SNAIGE CD40DM Bedienungsanleitung

BEVERAGE REFRIGERATOR

Instruction for Use

DEAR CUSTOMER!

CAREFULLY READ THE INSTRUCTION MANUAL. If instructions are not followed, there is a

risk of injury, damage of the appliance and loss of the right to free warranty service.

The Manufacturer shall not be held liable for damage arising from the failure to observe

the instructions contained in this manual.

Keep this manual for future reference, or to pass it over to the next user.

General information:

The appliance is a vertical beverage refrigerator with glass doors and with a fan and is

designed for cooling and storing bottled beverages only.

This appliance is intended for commercial use!

THE MANUFACTURER GUARANTEES RELIABLE OPERATION OF THE BEVERAGE

REFRIGERATOR WHEN THE AMBIENT TEMPERATURE IS +16 TO +32 DEGREES CELSIUS

AND THE RELATIVE AIR HUMIDITY NOT GREATER THAN 60 PER CENT.

GUIDELINES CONCERNING THE SAFETY OF USE

General safety requirements:

–WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

–WARNING: Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type recommended by the

manufacturer.

–WARNING: When positioning the appliance, ensure the supply cord is not

trapped or damaged.

–WARNING: Do not locate multiple portable socket-outlets or portable power

supplies at the rear of the appliance.

WARNING: Do not damage the appliance refrigeration system. It contains

the refrigerant gas R600a. If the refrigeration system is damaged:

•Do not use any open flame.

•Avoid sparks-do not turn on any electrical appliances or lighting fixtures.

•Immediately ventilate the room: air the room in which the appliance is placed for a

few minutes (the size of the room for a product containing isobuthane / R600a

must be at least 4 m3) to avoid damage to the cooling system.

C-Pentane is used as blowing agent in the insulation foam and it is a

flammable gas.

–WARNING: Disposal of the appliance should be according to national rules.

–This appliance is not designed for the storage of explosive substances such as

aerosol cans with a flammable propellant.

–It is prohibited to store petrol and other flammable liquids near the appliance.

–The appliance should be used only for storing foodstuffs.

Children and vulnerable people safety:

–Do not allow children to play with the packaging material from the appliance.

–This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

–Children aged from 3 to 8 years are allowed to load and unload refrigerating

appliances.

Requirements for the connection to the mains:

–The appliance should only be connected to an earthed socket installed in

accordance with the regulations. Make sure that the supply voltage corresponds

with the voltage marked on the rating label. This product complies with all binding

CE labelling directives. The earthed electrical socket by which the appliance is

connected to the mains should be in an accessible place. It is a legal requirement

that the appliance is properly earthed. The manufacturer will not be held liable for

any damage or injury which may result from the failure to fulfil this requirement.

–To avoid the exposure to danger, always have faulty cable be replaced only by

the manufacturer, by our customer service or by qualified person and with a cable

of the same type.

–It is forbidden to readjust or modify any parts of the unit. It is crucial not to

damage the capillary tube visible in the compressor recess. The tube may not be

bent, straightened or wound. If the capillary tube is damaged by the user the

guarantee will be void.

–Do not use adapters, multiple sockets and two-wire extension leads. If it is

necessary to use the extension lead, it must be equipped with a protection ring

and a single socket and must have a VDE/GS safety certificate. If an extension

lead is used (with a protection ring and safety certificate), its socket must be

located at a safe distance, away from the sinks, and must not be in a place where

it could be flooded by water or waste water.

–The frequency and power of the electricity supply in your house must conform to

the general data parameters of the appliance as it is shown in the product label.

–When positioning the appliance, be careful that the electrical cord isn’t squeezed

in order to avoid its damage. Do not store heavy objects such as cooling devices

or other devices next the appliance in such a way that they could squeeze and

damage the electrical cord. This can cause a short circuit and a fire.

–Make sure that the plug of the electrical cord is not squeezed by the back wall of

the appliance or otherwise damaged. A damaged plug can be the cause of a fire!

CAUTION! If the installed interior lighting or the advertising panel’s light-

emitting diode (LED) lamp for the cooling device is not functioning, contact

the maintenance and repair representative for replacements. Lamps can be

replaced only by the maintenance and repair representative

Do not try repair the appliance on your own. Always contact an authorized

technician. To avoid the exposure to danger, always have faulty cable be

replaced only by the manufacturer, by our customer service or by qualified

person whit a cable of same type.

Requirements for safe use:

–It is forbidden to use a technically damaged appliance.

–If the appliance is unplugged (for cleaning, moving to another place, etc.), it may

be repeatedly switched on after 15 min.

–When performing activities, such as cleaning, maintenance or moving, the

appliance must be completely disconnected from power supply (by pulling the plug

out from the socket). Do not pull on the cord, but hold the body of the plug

instead.

–Do not place any switched on electrical devices on top of the appliance because

this may cause ignition of plastic parts.

–Do not place any dishes with liquids on top of the appliance and do not keep

flowers in vases or other liquid-filled vessels on the appliance.

–Do not climb on or sit on the appliance, do not lean on or hang on the appliance

doors and do not allow children to do this.

