Sony Ericsson Walkman Phone Bedienungsanleitung

April 2006

etting

tarted

Transfer and listen to music

Enjoy your WALKMAN™ phone with your favourite music

Getting started Transfer and listen to music

2April 2006

Contents

Introduction ............................................................................................... 3

Overview ................................................................................................ 3

Install Disc2Phone ..................................................................................... 3

System requirements ............................................................................. 4

Install from the CD ................................................................................. 4

Download from the Web and install ....................................................... 4

Connect the USB cable ............................................................................. 5

Transfer music ........................................................................................... 5

Using Disc2Phone to add music ............................................................ 5

Using Windows Explorer to add music .................................................. 6

Using Windows Media Player 10 to add music ..................................... 7

Using iTunes 6 to add music ................................................................. 7

Use WALKMAN™ player to listen to music ............................................... 8

WALKMAN™ player controls ................................................................. 8

Browsing files ......................................................................................... 8

Playlists .................................................................................................. 9

WALKMAN™ player options .................................................................. 9

Additional information ................................................................................ 9

Getting started Transfer and listen to music

3April 2006

Introduction

Instruction symbols

The following instruction symbols may appear in this Getting started guide:

Overview

You can add music to your phone by using a computer connected to the phone via the USB cable.

You can use the following computer software to transfer music from a computer to the phone:

• Disc2Phone, which is included on the CD that comes with the phone

•Windows®Explorer

• Windows® Media® Player 10

• iTunes 6

Install Disc2Phone

The Disc2Phone software, included on the CD that comes with your phone, provides the possibility

to transfer music from CDs or your computer to your phone. You can also download the Disc2Phone

software from www.sonyericsson.com/support.

Note

Indicates that a service or function is network- or subscription-dependent. Contact your network

operator for details.

% See also page ...

}Use the selection keys or the navigation key to scroll and select.

Press the navigation key centre.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

Disc2Phone requires Microsoft .NET Framework 1.1 and .NET Framework 1.1 SP1

(available on the CD and can be installed if needed).

Getting started Transfer and listen to music

4April 2006

System requirements

The general system requirements are:

At least 100 MB free hard disk space, an Internet connection (for application activation and Gracenote CD

identification) and installed .NET Framework 1.1 SP1 (available on the CD and can be installed if needed).

• Windows 2000 (SP3/SP4): 128 MB RAM, 900 MHz

• Windows XP Home or Pro (SP1/SP2): 128 MB RAM, 900 MHz

Install from the CD

To install Disc2Phone from the PC Suite CD

1. Insert the CD that came with the phone. The CD should start automatically, if not:

click Start/Run... and type in D:/start.exe and click OK (D: is the CD drive letter on the system).

2. Select language.

3. Click Install in the Disc2Phone section.

4. If needed, follow the instructions to install .NET Framework 1.1 SP1 from the CD.

5. InstallShield Wizard: Click Next to continue the installation.

6. InstallShield Wizard: Read and accept the licence agreement, then click Next.

7. InstallShield Wizard: Click Next to install to the default folder.

8. InstallShield Wizard: Click Install to begin the installation.

9. InstallShield Wizard: Click Finish to exit the wizard.

Download from the Web and install

To download the latest version of the Disc2Phone software

1. In your Internet browser, go to www.sonyericsson.com/support.

2. Select a region and country.

3. Select a phone from the list or enter your phone model in the text field.

4. Select Software downloads.

5. Select the Disc2Phone Setup X.X.X.X for your preferred language under Applications.

6. Select Download and save the file to your computer.

To install the Disc2Phone from the downloaded file

1. Double-click on the downloaded Disc2Phone file.

2. If needed, follow the instructions to download and install .NET Framework 1.1 SP1 from Internet.

3. InstallShield Wizard: Click Next to continue the installation.

4. InstallShield Wizard: Read and accept the licence agreement, then click Next.

5. InstallShield Wizard: Click Next to install to the default folder.

6. InstallShield Wizard: Click Install to begin the installation.

7. InstallShield Wizard: Click Finish to exit the wizard.

It is recommended that you install PC Suite before installing Disc2Phone.

When starting Disc2Phone for the first time, the software needs to be activated.

Enter your email address in the text field and click Register to activate the software.

Getting started Transfer and listen to music

5April 2006

Connect the USB cable

Before you can begin transferring music to your phone, you need to establish a connection between

your phone and your computer. The Sony Ericsson USB cable that comes with your phone can be

used to connect the computer and the phone.

