Siqura FD12 Betriebsanleitung

Installation

and Operation

Siqura FD12

Vandal Proof Fixed Dome Camera

Contents

CONTENTS

1. PREFACE .........................................................................................................1

1.1. CHANGE LOG ...................................................................................................2

2. CAUTIONS.......................................................................................................3

3. OVERVIEW ......................................................................................................5

3.1. PRODUCT FEATURES ...........................................................................................5

4. PACKAGE CONTENTS ........................................................................................7

5. CAMERA CONFIGURATION .................................................................................9

5.1. PARTS DEFINITION.............................................................................................9

5.2. SIQURA FD12 SWITCHES,CONNECTORS,AND BUTTONS..................................................9

5.3. 10-POLE DIP SWITCH....................................................................................... 10

5.3.1. DIP switch settings ................................................................................ 11

5.4. TERMINAL BOARD ............................................................................................ 12

6. INSTALLATION............................................................................................... 13

6.1. HARD CEILING INSTALLATION............................................................................... 13

6.2. 4S MOUNT ELECTRICAL BOX................................................................................ 17

APPENDIX A: TECHNICAL SPECIFICATION................................................................... 19

APPENDIX B: TROUBLESHOOTING ............................................................................. 21

Preface

1. PREFACE

The information given in this manual was current when published. The company reserves the

right to revise and improve its products. All specifications are subject to change without

notice. The most recent version of this manual is on the Optelecom-NKF website, at

www.optelecom-nkf.com.

Notice

To work with the Siqura FD12 camera, an installer or technician must have the

following minimum qualifications:

•A basic knowledge of CCTV systems and their components.

•A basic knowledge of electrical wiring, and low-voltage electrical connections.

•Have read this manual completely.

Under copyright laws, the contents of this installation manual may not be copied,

photocopied, translated, reproduced or reduced to any electronic medium or machine-

readable format, in whole or in part, without prior written permission of the company.

Important information

Before proceeding, please read and observe all instructions and warnings in this manual.

Retain this manual with the original bill of sale for future reference and, if necessary,

warranty service. When unpacking your unit, check for missing or damaged items. If any

item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT.

Contact Optelecom-NKF for assistance.

Preface

Regulations

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received,

including interference that may cause undesired

operation.

This symbol on the product or on its packaging

indicates that this product shall not be treated as

household waste in accordance with Directive

2002/96/EC. Instead it shall be handed over to the

applicable collection point for the recycling of electrical

and electronic equipment. By proper waste handling of

this product you ensure that it has no negative

consequences for the environment and human health,

which could otherwise be caused if this product is

thrown into the garbage bin. The recycling of materials

will help to conserve natural resources.

For more detailed information about recycling of this

product, please contact your local city office, your

household waste disposal service or the seller of the

product.

Compliance is evidenced by written declaration from our

suppliers, assuring that any potential trace

contamination levels of restricted substances are below

the maximum level set by EU Directive 2002/95/EC, or

are exempted due to their application.

1.1. Change Log

Manual version 1.1 contains corrected power supply information.

Manual version 1.2 contains corrected day/night information.

Manual version 1.3 contains corrected pin connector assignment information.

Cautions

2. CAUTIONS

Only qualified service personnel or system installers should install and connect

this product.

Handle the camera carefully.

Avoid striking, shaking, etc. as the camera can be damaged by improper handing or

storage.

Do not disassemble the camera.

To prevent electric shock, do not remove screws or covers. There are no user serviceable

parts inside. If necessary, ask a qualified technician for servicing.

Do not operate the camera beyond the specified temperature, humidity and

power source ratings.

Verify the power source is appropriate before you plug in and operate the unit.

If the camera is installed outdoors, make sure it is sheltered from direct sunlight.

Do not use strong or abrasive detergents when cleaning the camera.

Use a dry cloth to clean the camera when it is dirty. If the dirt is hard to remove, use a

mild detergent and wipe gently. To clean the lens, use lens tissue or a cotton tipped

applicator and ethanol. DO NOT clean the lens with strong detergents.

Never face the camera towards the sun.

Do not aim the camera at bright objects. Whether the camera is in use or not, never aim

it at the sun or other extremely bright objects. Otherwise, the camera may be damaged.

Overview

3. OVERVIEW

The Siqura FD12 is a 1/3” CCD color fixed dome camera designed for both indoor and

outdoor video surveillance systems with ultraviolet ray prevention and vandal-proof housing,

and compliant with the international IP66 water resistant standard. This dome camera is

equipped with Back Light Compensation, Auto Exposure and Automatic Gain Control

functions that work together to achieve a consistent video output level, while a signal-to-

noise ratio of more than 50 dB and 520 TVL High Resolution ensure image clarity.

Additionally, the camera’s built-in Blue Glass Optical Filter allows the user to improve and

enhance pictures’ hue. With integrated features and functions, the Siqura FD12 promises

tight security and provides optimum pictures.

3.1. Product Features

Dome Body

•Dust- and waterproof (IP 66 Standard)

•Special nail design guards against theft

•Vandal-proof structure with metallic base

•3-D hinge (Pan, Tilt and Rotation)

•Internal Heater and Fan

•Mounting: Hard Ceiling, 4S Electrical Box Support

•AC 24V Dual Power Support

Camera

•Horizontal resolution > 520 TV lines (540 TVL Max.)

•Day/Night function

•High Sensitivity, Low Smear and High S/N Ratio

•Anti-color-rolling

•CCD Blemish Compensation

•Backlight Compensation (BLC)

•Automatic Tracing White Balance

•Automatic Iris Control

•Automatic Gain Control (AGC)

•Mirror Function

•Electronic Shutter

•Flickerless Mode

•Suppress Function

•Built-in Anti-aliasing Optical Low Pass Filter

Refer to Appendix A: Technical Specification for more detailed information.
