Simplay Labs SL-889 Bedienungsanleitung

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

Simplay-UG-SL889-1.1

Aug 2020

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester
User Guide

2 © 2019-2020 Simplay Labs, LLC., Simplay-UG-SL889-1.1
All rights reserved. CONFIDENTIAL
Contents
1. Overview........................................................................................................................................................................4
 SL-889 Hardware ...................................................................................................................................................4
1.1.1. Signal Path.......................................................................................................................................................5
 SL-889 Controls, Indicators, and Interface Connectors ..........................................................................................6
 SL-889 Test Modes .................................................................................................................................................6
1.3.1. Standard Test Mode ........................................................................................................................................6
1.3.2. Devices under Test ..........................................................................................................................................8
 HDMI 2.1 Video Resolution Support.......................................................................................................................8
 Inside the Box .........................................................................................................................................................8
1.5.1. 12V Power Supply ...........................................................................................................................................9
1.5.2. 2M Golden Test HDMI Cat-3 Cable .................................................................................................................9
2. The SL-889 in Standard Test Mode..............................................................................................................................10
 Calibrated HDMI 2.1 Tx Output Notes:.................................................................................................................10
 Setting up Connections –Pre-Test Operation ......................................................................................................11
 Setting up Connections –Normal Operation .......................................................................................................12
 Operation - Detailed.............................................................................................................................................12
 Operation –Quick Start........................................................................................................................................14
 Chamber Set Up....................................................................................................................................................15
2.6.1. CISPR Chamber Set Up –Cable Placement....................................................................................................15
2.6.2. HDMI Forum Recommended Chamber Set Up –Cable Placement...............................................................15
3. RF Scans and EMI Chamber measurements with the SL-889 ......................................................................................16
 HDMI 2.1 EMI Measurement................................................................................................................................16
3.1.1. EMI Chamber RF Emission Scans...................................................................................................................16
 EMI Limits and Testing..........................................................................................................................................17
3.2.1. CISPR 32 EMI Testing Standards....................................................................................................................17
3.2.2. HDMI Forum Cat-3 Cable EMI Testing Guidelines .........................................................................................17
Appendix A. Internal Firmware Upgrade ......................................................................................................................18
A.1. Update Firmware/Scripts/Test Images.................................................................................................................19
References ..........................................................................................................................................................................24
Revision History ..................................................................................................................................................................25


 SL-889 HDMI 2.1 Cat-3 Cable EMI Tester
 User Guide

Simplay-UG-SL889-1.1 © 2019-2020 Simplay Labs, LLC., 3
 All rights reserved. CONFIDENTIAL
Figures
Figure 1.1. SL-889 − Top View...............................................................................................................................................4
Figure 1.2. SL-889 − Front Panel View ..................................................................................................................................4
Figure 1.3. SL-889 − Rear Panel View ...................................................................................................................................5
Figure 1.4. SL-889 –Signal Path............................................................................................................................................5
Figure 1.5. Locating SL-889 Components − Top View...........................................................................................................6
Figure 1.6. LCD Display Screen Main Window ......................................................................................................................7
Figure 1.7. 12V Power Supply...............................................................................................................................................9
Figure 1.8. 2M Golden Cat-3 HDMI 2.1 Cable.......................................................................................................................9
Figure 2.1. Pre-Test: Connecting the DUT cable with optional monitor output.................................................................11
Figure 2.2. Test: Connecting the DUT cable in Normal Operation .....................................................................................12
Figure 2.3. SL-889 Operation: Boot Down Counter ............................................................................................................12
Figure 2.4. SL-889 Operation: C0 Resolution, V1.00 Firmware, No HDMI Cable Attached ...............................................13
Figure 2.5. SL-889 Operation: Selector ..............................................................................................................................13
Figure 2.6. SL-889 Operation: C4 Resolution, No Cable Attached .....................................................................................13
Figure 2.7. SL-889 Operation: C4 Resolution, TMDS 185 MHz link, HDMI Cable Attached ...............................................14
Figure 2.8. SL-889 Operation: Optional Monitor Output...................................................................................................14
Figure 2.9. CISPR recommended DUT cable placement inside chamber............................................................................15
Figure 2.10. HDMI Forum recommended DUT cable placement inside chamber ..............................................................15
Figure 3.1. 30MHz-1000MHz Scan......................................................................................................................................16
Figure 3.2. 1000MHz-6000MHz Scan..................................................................................................................................16
Figure 3.3. HDMI Forum recommended DUT cable placement inside chamber ................................................................17