Your phone can be either turned on or turned off when connecting the USB cable. If the phone is on,

select File Transfer in the pop-up that appears in the phone. The phone will turn off in this mode.

To connect your phone to a computer via the USB cable

1. Connect the USB cable to your phone and computer.

2. Computer: If the Found New Hardware Wizard appears, click Cancel to exit the wizard.

3. Phone: When your phone is turned on, }File Transfer in the pop-up.

4. Wait for your phone to prepare for file transfer.

5. Computer: Your phone memory and Memory Stick are added as removable disks in Windows Explorer.

6. Computer: If a dialog box asks what you want to do with the files on the removable disks

(the phone memory and Memory Stick), select Take no action.

7. Use one of the described computer software to transfer the music:

%5 Using Disc2Phone to add music

%6 Using Windows Explorer to add music

%6 Using Windows Media Player 10 to add music

%7 Using iTunes 6 to add music

Transfer music

Using Disc2Phone to add music

Your phone works with the Disc2Phone computer software, included on the CD that comes with the

phone. Use Disc2Phone to transfer WAV and MP3 tracks from CDs or your computer to your phone.

This way the music files are transferred in an automatic Artist-Album-Title order. Follow the procedures

below to start using Disc2Phone.

To transfer music using Disc2Phone

1. Computer: Start Disc2Phone from the PC Suite by clicking on the Disc2Phone icon, or double-click

on the shortcut to Disc2Phone on your desktop.

2. Computer: Select My Music, Audio CD or My Computer as a music source.

3. Computer: Locate and select the folder with the tracks you want to transfer.

4. Computer: Add tracks to the Transfer List:

• To add all the tracks from the folder, click Add.

• To add specific tracks from the folder, open the folder, mark the tracks and click Add.

When starting Disc2Phone for the first time, the software needs to be activated.

Enter your email address in the text field and click Register to activate the software.

Tracks found on a music CD will be displayed directly in the Transfer List.

Getting started Transfer and listen to music

6April 2006

5. Computer: Select the location to transfer the files to in the drop down list (Removable Disk).

6. Computer: Click Transfer to transfer the files from the Transfer List to your phone.

7. Computer: For details on transferring music, please refer to Disc2Phone Help.

Click in the top right corner of the Disc2Phone window.

8. Computer: Close the Disc2Phone software, right-click on both Removable Disk icons in Windows

Explorer and select Eject to disconnect the USB cable. A pop up will appear in the phone saying

that it is safe to disconnect the USB cable.

Using Windows Explorer to add music

To add music using Windows Explorer

1. Computer: Open Windows Explorer.

2. Computer: Find the folder where you have stored the music that you want to transfer. Usually all

music is stored in the My Music folder under Windows Explorer/My Documents, unless you specifically

changed folders.

3. Computer: Browse to the music you want to transfer.

4. Computer: Open My Computer in a separate window.

5. Computer: In My Computer/Removable Disk (drive:) check if the MP3 folder exists. If you do not have

this folder, right click and select New/Folder, name the folder MP3.

6. Computer: Keep the Windows Explorer window and the MP3 window (My Computer/Removable

Disk (drive:)/MP3) open side by side.

7. Computer: Select the MP3 files you wish to transfer in Windows Explorer and drag-and-drop them

to the MP3 folder (that is, the phone memory or Memory Stick), either one by one, or several at a time

by pressing Shift or Ctrl and clicking on the files.

8. Computer: Right-click on both Removable Disk icons in Windows Explorer and select Eject to

disconnect the USB cable. A pop up will appear in the phone saying that it is safe to disconnect

the USB cable.

Using Windows Media Player 10 to add music

To rip music using Windows Media Player 10

1. Computer: Start Windows Media Player. (Make sure all other music applications are closed.)

2. Computer: Insert the music CD into the CD drive.

3. Computer: Click the Rip tab. The tracks of the inserted CD are displayed and selected to be copied.

4. Computer: Click Rip Music.

5. Computer: When the tracks have been copied, click the Library tab.

To transfer music using Windows Media Player 10

1. Computer: Open Windows Media Player.

2. Computer: If the Device Setup window appears, select Manual and click Finish.

3. Computer: Go to the Library tab in Windows Media Player.

Do not disconnect the USB cable during file transfer as this may harm the phone memory

or Memory Stick.

Do not disconnect the USB cable during file transfer as this may harm the phone memory

or Memory Stick.

