Usage and installation manual
for the BOT-25 water tank around the smoke pipe
The Skamet water tank around the smoke pipe is meant for warming up the sauna water.
In conditions, where there is no on-site water system and the obtained water is retrieved
from the river, lake or well.
The water tank is suitable for all of the wood burning stoves which smoke pipe diameters
are 115mm. The water pipe is installed directly on to the chimney pipe and smoke pipes ex-
tend from the water tank to the exhaust gas duct. The water tank has a cylindrical shape,
with a covered container on top, which diameter is 300mm. The Skamet water tank around
the smoke pipe accommodates 25 l of water. The water pipe is equipped with a pipe tip
(internalthread ½“), where a faucet is adaptable. The product is made of either 2mm black
metal and finished off with a heat resistant paint or 2mm stainless steal.
The water tank uses the combustion temperatures, being released from the smoke pipes
to heat the water. Because the installed water tank to the smoke pipe by its capacity is
small and effective (depending on the tank distance from the oven) then the water might
start to boil. To avoid the water from boiling, it is advised to pour out some of the hot water
and to add cool water.
Installation
Connect the smoke pipe to the tank. The Skamet production does not require the usage of
transitions and joints. For the other firm products ensure, that the smoke pipe extending
from the oven, external diameter would be 115mm. Otherwise it would be necessaryto use
transitions or joints.
Ensure that the product is firmly attached to the smoke pipe. Connect the tank upper part
with the smoke pipe or knee and then to the chimney.
Good to know
• Keep the tank as full as possible. Welds can crack, when heating the water tank empty.
• Do not use salt water. Salty water causes corrosion and shortens the longevity of the
tank.
• Clean the tank regularly. During consumption, rust can precipitate to the bottom of the
tank (specially for the black metal tank). It is possible to remove it, through the faucet
attached to the tank. Prior to each usage it is possible to eliminate the precipitated rust
through the faucet. Clean the tank with water and clean cloth. Do not use any chemicals
for cleaning.
• Do not let the water freeze in the tank. During freezing the water physical compounds
change, which damage the tank and welding interfaces.
If the product instructions have not been followed, then the product warranty will not apply.
BOT-25 General data
Hight: 650 mm
Diameter: 300 mm
Flue pipe diameter: 115 mm
Capacity: 25 l
Weight: 10 kg
