Sealey VS270 Bedienungsanleitung

MULTI VOLTAGE GLOW PLUG TESTER

MODEL NO: VS270

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.

9Maintain tester in good and clean condition for best and safest performance.

9Wear approved eye protection. A full range of personal safety equipment is available from your Sealey stockist.

9Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.

9Account for all tools and parts being used and DO NOT leave any in or near the engine.

8DO NOT use tester if damaged.

9Vehicle should be in a well ventilated area.

IMPORTANT: These instructions are provided as a guide only. Always refer to the vehicle manufacturer’s service instructions, or a

proprietary manual, to establish the current procedure and data.

WARNING! The warnings referred to in this guide cannot cover all possible conditions and situations that may occur. It must be

understood that common sense and caution are factors which cannot be built into this product, but must be applied by the operator.

2. INTRODUCTION

Designed to test low voltage glow plug operation on modern diesel engines. Prevents glow plug damage caused by testing with the vehicle

battery. Glow plugs can be tested whist in situ. Supplied in storage case with instructions. Requires 9V battery (not supplied).

3. OPERATION

3.1. To t the battery remove rubber case, the battery compartment is located on the base of back of the unit.

3.2. MULTI VOLTAGE GLOW PLUG TESTER

3.2.1. Many modern diesel engines have low voltage glow plugs tted, this type of glow plug cannot be tested using the vehicle battery

voltage as damage may occur.

VS270 Issue 1 06/11/19

Original Language Version

Refer to

instructions

Wear eye

protection

Wear protective

gloves

Wear safety

footwear

Wear protective

clothing

3.3. INITIALISATION

3.3.1. Before the tester is used for the rst time, or if any other type of test probe is used than the one supplied, the device will need to be

initialised as follows;

1. Fit the connection leads to the unit observing the polarity.(Remove dust caps and replace after use).

2. Connect the red probe to the black clip.

3. Press and hold the power button, the tester will count from 0 to 5, continue to hold until “Zero” is displayed.

4. The tester is now ready for use.

3.4. TESTING METHOD

1. Disconnect the electrical connection to the glow plug(s).

2. Connect the black earth lead to a clean ground connection on the vehicle.

3. Press the power button to switch on the tester.

4. Touch the red probe to the positive (+) terminal of the glow plug.

5. The tester will show the condition of the glow plug within a few seconds.

4. MAINTENANCE

9Keep tester clean and dry.

8DO NOT use if leads are damaged.

9Replace batteries as required.

g.1 g.2 g.3

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid

waste authority for recycling information.

BATTERY REMOVAL

Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products

containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack

Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

Original Language Version

Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