Windows Media Player, by default, will rip all tracks into WMA (Windows Media Audio). Go to Tools/

Options/the Rip Music tab and select MP3 instead. Your phone supports bit rates up to 192 Kbps.

Getting started Transfer and listen to music

7April 2006

4. Computer: Click Tools /Options/the Devices tab and select the Removable Disk (drive:).

Click on Properties and mark the “Create folder hierarchy on device” check box. Click OK, twice.

5. Computer: Select the tracks you want to transfer to your phone, right-click on the selection and select

Add to/Sync List.

6. Computer: Click the Start Sync button.

7. Computer: Close Windows Media Player, right-click on both Removable Disk icons in Windows

Explorer and select Eject to disconnect the USB cable. A pop up will appear in the phone saying

that it is safe to disconnect the USB cable.

Using iTunes 6 to add music

To copy music using iTunes

1. Computer: Start iTunes.

2. Computer: Insert the music CD into the CD drive.

3. Computer: Click on the CD in the Source list.

4. Computer: Click Edit/Preferences and select the Advanced tab and then the Importing tab.

5. Computer: Select format in the Import Using: drop-down menu (MP3, WAV and AAC are supported).

6. Computer: Select bit rate in the Setting: drop-down menu (bit rates up to 192 kbps are supported).

7. Computer: Click OK.

8. Computer: Click Import CD.

9. Computer: When tracks have been copied, click on Library in the Source list.

10. Computer: Mark the tracks to transfer and click Edit/Copy.

11. Computer: Open My Computer/Removable Disk (drive:) and check if the MP3 folder exists.

If you do not have this folder, right click and select New/Folder, name the folder MP3.

12. Computer: Open the MP3 folder and select Edit/Paste.

13. Computer: Close iTunes, right-click on both Removable Disk icons in Windows Explorer and select

Eject to disconnect the USB cable. A pop up will appear in the phone saying that it is safe to

disconnect the USB cable.

Do not disconnect the USB cable during file transfer as this may harm the phone memory

or Memory Stick.

Do not disconnect the USB cable during file transfer as this may harm the phone memory

or Memory Stick.

Getting started Transfer and listen to music

8April 2006

Use WALKMAN™ player to listen to music

To play music

1. }WALKMAN and browse for songs by artists, tracks or playlists. You can also browse for video clips.

Press to open a list, press to go back in a list.

2. Highlight a track }Play.

WALKMAN™ player controls

•Press to pause the playback. Press again to resume playing.

• Press to go forward to the next music track or video clip.

• Press to go back to the previous music track or video clip.

• Press and hold or to fast forward or rewind when playing music tracks or video clips.

• Press or to show a track-by-track view of the current list when playing music tracks.

Files that are highlighted will not be selected until you }Play.

• When a video clip is playing, press to play the video in slow motion. To resume normal playback,

}Play.

• When a video clip is paused, press to play the video one frame at a time.

• Press to go to the WALKMAN™ player, or to minimize and maximize the WALKMAN™ player

during playback. This control only works when the WALKMAN™ player is playing music files.

• Press to go to the WALKMAN™ player browser when in the Now Playing view.

• Press and hold one of the volume buttons to skip a track.

Browsing files

In the WALKMAN™ player browser you can browse for music and video content in lists:

•Artists – lists music you have transferred to the phone, sorted in an Artist-Album-Title order.

•Tracks – lists all music files in your phone memory and on the Memory Stick.

•Playlists – create or play your own lists of sound files.

•Videos – lists all video clips in your phone.

Playlists

To organize the media files that are stored in the File Manager, you can create playlists. Files in a playlist

can be sorted by artist, title or by the order in which the files were added to the playlist. You can add a file

to more than one playlist.

When you delete a playlist or a file from a playlist, it is not deleted permanently from the phone memory

or Memory Stick. You can add the file to another playlist.

Getting started Transfer and listen to music

9April 2006

To create a playlist

1. }WALKMAN }Playlists }New Playlist }Add enter the name of the playlist }OK.

2. Select from the files that are available in the File Manager. You can add several files at a time

and you can also add folders. All files in the selected folders will be added to the playlist.

3. }Add to add the selected files to the playlist. The playlist is now saved and can be used.

To add files to a playlist

1. }WALKMAN }Playlists select a playlist }Open }More }Add Media.

2. Select from the files that are available in the File Manager.

3. }Add to add the selected files to the playlist. The changes to the playlist are now saved.

To remove files from a playlist

1. }WALKMAN }Playlists select a playlist }Open.