–Do not use water spray and steam to clean the appliance.

The appliance should be transported in the vertical position. The

manufacturer will not be responsible for any damage of the appliance that

results from non-compliance with the instructions for transportation.

INSTALLATION AND OPERATING CONDITIONS

Positioning:

•This appliance can be installed in a dry, well ventilated indoor where the ambient

temperature corresponds to the climate class indicated on the rating plate of the

appliance.

Do not install this appliance in areas that are too humid or too colds,

such as the construction appendices, garages or wine cellars. Place

the appliance away from heat sources such as kitchen stove/oven,

radiators, or direct sunlight. The appliance must not touch any pipes

for heating, gas or water supply, or any other electrical devices.

Minimum distances from the heat sources:

- from the electric gas and other ovens - 30 mm,

- from oil or coal fired ovens - 300 mm,

- from built-in ovens - 50 mm

If there is no possibility of ensuring the above- mentioned distances, provide an

appropriate insulation board.

•Do not cover the ventilation holes at the

top of the appliances –it must be a

good air circulation around the

appliance. There should be a gap of at

least 10 cm between the top of the

appliance body and any furniture that

may be above it. If this requirement is

not followed, the appliance consumes

more electrical energy and its

compressor may overheat. 

•If the appliance is placed in a corner, a

gap of at least 1 cm must be left

between the appliance body and the

wall. 

•The appliance must stand on a level

surface and must not touch the wall. If necessary, regulate the height of the appliance

by adjusting the levelling feet: by turning them clockwise –the front of the appliance

rises, by turning them counter clockwise –it comes down. If the appliance is tilted

slightly backward –the doors will close by themselves.

Preparing for operation:

•It is recommended to prepare the appliance for operation with a helper.

•Remove package. Lift the appliance away from foamed polystyrene base.Therefore take

out adhesive tapes from sides and simply lift the appliance up and take out the board.

Strip adhesive tapes off and open the door. Remove the spacer above the door.

•When positioning the appliance in chosen location, it will move more easily into position

if you lift the front a little and incline it backward allowing it to roll on its casters.

•When placing, moving, lifting the appliance, do not hold the door handles, do

not pull the condenser at the rear part of the refrigerator and do not touch the

compressor unit.

•The appliance should not be connected to the mains until all packing and

transport materials aren’t removed. Suitably dispose the packaging material.

First use:

•Before using the appliance for the first time, the interior and all internal accessories

should be washed with lukewarm water and some neutral soap to remove the typical

smell of a brandnew product, then dried thoroughly.

•The unit should only be transported in its vertical position; do not tilt any more than

30°.

•Once the unit has been positioned, wait for about 30 minutes before it is connected to

the mains.

If the unit has been tilted more than 30° during transport:Wait at least 4

hours before connecting the appliance to the power supply. If this is not

done, the appliance compressor may fail.

•When first starting-up or after a period out of use, before putting the products in the

compartment let the appliance run at least 2 hours.

DESCRIPTION OF THE APPLIANCE, BASIC PARTS

The appliance accessories listed below may differ from the accessories of the

appliance you have bought in quantity and in design. This description is adapted for

entire group of refrigerator-freezer.



Advertising panel

Fan. The fan for the appliance is

activated and operates

continuously!

Thermostat - temperature

regulator

Shelves

Interior lighting on/off button

Symbol “|”:on; “O”: off

Condenser

Advertising panel light on/of

button. Symbol “|”:on; “O”: off.

Thaw water drip tray

LED lighting

Compressor

TEMPERATURE REGULATION

The appliance is activated by connecting it to the mains.

The temperature in the appliance is controlled using the thermostat knob 2(see fig. 1) by

turning it to one side or the other. Turning the thermostat dial clockwise reduces the

temperature in the appliance. The temperature indication in digits is shown beside the

thermostat knob. The number “0, 2, 3, 4, 5”do not mean a specific temperatures.

The temperature can be set within a 0 °C to +10 °C range.

The temperature is regulated on a scale of five digits.

0= Compressor is switched off. WARNING! Electric current is not switched off.

With the temperature control in position ‘0’, only the compressor is switched off, while the

fan is still running.

1= highest temperature (lowest cooling)

5= lowest temperature (highest cooling)

If the room is cool, the appliance cools less. The temperature in the appliance may

therefore rise. Use the thermostat wheel to set a lower temperature.

THE TEMPERATURE IN THE APPLIANCE COMPARTMENT MAY VARY DEPENDING

ON AMBIENT TEMPERATURE, THE AMOUNT OF BEVERAGES, THE TEMPERATURE

OF THE BEVERAGES, AND HOW OFTEN THE APPLIANCE DOOR IS OPENED AND

CLOSED. Therefore we recommend:

•locate the appliance away from heat sources,

•beverages placed in the appliance should not be warmer than the room temperature,

•appliance door must not to be left open.

DEFROSTING, CLEANING AND CARE

THE REFRIGERATOR COMPARTMENT defrosts automatically. Drops of ice that form on the

back wall of the refrigerator compartment thaw during the time the compressor is not working

and the thaw water runs down the thaw water runoff channel to the tray on top of the

compressor (Fig. 1), where it evaporates.

