DEHUMIDIFIERS
CFO-20P, CFO-40P
USER MANUAL
Content
Operation Notices
● Safety Precautions..................................................................................2
● The Refrigerant.......................................................................................1
● Operation Area........................................................................................3
●Parts Name.............................................................................................4
●Check Before Operation.........................................................................5
Operation Instructions
●Operation Method...................................................................................6
● Drainage Method
Maintenance
●Clean and Maintenance........................................................................12
Malfunction
●Troubleshooting....................................................................................15
●Producer, service, contact................................................................... 20
●Error Codes, Technical specifications
....................................................17
Note:
Graphics in this manual are only for reference. Please refer to actual
products for specific details.
....................................................................................9
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from un-
controlled waste disposal, recycle it responsibly to promote the sustainable reuse of mate-
rial resources.To return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this product for envi-
ronmental safe recycling.
Electric schematic diagram● ..................................................................19
Explanation of Symbols
Exception Clauses
Indicates a hazardous situation that, if not avoided, will
Manufacturer will bear no responsibilities when personal injury or
1.Damage the product due to improper use or misuse of the product;
2.Alter, change, maintain or use the product with other equipment without abiding
by the instruction manual of manufacturer;
product;
4.After verification, defects are due to improper operation during transportation of
regulations;
5.Operate, repair, maintain the unit without abiding by instruction manual or related
performance of parts and components that produced by other manufacturers;
6.After verification, the problem or dispute is caused by the quality specification or
majeure.
7.The damage is caused by natural calamities, bad using environment or force
3.After verification, the defect of product is directly caused by corrosive gas;
property loss is caused by the following reasons.
result in death or serious injury.
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
Indicates a hazardous situation that, if not avoided, may
result in minor or moderate injury.
Indicates important but not hazard-related information,
used to indicate risk of property damage.
Indicates a hazard that would be assigned a signal word
WARNING or CAUTION.
DANGER
WARNING
CAUTION
N OTIC E
1
The Refrigerant
WARNING
To realize the function of the air conditioner unit, a special refrigerant circulates in
the system. The used refrigerant is the fluoride R290, which is specially cleaned.
The refrigerant is flammable and inodorous. Furthermore, it can leads to explosion
under certain conditions.
Compared to common refrigerants, R290 is a nonpolluting refrigerant with no harm
to the ozonosphere. The influence upon the greenhouse effect is also lower. R290
has got very good thermodynamic features which lead to a really high energy
efficiency. The units therefore need a less filling.
Please refer to the nameplate for the charging quantity of R290.
Appliance filled with flammable gas R290.
Before install and use the appliance, read the owner’s manual first.
Before install the appliance, read the installation manual first.
Before repair the appliance, read the service manual first.
Appliance filled with flammable gas R290.
Appliance shall be installed, operated and stored in a room with a floor area larger
The appliance shall be stored in a room without continuously operating ignition sources .
(for example: open flames, an operating gas appliance or an operating electric heater.)
The appliance shall be stored in a well-ventilated area where the room size corresponds
to the room area as specified for operation.
The appliance shall be stored so as to prevent mechanical damage from occurring.
Keep any required ventilation openings clear of obstruction.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
Do not use means to accelerate the defrosting process or toclean, other than those
recommended by the manufacturer.
Servicing shall be performed only as recommended by the manufacturer.
Should repair be necessary, contact your nearest authorized Service Centre.
Any repairs carried out by unqualified personnel may be dangerous.
Compliance with national gas regulations shall be observed.
Read specialist’s manual.
than 4 m .
2
● This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory ormental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the app-
liance in a safe way and understand the hazards involved.
● Children shall not play with the appliance.
● Cleaning and user maintenance shall not be made by children
without supervision.
● Before operation, please check the power cord if it complies with
the requirement indicated on the nameplate.
● Before cleaning, please turn it off and unplug the dehumidifier.
● Make sure the power cord is not pressed by any hard objects.
● Do not remove the power plug or move unit by pulling the power
cord.
● Do not operate any heating appliances near the dehumidifier.
● Do not move get the power plug with wet hands.
● Please use grounded power cord and make sure it's well conne-
cted and not damaged.
● Children and disabled people are not allowed to use the dehum-
idifier without supervision.
● Keep children from playing or climbing on the dehumidifier.
● Memory function is included in this dehumidifier. When nobody
is taking care of the unit, please turn it off and remove the power
plug or disconnect power.
● Do not repair or disassemble the unit by yourself.
● If abnormal condition occurs (e.g. burned smell), please discon-
nect power at once and then contact local dealer.
● Dehumidifier can not be disposed of everywhere. If you want to
get rid of this dehumidifier, please check with local handling dis-
posal or information service center about what to do.
● Do not use an extension cord.
Safety Precautions
2
● The appliance shall be installed in accordance with national wiring
regulations.
● If the SUPPLY CORD is damaged, it must be replaced by the
● Far away from fire source, inflammable and explosive objects.