Figure A.1. SimplayLabs SL-889 Web Support Page ...........................................................................................................18
Figure A.2. SL-889 Firmware Version Display .....................................................................................................................18
Figure A.3. SL-889 Firmware update via network port.......................................................................................................19


SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

1. Overview

The SL-889 HDMI 2.1 Cat-3 Cable EMI Tester is designed for radiated emissions testing of HDMI 2.1 Ultra High Speed

cables and is compliant to the latest High Definition Multimedia Interface (HDMI®) 2.1 specifications.

This User Guide provides details on how to setup and test cables for radiated emissions for compliance in a EMI

chamber to HDMI 2.1 specifications.

For the latest updates to documentation or software updates, see online at:

https://www.simplaylabs.com/ProductsServices/Products/HDMI/ .

SL-889 Hardware

Figure 1.1, Figure 1.2, and Figure 1.3 show the top view, the front panel view, and the rear panel view of the SL-889,

respectively.

Figure 1.1. SL-889 −Top View

Figure 1.2. SL-889 −Front Panel View

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

Figure 1.3. SL-889 −Rear Panel View

1.1.1. Signal Path

Figure 1.3 shows the internal and external signal path of the SL-889. An internal Video Generator generates an ITU-R

BT-1729 test pattern which is fed to an HDMI transmitter. When an external HDMI cable DUT is connected, the Tx will

begin transmitting a HDMI 2.1 Video/Audio data stream to the built-in HDMI receiver. At this point the Test Equipment

can be used inside an RF chamber, and radiated emissions scans may be taken. An optional LCD monitor can be used

during Pre-Scan operations to visually verify the signal has been successfully received across the DUT cable.

Figure 1.4. SL-889 –Signal Path

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

SL-889 Controls, Indicators, and Interface Connectors

Figure 1.5 shows the location of the SL-889 enclosure features: input and output ports, power and ethernet, LCD

display, and resolution select rotary switch.

Figure 1.5. Locating SL-889 Components −Top View

Item

Label

Description

Network

RJ45 Ethernet Port.

+12 V DC

DC power receptacle, 12 V 2 A.

HDMI OUT1

HDMI TX0 output Port. For Cable DUT Transmit.

HDMI OUT2

HDMI TX1 output Port. For Optional Display Monitor output.

HDMI IN1

HDMI RX0 input Port. For Cable DUT Receive.

Selector

Resolution Select Rotary Switch

LCD Display

Alphanumeric LCD display that shows resolution selected and connection status.

SL-889 Test Modes

The SL-889 is designed to offer the following distinct mode of operation:

•Standard Test Mode, see Section 1.3.1.

1.3.1. Standard Test Mode

In its standard test configuration, the SL-889 offers audio and video generation and reception features to enable

radiated emissions compliance testing to HDMI 2.1 specifications.

1.3.1.1. Available Standard Tests

The SL-889 is ready for use in standard test mode immediately upon delivery. These are the operations that are done in

standard test mode:

LCD Alphanumeric

Display

3 4 5

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

1. Generate a calibrated HDMI 2.1 output signal using HDMI OUT1 port

2. Receive and Analyze a HDMI 2.1 input signal using HDMI IN1 port

3. Generate an optional display monitor output signal using HDMI OUT2 port

For details of the above operations, refer to Section 2.