REGULARLY CLEAN THE APPLIANCE.

Note: before cleaning the cooling device and its rear compartment part,

the device must be disconnected from the mains by unplugging.

•Protect the appliance inner surfaces and plastic parts from fats, acids and sauces. In

case of accidental spills –immediately clean with warm soapy water

or dishwashing detergent. Wipe dry.

•Regularly clean the hermetic gaskets of the doors. Wipe dry.

•At least once a year clean dust away from the back part of the

appliance body and the compressor. A soft brush, electrostatic cloth

or vacuum cleaner may be used for cleaning.

•Regularly clean the thaw water channel space in the refrigerator

with a special cleaner for that purpose (see fig.).

•DO NOT use detergents containing abrasive particles, acid, alcohol or benzene for

cleaning the appliance inner and outer surfaces. DO NOT use for cleaning cloths or

sponges that have coarse surfaces intended for scrubbing.

•If the appliance is to be left switched off for an extended period, leave its doors open.

CHANGING THE OPENING DIRECTION OF THE DOORS

It is recommended that changing the opening direction of the doors should be done with a

helper. You will need two spanners No. 8 and No. 10 and a head screwdriver.

When changing the opening direction of the doors, YOU CAN NOT lay the

refrigerator horizontally!

Warning: Always disconnect the unit from the mains before any maintenance or repair

work is carried out.

Before you start, please note the following:

∙ Always ensure that the correct number of washers is used on all hinge bolts and screws.

∙ So that the doors can close tightly against the frame, take the utmost care that they are

properly aligned during reassembly.

Do the actions below in the order they are listed (see fig.):

1. Turn off the appliance and pull the plug out of the electricity supply socket.

2. Remove the two screws (8) and separate the bottom bracket (10) together with the

washers and gaskets (9) on the small axle.

3. Remove the two screws (7)and separate the bracket (5) and the gasket (6).

4. Separate the door (4).

5. Remove the 4 screws (1) at the top of the advertising panel, separate the top of the

advertising panel (11), remove the front part of the advertising panel (12), and then

remove 4 screws (13) and separate the advertising panel; then loosen the 2 screws

(14) and transfer the upper bracket (15) to the other side. Assemble the advertising

panel in reverse order.

6. Turn the door 180°, insert the upper axle and mount the door on it.

7. Remove the mounting screws (2)from the door, separate the handle (3) and attach it

by screwing the screws into the holes on same side.

8. Using the supplied washers and gaskets, attach the lower bracket (10) on the opposite

side of the cooler, but first attach the bracket axle to the door. Screw in the bracket (5)

on the opposite side of the cooler.

CAUTION! Wait at least 4 hours before re-connecting the unit to the mains.

OPERATION PROBLEMS AND THEIR SOLUTIONS. What if …

•The appliance is plugged in to the mains but it does not work. Check if your

house electricity supply installations are in order. Check if the plug is correctly inserted

into the electricity supply socket.

•The noise has become louder. Check if the appliance is standing stable, on a level

place. To make it level, regulate the front feet. Check if the appliance is not touching

any furniture and if no part of the refrigeration system at the back part of the appliance

body is touching the wall. Pull the appliance away from any furniture or walls. Check if

the cause of increased noise isn’t due to bottles, cans in the appliance that might be

touching each other.

Andere Handbücher für CD40DM

Inhaltsverzeichnis

Andere SNAIGE Kühlschrank Handbücher

SNAIGE

SNAIGE C 29SM Bedienungsanleitung

SNAIGE

SNAIGE RF31SM Bedienungsanleitung

SNAIGE

SNAIGE CD29DM Bedienungsanleitung

SNAIGE

SNAIGE CD48DM-S300BD Bedienungsanleitung

SNAIGE

SNAIGE R 13SM Bedienungsanleitung

SNAIGE

SNAIGE FR27SM Bedienungsanleitung

SNAIGE

SNAIGE CC70MF Bedienungsanleitung

SNAIGE

SNAIGE RF53SG Bedienungsanleitung

SNAIGE

SNAIGE R 13SM Bedienungsanleitung

SNAIGE

SNAIGE FR240 Bedienungsanleitung

SNAIGE

SNAIGE RF27SM Bedienungsanleitung

SNAIGE

SNAIGE SGM020P2AA Series Handbuch

SNAIGE

SNAIGE WD35SM Bedienungsanleitung

SNAIGE

SNAIGE CD290-1004 Bedienungsanleitung

SNAIGE

SNAIGE MD40DD Bedienungsanleitung

SNAIGE

SNAIGE C 31SM Bedienungsanleitung

SNAIGE

SNAIGE R 130 Bedienungsanleitung

SNAIGE

SNAIGE RF62FB-TNCBNE0 Bedienungsanleitung

SNAIGE

SNAIGE Fresh INN RF53SM Bedienungsanleitung

SNAIGE

SNAIGE MD14DC Bedienungsanleitung

SNAIGE

SNAIGE C 14SM Bedienungsanleitung

SNAIGE

SNAIGE MD40DC Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
