Soltech VIOS Bedienungsanleitung

6.8W / 800LM

4.0Ah / 3.7V

SMD 2835 X 60PCS

4.4 Wp, Mono-crystalline Silicon

3 Different Modes

120° ≤ 19.7ft

39.3 ft

IP65

3 YEARS

35,000 hrs

≤ 13.1 ft

Solar Light X 1, Accessory Bag X 1,

User Manual X 1, Measure Card X1

SPECIFICATIONS

POWER / LUMEN

LED

LI-ION BATTERY

SOLAR PANEL

WORKING MODE

DETECTION ANGLE / AREA

VISIBLE DISTANCE

IP DEGREE

WARRANTY

LIFESPAN

INSTALLATION HEIGHT

PACKING

011

INTRODUCTION

1. This is a solar powered lamp, please install it in a

location where it can get enough sunshine.

2. Please note the duration of the light depends on sun

intake & weather.

3. The lamp will automatically turn on at dusk.

4. Built-in IC with over-charge, over-discharge, and

over-voltage protection.

Warning

1. The lamp is equipped with internal batteries. Non-professionals

please do not disassemble the lamp.

2. Please do not dispose the battery in household garbage to

avoid explosion.

WATERPROOF SUPER

BRIGHT

CORDLESS DUSK TO

DOWN SENSOR

MOTION

SENSOR

LOW

COST

SOLTECH LLC reserves the right to update all product data sheets at any time. Consult

SOLTECH marketing specialists for publication updates at www.soltechlighting.com

SOLTECH offers

advanced LED

technology that

is eco-friendly

and utilizes

clean energy.

VIOS

1460 Park Avenue.

Emeryville CA 94608 USA

www.soltechlighting.com

Please read and follow all instructions to operate. Save this

manual for future reference.

SOLAR LED WALL LIGHT

6.8W 800LM

4,000K

INSTALLATION

1. Please use the measure card to correctly

position the hole drillings then drill 3 holes

of 6mm

2. Fix 3 expansion plugs into the holes

3. Fix 3 screws into the expansion plugs leaving

spare space to hang & secure the light.

4. Hang the notch onto the screws and fasten

the lamp

5. Press the power button on the back to

program the operating mode

MODE A

Automatically turn on at dusk (< 30 Lux) and remains

at 20% brightness for 5 hours then turns off.

Measure Card X 1

Power Button

Expansion

Plugs X 3

Light X 1

Screws X 3

6mm

Please press the power button to program an

operating mode:

Press 1 time for MODE A

Press 2 times for MODE B

Press 3 times for MODE C

Press 4 times to TURN OFF

OPERATING

MODES

MODE B

Automatically turns on to full brightness (800LM)

when motion is detected in the range ≤19.7ft and then

dims to 3% brightness in 20 seconds of no motion.

MODE C

Automatically turns on to full brightness (800LM)

when motion is detected in the range ≤19.7ft and

then turns off in 30 seconds of no motion.

120° 120°
