INSTRUCTION

MANUAL

Speco 3MP-TVI IR Series

Speco Technologies is constantly developing product improvements.

We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 1/13/2017

HT7043T

(IR Bullet Camera)

HT5943T

(IR Dome Camera)

Contents

◑

Contents...................................................... 1

◑

Precautions ................................................. 2-3

◑

Safety Instructions ...................................... 4

◑

Package Contents....................................... 5

◑

Camera Installation ..................................... 6-9

◑

Lens Adjustment ......................................... 10-11

◑

Specications.............................................. 12-13

◑

Camera Dimension ..................................... 14

◑

Features...................................................... 15

◑

OSD Menu Details ...................................... 16-29

◑

Trouble Shooting......................................... 30

Precautions

Do not install the camera in

extreme temperature conditions.

Do not touch the front lens of the

camera.

Never keep the camera pointed

directly at strong light.

Do not expose the camera to

radioactivity.

Do not install the camera under

unstable lighting conditions.

Do not drop the camera or subject

it to physical shocks.

Only use the camera under conditions

where temperatures are between

-10°C and +50°C. Be especially careful to

provide ventilation when operating under

high temperatures.

This is one of the most important parts of

the camera. Be careful not to leave

fingerprints on the lens cover.

It can cause malfunctions to occur. If exposed to radioactivity the CCD

will fail.

Severe lighting change or flicker can

cause the camera to work improperly.

Housing damage can compromise

weatherproof ratings.

NOTE

* If the camera is exposed to spotlight or object reflecting strong light,

smear or blooming may occur.

* please check that the power satisfies the normal specification before

connecting the camera.

Safety Instructions

Precautions for use

Please handle this camera carefully :

◑ This camera should be installed by qualied personnel only

◑There are no user serviceable parts inside

◑Do not disassemble this camera other than to make initial adjustments

◑Use a UL approved regulated 24 volt AC or 12 volt DC power supply

◑

Use appropriate low voltage power cable to prevent re or electrical shock

◑

Please insure that your installation area can support the weight of the camera

◑Do not use a strong or abrasive detergent when cleaning the camera

◑Do not install near cooling or heating device

Package Contents

Please make sure that the following items are included in the Package:

1) HT7043T

• 1 Video Test Connector, Power Jack

• 1 Focus Adjustment

• 1 Bracket Base

• 1 Wrench

• Set Screw

- 4 Tapping Screws 4x25

- 4 Hexagon Socket Screws M5x10

2) HT5943T

• 1 Video Test Connector, Power Jack

• 1 Chameleon Cover

• 1 Wrench

• Set Screw

- 3 Tapping Screws 3.5x20

CAMERA INSTALLATION

CONNECT POWER CABLE

1. WHEN USING 12 VOLTS DC (constant voltage 500mA)

2. WHEN USING 24 VOLTS AC (40 Volt Amps)

3. CONNECT VIDEO CABLE

CONNECT BLACK COLOR BNC CABLE TO THE BNC JACK.

DC 12V Power Supply

Power In put :R ED

Center : (+)

T V I

LBACK:(-)

RED(+)

Power Supply

AC 24V

CAMERA INSTALLATION

Compatibility

1) HT7043T

CVCJBB INTJBS INTCM

2) HT5943T

CVCJBD

→

Adaptor plate(59PLATE) with rubber

CAMERA INSTALLATION

CAUTION : The installation instructions in this manual are for use by qualified service

personnel only. To reduce the risk of electric shock, do not perform any servicing other

than that contained in the operating instructions unless you are qualified to do so.

3AXIS BRACKET

SCREW TS T1, 4X25, TH, SUS, 4EA

SCREW M5X10, HEXAGON SOCKET, SUS, BK, 4EA

WALL

1. HT7043T

CAMERA INSTALLATION

2. HT5943T

VANDAL DOME BASE

VANDAL DOME BODY

BODY OUTER COVER SPECO

SCREW TS T1, 3.5X20, PH, SUS, 3EA
