SignaMax 065-7401 Bedienungsanleitung

Signamax Connectivity Systems 065-740x Series

www.signamax-us.com www.signamax-eu.com

SignamaxConnectivity Systems

Hardened Compact Switch

User's Guide

Model: 065-7401

065-7402

065-7405

065-74051

065-74052

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Preface

A member of the growing family of rugged switches, this

switch addresses a need for a smaller switch. This switch

provides an affordable solution for rugged and outdoor

environment, transportation road-side cabinet, industrial

floor shop, multitenant dwellings or Fiber To The Home

(FTTH) applications. Capable of operating at temperature

extremes of -10°C to +60°C, this is the switch of choice for

harsh environments constrained by space.

Plug-and-Play Solution:

The switch is a plug-and-play Fast Ethernet Switch in

compact size. It doesn't have any complicated software to

set up.

This manual describes how to install and use the hardened

compact Ethernet Switch. This switch integrates full wire

speed switching technology. This switch brings the answer

to complicated hardened networking environments.

To get the most out of this manual, you should have an

understanding of Ethernet networking concepts.

In this manual, you will find:

•Features on the switch

•Illustrative LED functions

•Installation instructions

•Specifications

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Table of Contents

REFACE

ABLE OF

ONTENTS

RODUCT

VERVIEW

ARDENED

OMPACT

WITCH

ACKAGE

ONTENTS

RODUCT

IGHLIGHTS

Basic Features 4

RONT

ANEL

ISPLAY

HYSICAL

ORTS

NSTALLATION

ELECTING A

ITE FOR THE

WITCH

DIN

AIL

OUNTING

ONNECTING TO

OWER

DC Terminal Block Power Inputs 7

ONNECTING TO

OUR

ETWORK

Cable Type & Length 8

Cabling 9

PECIFICATIONS

PPENDIX

–

ONNECTOR

INOUTS

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Product Overview

Hardened Compact Switch

Package Contents

When you unpack the product package, you shall find the

items listed below. Please inspect the contents, and report

any apparent damage or missing items immediately to your

authorized reseller.

This Switch

User’s Manual

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Product Highlights

Basic Features

•5-port 10/100Base-TX or 4-port 10/100Base-TX plus

1-port 100Base-FX.

•Available in media converter format with 1-port

10/100Base-TX and 1-port 100Base-FX.

•Support IEEE802.3/802.3u/802.3X.

•Auto-negotiation: 10/100Mbps, Full/half-duplex; Auto

MDI/MDIX.

•Support 2K MAC addresses.

•Store-and-forward mechanism.

•Full wire-speed forwarding rate and non-blocking

mechanism.

•Broadcast storm filtering.

•Operating voltage and Max. current consumption:

12VDC @ 0.71A, 24VDC @ 0.37A, 48VDC @ 0.22A.

•Power consumption: 10.56W Max.

•Power Supply: DC Terminal Block power input,

10-48VDC with polarity protection.

•Plastic compact DIN-Rail Industrial case design.

•DIN-Rail mounting ability.

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Front Panel Display

LED State Indication

10/100TX or 100FX

Steady A valid network connection established.

LNK stands for LINK.

LNK/ACT

(Green) Flashing

Transmitting or receiving data.

ACT stands for ACTIVITY.

Steady Light solid yellow for a port transferring

at 100Mbps.

100

(Yellow) Off The port is transferring at 10Mbps If this

LED is dark.

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Physical Ports

This switch provides:

•Five 10/100BaseTX ports

•Four 10/100BaseTX ports + one 100BaseFX port

•One 10/100BaseTX port + one 100BaseFX port

CONNECTIVITY

•RJ-45 connectors

•SC or ST connecto on 100BaseFX fiber port.

Signamax Connectivity Systems 065-740x Series

www .signamax-us.com www.signamax-eu.com

Installation

This chapter gives step-by-step instructions about how to

install the switch:

Selecting a Site for the Switch

As with any electric device, you should place the switch

where it will not be subjected to extreme temperatures,

humidity, or electromagnetic interference. Specifically, the

site you select should meet the following requirements:

- The ambient temperature should be between -10 to 60

degrees Celsius.

- The relative humidity should be less than 90 percent,

non-condensing.

- Surrounding electrical devices should not exceed the

electromagnetic field (RFC) standards.

-Make sure that the switch receives adequate

ventilation. Do not block the ventilation holes on each

side of the switch

The Terminal Block

PWR Power Input

GND Power Ground

Earth Ground

Signamax Connectivity Systems 065-740x Series

www.signamax-us.com www.signamax-eu.com

Connecting to Your Network

Cable Type & Length

It is necessary to follow the cable specifications below

when connecting the switch to your network. Use

appropriate cables that meet your speed and cabling

requirements.

Cable Specifications

Speed

Connector

Port Speed

Half/Full

Duplex

Cable

Max.

Distance

10BaseT RJ-45 10/20 Mbps 2-pair

UTP/STP Cat.

3, 4, 5

100 m

100BaseTX

RJ-45 100/200 Mbps

2-pair

UTP/STP Cat.

100 m

100BaseFX

SC, ST 100/200 Mbps

MMF (50 or

62.5µm)

2 km

100BaseFX

SC, ST 100/200 Mbps

SMF (9 or

10µm)

15, 40, or 75

Signamax Connectivity Systems 065-740x Series

www.signamax-us.com www.signamax-eu.com

Cabling

Step 1: First, ensure the power of the switch and end devices is turned

off.

<Note> Always ensure that the power is off before any installation.

Step 2: Prepare cable with corresponding connectors for each type of

port in use.

<Note> To connect two regular RJ-45 ports between switches or hubs, you

need a cross-over cable.

Step 3: Consult the previous section for cabling requirements based

on connectors and speed.

Step 4: Connect one end of the cable to the switch and the other end

to a desired device.

Step 5: Once the connections between two end devices are made

successfully, turn on the power and the switch is operational.