● Prohibit operating the unit in the bathroom or laundry room.
manufacturer, its service agent or similarly qualified person in
order to avoid a hazard.
3
Operation Area
temperature will not below 5°C or
above 32°C. The suggested range of relative humidity is between 30% and 90%.
●
●
●
During operation, please make sure there's enough space around the unit.
During operation, the nearby enclosed space, such as wardrobe can't be
dehumidified.
This dehumidifier is intended for indoor applications only. It should not be used
for commercial or industrial applications.
● Close all doors, windows and other outside openings of the room to improve
the working effect.
● Please keep the air inlet/outlet clean and not blocked.
●Avoid direct sunlight.
Note:
Note:
● The dehumidifier has rollers to aid placement. Do not attempt to roll the
dehumidifier on carpet or over objects. Otherwise, water may spill out from
the bucket or the dehumidifier may get stuck by the objects.
● Please stop operation before moving the dehumidifier. The tilting angle can't
be too large when moving the unit. Do not move the unit along front or back
direction.
20cm at least
20cm at least
50cm at least
Parts Name
Front Side
Back Side
4
Control Panel
Air outlet
Cover plate
(continous drainge)
Air inlet
Water Bucket
Fixing hole of
power cord
Power cord
Check Before Operation
aced.
Below are the checking steps:
1. Hold the handles on both sides of the water bucket and pull it out following the
arrow direction.
moved a little after long-time transportation. If it's not placed properly, move it
to the correct position by hand.
3. Replace the bucket as instructed in step 1.
Float
Correct Position Wrong Position
5
6
Operation Method
Basic Functions of the Buttons
123456
Notes:
● Do not remove the bucket while unit is
● Water bucker must be correctly installed for operation.
in operation.
● If you want to use drain hose to drain water away, please install the hose acc-
ording to section "Drainage method".
● Each time pressing the effective button on the control panel will give out a
"beep" sound.
● When power is connected, power indicator on the control panel will be on and
1ON/OFF Button
3Timer Button
Press Timer button to set timer on or timer off. The timer can be set in 1h
increment among 0-24h with each press of Timer button. If hold the Timer
button, time will increase rapidly circularly. After timer is set, time will be
displayed for 5s and timer indicator will be on.
Speed Indicator
Timer Indicator
Filter Cleaning
Indicator
Dehumidify Mode
Indicator
Bucket Full
Indicator
Display Window
Wind Direction Indicator
FanMode
Wind
Direc
Humidity Timer
High Med LowTimer ON/OFFSmart Cont Quiet DryWater Full Swing Fixed
Angle
Filter Clean
Press Fan button can set high, medium or low fan speed. When the
corresponding indicator is on, it indicates the current fan speed has been set.
2Fan Button
7
Press Humidity button to set your required humidity. If hold Humidity
button, humidity can be set in 10% increment among 30%-80% circularly.
After that, the set humidity will be displayed for 5s.
4Humidity Button
When swing of horizontal louver is needed, press Wind Direc button to
select swing or fixed angle. When Swing light of Wind Direc indicator is on,
the horizontal louver begins to swing; when Fixed Angle light is on, the
horizontal louver stays at current position.
6Wind Direc Button
Press Mode button can set 4 kinds of dehumidify mode - Smart, Cont.,
Quiet and Dry.
● If smart indicator is on, it indicates the unit enters into smart mode. The
unit will intelligently select the comfortable humidity for human according
to current temperature.
● If cont indicator is on, it indicates the unit enter into continuous dehumidify
mode. The unit will always dehumidify only until the humidity is decreased
to the inapplicable humidity of human.
● If the quiet indicator is on, the unit enter into quiet mode. The unit will
intelligently select the comfortable humidity for human according to current
temperature. The unit will operate at the fan speed whose noise is the
lowest. The fan speed can't be adjusted.
● If the dry indicator is on, the unit enters into dry mode. After clothes are
dried, room humidity will be kept at certain range to prevent mildew. Under
dry mode, fan speed and humidity can't be adjusted.
5Mode Button
Note:
● Under smart mode and quiet mode, if room humidity is lower than set
humidity, or lower than the defaulted comfortable temperature, the unit will
stop dehumidifying.
● Under dry mode and cont mode, the humidity can't be adjusted. Under dry
mode and quiet mode, fan speed can't be adjusted.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Sinclair Luftentfeuchter Handbücher
Sinclair
Sinclair CFO-20N Bedienungsanleitung
Sinclair
Sinclair CFO-16E Bedienungsanleitung
Sinclair
Sinclair CFO-12E Bedienungsanleitung
Sinclair
Sinclair CFO-18P Bedienungsanleitung
Sinclair
Sinclair R-9112 Bedienungsanleitung
Sinclair
Sinclair CFO-45E Bedienungsanleitung
Sinclair
Sinclair CFO-20N Bedienungsanleitung
Sinclair
Sinclair CFO-16E Bedienungsanleitung
