsanleitung
Seagull Models
Seagull Models YAK 54 Bedienungsanleitung