1.3.1.2. The SL-889 LCD Display Screen in Standard Test Mode

Figure 1.6 shows the LCD display screen of the SL-889 in standard test mode under default factory configuration.

Figure 1.6. LCD Display Screen Main Window

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

1.3.2. Devices under Test

Standard test operations are available for:

•HDMI 2.1 Cat-3 Cables

HDMI 2.1 Video Resolution Support

The SL-889 includes support for TMDS and FRL signalling:

•6 TMDS Freqencies supported with 4 Video Resolutions

•2 FRL Frequencies with 2160p60 Video Resolution

Value

Description

720x480p60 (16:9) RGB 8-bit 27 MHz -

720x480p60 (16:9) RGB 8-bit 27 MHz

720x480p60 (16:9) RGB 12-bit -40.5 MHz

1920x1080p60 RGB 8-bit 148.5 MHz

1920x1080p60 RGB 10-bit 185 MHz

3840x2160p24 RGB 8-bit 297 MHz

3840x2160p60 RGB 8-bit 594 MHz

3840x2160p60 FRL 6 GHz 4 Lane FRL

3840x2160p60 FRL 12GHz 4 Lane FRL + eARC

C9-C15

3840x2160p60 FRL 6 GHz 4 Lane FRL (Subject to change, reserved for future use)

Note: Resolutions in bold are required resolutions for HDMI 2.1 radiated emissions testing.

Inside the Box

The SL-889 delivery includes the following items:

•SL-889 HDMI 2.1 Cat-3 Cable EMI Test Tool

•SL-889-PS 12V power supply

•SL-889-GC 2M HDMI 2.1 Cat-3 Golden Test Cable

•Quick Start Guide

•Calibration Packet

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

1.5.1. 12V Power Supply

The included 12V power supply has been chosen for proper operation with the SL-889. It has been modified with the

addition of a ferrite filter for lower noise operation. Please do not substitute another supply as the results of EMI scans

cannot be guaranteed.

Figure 1.7. 12V Power Supply

1.5.2. 2M Golden Test HDMI Cat-3 Cable

The included 2M cable has been developed for specific use with the SL-889. It has been shown to have superior RF

suppression. It should be kept as a test reference cable and can be used to calibrate your SL-889 to different RF

chambers.

Figure 1.8. 2M Golden Cat-3 HDMI 2.1 Cable

SL-889 HDMI 2.1 Cat-3 Cable EMI Tester

User Guide

2. The SL-889 in Standard Test Mode

In its standard test configuration, the SL-889 offers audio and video test features to enable radiated emissions

compliance testing to HDMI 2.1 specifications.

These are the operations that are available in the standard test mode:

1. Generate a calibrated HDMI 2.1 signal output using the HDMI OUT1 port

2. Receive a HDMI 2.1 signal using the HDMI IN1 port

Calibrated HDMI 2.1 Tx Output Notes:

The SL-889 generates fixed stimulus to an HDMI 2.1 Category 3 Cable so the DUT cable’s EMC

Emission performance can be measured.

The SL-889 does not go through HDMI 2.1 FRL Link Training, and does not adjust the TX signal in

response to the RX’s measured error rate.

The documentation shipped with each SL-889 contains waveforms captured while it was sending

TMDS data at 2.97 GHz and FRL data at 12.0 GBPS.

A waveform exhibiting a Rising/Falling/Rising pattern (or a Falling/Rising/Falling pattern), with the

time between the first and last edges at a minimum, represents 2 bit times.

The included 12.0 GHz waveform was captured at 200 Picoseconds (ps) per division, with each

division internally subdivided by four tick marks.

Each 1/5th of a division is 40 ps.

A 12.5 GBPS signal would result in a bit time of 80 ps.

In the faster waveform the time between the first and last edges of the Rising/Falling/Rising

pattern is slightly more than 4 tick marks (160 ps).

One bit time is half the total time, or slightly more than 80 pS.