2. Select the file and press .

To delete a playlist

}WALKMAN }Playlists select a playlist and press .

WALKMAN™ player options

Depending on what is selected when you press More you will have different options to choose from.

}More to view a selection of the following options:

•Now Playing – go to the Now Playing view.

•Add Media – add files or folders to the playlist.

•Sort – sort the playlist by artist, title or by the order in which files were added to the playlist.

•Delete – remove a file from the playlist. In playlists you have created, the file is only removed

from the playlist. In the Artists list, the file is permanently deleted from the memory.

•Rename – rename the playlist. You can only rename user-created playlists.

•Delete Playlist – delete the playlist. Only the playlist is deleted; the files are still listed

in the File Manager. You can only delete user-created playlists.

•Minimize – minimize the WALKMAN™ player during playback.

•Information – view information about the current track or video.

•Play Mode – change the playback order of songs and videos. Select Shuffle to play the playlist

files in random order, or Loop to restart the playlist when the last file has been played.

•Equalizer – change the settings of the treble and bass when playing music.

•Send – send a sound or video clip.

•Full Screen – view video clips in maximum size.

•Capture Frame – when a video clip is paused, capture a picture from the video clip.

Additional information

Support documents, software, settings and more information are available at www.sonyericsson.com/

support.

Getting started Transfer and listen to music

10 April 2006

Formats

The following formats are supported in your phone:

iTunes is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.

WALKMAN™ and the WALKMAN™ logo and symbol are registered trademarks of Sony Corporation.

Memory Stick™, Memory Stick Micro™ and M2™ are trademarks or registered trademarks

of Sony Corporation.

Microsoft, Windows and Windows Media Player are either registered trademarks or trademarks

of Microsoft Corporation in the U.S and other countries.

Other product and company names mentioned herein may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

File types Formats Extensions

Audio AAC

AAC+

MP3 (192 kbit/s for local playback)

MP4

M4A

3GP

(Audio encoded in AAC or AMR)

AMR

WAV

G-MIDI (level 1 with 40 voices polyphony)

.mp3

.mp4

.m4a

.3gp

.amr

.wav

.mid

Video

(including audio part)

MP4

(video: MPEG4, audio: AAC or AMR)

3GP

(video: MPEG4 or H.263, audio: AAC or AMR)

.mp4

.3gp

Streaming transport RTSP according to 3GPP™

Andere Handbücher für Walkman Phone

Inhaltsverzeichnis

Andere Sony Ericsson Handy Handbücher

Sony Ericsson

Sony Ericsson G705U Bedienungsanleitung

Sony Ericsson

Sony Ericsson T61c Bedienungsanleitung

Sony Ericsson

Sony Ericsson Walkman W715 Bedienungsanleitung

Sony Ericsson

Sony Ericsson K550 Bedienungsanleitung

Sony Ericsson

Sony Ericsson EXPERIA Mini ST15i Referenzhandbuch

Sony Ericsson

Sony Ericsson XPERIA active ST17a Technisches Handbuch

Sony Ericsson

Sony Ericsson W595s Bedienungsanleitung

Sony Ericsson

Sony Ericsson K530 Bedienungsanleitung

Sony Ericsson

Sony Ericsson Z208 Bedienungsanleitung

Sony Ericsson

Sony Ericsson P900 Kurzanleitung

Sony Ericsson

Sony Ericsson T226 Kurzanleitung

Sony Ericsson

Sony Ericsson Walkman W880 Bedienungsanleitung

Sony Ericsson

Sony Ericsson V630i V630i V630i Kurzanleitung

Sony Ericsson

Sony Ericsson S700c Bedienungsanleitung

Sony Ericsson

Sony Ericsson Cyber-Shot K770 Bedienungsanleitung

Sony Ericsson

Sony Ericsson Walkman W880 Bedienungsanleitung

Sony Ericsson

Sony Ericsson CYBER-SHOT C510 Kurzanleitung

Sony Ericsson

Sony Ericsson P910a P910a P910a Bedienungsanleitung

Sony Ericsson

Sony Ericsson CMD-Z7 Bedienungsanleitung

Sony Ericsson

Sony Ericsson W880i Bedienungsanleitung

Sony Ericsson

Sony Ericsson Z558 Bedienungsanleitung

Sony Ericsson

Sony Ericsson C903 Cyber-shot Bedienungsanleitung

Sony Ericsson

Sony Ericsson K508i Bedienungsanleitung

Sony Ericsson

Sony Ericsson Z770i Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
