INSTRUCTION

MANUAL

Miniature Weatherproof

Color Camera

CVC61HRB(Black)

CVC61HRW(White)

Speco Technologies is constantly developing product improvements.

We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 4/20/2012

CVC71HRB(Black)

CVC71HRW(White)

•To avoid electrical shock, do not open the case of this product.

•Only use a regulated DC 12V Power supply to operate this product.

•Do not overload electrical outlets or extension cords. This can result in a fire or

electrical shock.

•Keep this product away from strong magnetic fields.

•Do not expose this product in direct sunlight or strong reflected rays.

•Refer servicing to qualified personnel only.

•Do not change or modify this product. This willvoid the warranty.

•

1. Loosen the two locking screws①, using the supplied hex-head wrench and remove

the mounting base.

2. Attach the mounting base②to a suitable solid surface, such as a wall or ceiling. On

partitioning locate a wall stud or ceiling joist. Secure the mounting base using the

supplied screws③. Fit the camera④to the mounting base ②and fix in to position

using the two locking screws①, secure them with the hex-head wrench.

3. How to set the angle of view:

Loosen the two locking screws①, using the supplied hex-head wrench, and set the

desired camera angle by moving the camera right /left and up/down.

4. Connect the video connector (BNC) of the camera cable to the incoming video

cable. The other end of the video cable should be connected to a DVR or Monitor.

Plug the camera power connector (red DC jack) into the DC12V regulated power

nodeyalpsideblliwerutcipehtdnaylppusrewopehtnohctiwS.ylppus a monitor.

Precautions

Features

Installation

•

1/3” Sony Super-HAD™ CCD

540 TV Lines Super High Resolution

Compact Size - Only 1.89” In Diameter!

Vandal Resistant Housing

Cast Aluminium Construction

Integrated

Integrated 10pc IR LEDs

3.4mm Fixed Lens

Impressive Picture Quality

Weatherproof (IP66 Rated)

12V DC Required

Specifications

1.89”

1.46”

Image Sensor

Lens

Scanning System

Frequency

Video Output

Gain Control

White Balance

Power Supply

Dimensions

Weight

1/3” Sony Super-HAD™ CCD

540 TV Lines

0.1 Lux(IR LED ON : 0.0002Lux)

Built-In 10 IR LEDs

5 m

3.4mm Fixed Lens

768 x 594

Auto: 1/60 ~ 1/120,000 Seconds

2:1 Interlace

Internal

1.0Vp-p~75 Ohm

>50dB (AGC Oﬀ)

Auto

IP66

-4 ~ +140° F

12V DC Required

120mA Max.

1.89”(Dia) x 1.46”(H)

0.25 lbs.

•

LED

•

• IR Distance

•

1.89” dia

1.46”
